Supplementary Instructions
This manual contains supplementary instructions regarding the use of the computer.
It explains the cases where the operation of the computer differs from that in the Operating Instructions.
This model is equipped with a CD-R/RW drive and Easy CD Creator™ 4/DirectCD™ 3 CD-ROM. Also featured is a slot for
accommodating a smart card: this feature makes it possible to use the security functions that, for instance, prohibit the unauthorized
use of the computer by anyone who does not have a smart card. (A smart card and software (application software, driver, addi-
tional Microsoft modules, etc.) need to be purchased separately for this.)
Using a smart card
CAUTION
Do not bend the card or force it into the slot.
Do not touch the contact area or press down on it forcefully. Otherwise, the card may no longer work properly.
For other details on how to handle the card, refer to the instructions that accompany the card.
When using a smart card, do not select [Refresh] in [Device Manager] of [Control Panel]-[System]. Doing so will make the
smart card unusable. If you should happen to select [Refresh], the smart card can be used again by entering standby or
hibernation mode and then resuming operation, or alternatively, by restarting the computer.
Installing the smart card
NOTE
Confirm that [Smart Card] is set to [Auto] or [Enable] in [Advanced] menu of
Setup Utility.
1
Press the smart card eject button and confirm that the button is not sticking out.
2
Align the smart card so that the location of the contact is as shown in the figure
on the right, and then insert the card all the way into the slot.
Removing the smart card
Press the smart card eject button, and pull out the card.
CAUTION
Remove the smart card only with the eject button. If you pull the smart card
without using the eject button, it may cause damage to the reader contact.
Contact
Smart Card
(Press the center part of the card
and insert it with the contact side
up.)
Smart Card
Eject Button
1
