READ INSTRUCTIONS CAREFULLY:
Place instructions in a safe place for future reference. Do not allow anyone
who has not read these instructions to assemble, turn on, adjust or operate
the heater.
Models: HCK-BX2UK; HCK-BX3UK
1.1
Disconnect the heater from the mains power supply, before servicing or
performing any cleaning or maintenance. Servicing or maintenance must
only be carried out by a qualified electrician or service agent
1.2 WARNING: In order to avoid overheating, do not cover the heater.
1.3 CAUTION-some parts of this product can become very hot and cause burns.
Particular attention has to be given where children and vulnerable people are
present.

2. Introduction

2.1 . This unit is designed to raise the ambient temperature of an entire room, the
temperature of the air coming out of the front of the heater will be warmer than the
general temperature of the room, but there may not be a significant increase due
to the large volume of air passing over the element. For the same reason, the
element is hot during operation, but does not glow visibly. The room temperature
depends on room size, insulation and the ambient temperature, which will
increase as the room gets warmer.
2.2 The unit incorporates a thermostat and a self-resetting thermal cut-out to
control the heating elements. The thermostat feels the air temperature and
controls the surrounding temperature. The fan motor is not controlled by the
thermostat and it keeps on working when the thermostat cuts off the heating
element. The self-resetting thermal cut-out will switch off the heater to ensure the
safety in the event of overheating.
User's Manual and
Operating
Instructions
1
Read and follow all instructions.
PREMIUM
QUALITY
FAN HEATERS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCK-BX2UK and is the answer not in the manual?

Questions and answers

Summary of Contents for Climate King HCK-BX2UK

  • Page 1 Place instructions in a safe place for future reference. Do not allow anyone who has not read these instructions to assemble, turn on, adjust or operate the heater. Models: HCK-BX2UK; HCK-BX3UK Disconnect the heater from the mains power supply, before servicing or performing any cleaning or maintenance. Servicing or maintenance must only be carried out by a qualified electrician or service agent 1.2 WARNING: In order to avoid overheating, do not cover the heater.
  • Page 2 This is quite normal and it stops after a short time. The heating element is made of stainless steel and was coated with protection oil during production. The smoke is caused by the residual oil burning off when heated . 3. Technical specifications Model HCK-BX2UK HCK-BX3UK Waterproof Class IPX4 IPX4...
  • Page 3 5. Safety regulations It is the responsibility of the owner and the operator to read, understand and comply with the following: You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and any other connectors for wear or damage.
  • Page 4 and similar. 5.2.3 Do not cover the fan heater. 5.2.4 The fan heater must not be located immediately below a wall socket. 5.2.5 Do not connect the fan heater using an on/off timer or other equipment which can automatically switch the device on. 5.2.6 The fan heater must not be placed in rooms where flammable liquids or gases are used or stored or where industrial powders or chemicals are used that could block the heater or any of its parts.
  • Page 5 This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 6 Problem Possible cause Treatment The heater does not The plug is loose, bad Pull out the plug, check the operate,even when connection connection of the plug and it is plugged in and socket. Then connect again. the switch, No power in socket outlet Insert the plug in a proper thermostat are socket...
  • Page 7 If you have any problems with this product, please in the first instance call the retailer from whom you purchased it. Climate King Cottage Stores LLP 7 Harris Drive...

This manual is also suitable for:

Hck-bx3uk
