Steinway & Sons Model P100
OWNER'S
MANUAL
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Steinway & Sons P100 and is the answer not in the manual?

Questions and answers

Related Manuals for STEINWAY LYNGDORF Steinway & Sons P100

Summary of Contents for STEINWAY LYNGDORF Steinway & Sons P100

  • Page 1 Steinway & Sons Model P100 OWNER’S MANUAL Version 1.0...

  • Page 2: Table Of Contents

    Table of Contents Compliance ......................4 Pre-Installation ..................... 5 Unpacking the Product ..................5 Operating Voltage .................... 5 Ventilation Requirements ................. 5 Heat output ....................... 5 Home Automation System Integration ..............6 Preparing the Model P100 for Mounting in a Rack ..........7 Rear Panel ......................
  • Page 3 Audio Setup ....................... 19 Audio Processing ................... 19 Voicing Setup ....................19 Zone B ....................... 19 Setup ......................19 System Configuration ..................20 General Setup ....................20 Trigger In Setup ....................20 Trigger Out Setup ................... 20 Network Configuration ..................21 Streaming Setup .....................

  • Page 4: Compliance

    Steinway Lyngdorf products and accessories comply with parts 15 and 68 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference;...

  • Page 5: Pre-Installation

    Unpacking the Product Carefully remove the unit and accessory kit from the carton and check for shipping damage. Contact both the shipper and your Steinway Lyngdorf representative immediately if the unit bears any sign of damage. Note: Keep the shipping carton and all packing material for future use. If this unit is shipped without the original packing, damage could occur and void the warranty.

  • Page 6: Home Automation System Integration

    Cables and Plugs Use only mains cables and power plugs approved by Steinway Lyngdorf. Using other types may cause damage to the system and will void the warranty. Connecting For cabling between the processor and amplifiers, please use RJ45 to RJ45 B standard cables. Use only cables and connectors approved by Steinway Lyngdorf.

  • Page 7: Preparing The Model P100 For Mounting In A Rack

    Preparing the Model P100 for Mounting in a Rack The Model P100 processor is equipped from the factory with feet for free-standing placement on a shelf, table, or rack. To install the Model P100 in a rack: 1. Turn the Model P100 upside down and place it on a stable, even surface. 2.

  • Page 8: Rear Panel

    1 RS-232 connector for serial control of the unit. • 5 Digital Link outputs for connecting Steinway Lyngdorf’s amplifiers. Note: Do not use the USB ports for charging smartphones and tablets. In Standby mode, only LAN A is active; LAN B connector is not active.

  • Page 9: Remote

    Remote The Model P100 comes with a dedicated RF and IR remote control for installations and everyday use. Setup Access the installation menu. Standby Turn the Model P100 on and into standby. Audio Access the post-processing menu. “Picture-in-picture” /not supported in P100. Up/Down Move up and down in menus.

  • Page 10: How To Pair Remote

    How to Pair Remote The remote control is paired to the Model P100 at the factory, and you only need to pair it again if you have a new Model P100 or remote. To pair the RF remote control to a Model P100: 1.

  • Page 11: Installation Via Web Interface

    Installation Via Web Interface You will need a computer, and the Model P100 must be connected to an existing network, or you may use a crossover network cable for direct connection. If you do not know the IP address of the Model P100 on your local network, the Model P100 supports Apple´s Bonjour Discovery service, which must be on the computer you want to set up the Model P100 with.

  • Page 12: Edit

    Select the default voicing. Video input Select the video input. Preset vTuner station Select and preset a vTuner internet radio station. Speaker configuration Select which speaker configuration to use. Trigger out Choose which trigger output to activate when using this source. Audio input Select the audio input.

  • Page 13: Speaker And Room

    To add a file, insert a USB stick with the speaker configuration file you have received from your Steinway Lyngdorf representative, select the file and press Add. The speaker configuration will be added to the Speaker Configuration list. After adding the speaker configuration, it will be visible as a menu below Speaker Configuration.

  • Page 14: Media Player

    • If the woofers are lower than the listening position, measure the distance from the listening position to the back edge of the top woofer. When measuring distances to in-wall boundary woofers: • If the stack of woofers is taller than the listening position, measure the distance from the listening position to the dust cap of the middle of the stack of woofers.

  • Page 15: How To Set Up Roomperfect

    If the microphone has been dropped on the floor, it may be damaged. If this is the case, obtain a new microphone from your Steinway Lyngdorf representative before performing the system calibration.

  • Page 16: Measuring The Focus Position

    Measuring the Focus Position When the calibration volume has been set, RoomPerfect™ will send a range of tones to measure the focus position. If there is noise in the room, the measurement may take longer. This will not affect the quality of the result. See RoomPerfect™...

  • Page 17: Room Measurements Above 90% Roomknowledge

    • the microphone should not be closer than 0.5m/1.5ft from the floor, ceiling, and walls. • the microphone should be at least 1m/3ft from the front of the loudspeakers. • there should be at least 50cm/1.5ft between each measurement. • do not take symmetrical measurements in the room.
  • Page 18 To fully optimize RoomPerfect™’s understanding of the room’s acoustical properties, we recommend you keep doing measurements until the RoomKnowledge is above 95%. The higher the RoomKnowledge, the more accurate the room correction filters will be. Calculation of Focus and Global Filters When room measurements are complete, the system will calculate the focus and global filters automatically.

  • Page 19: Audio Setup

    Audio Setup Audio Processing This menu allows you to manage the dedicated audio processing presets for DTS, NeoX, AURO, and Dolby. Voicing Setup A voicing is an equalizer filter that can be activated to amplify or attenuate certain frequencies according to your personal preferences.

  • Page 20: System Configuration

    System Configuration General Setup Power management • Choose the standby mode: Deep sleep – The Model P100 cannot be turned on via LAN, CEC or a control system. Network - The Model P100 can be turned on via LAN, CEC or a control system. •...

  • Page 21: Network Configuration

    Network Configuration Change the network mode to manual or automatic. For more info, see the Network Setup chapter. Streaming Setup Configure streaming player setup. • Streaming players can control volume – set to Off or On • Streaming players can change input source – set to Off or On •...

  • Page 22: Software Update

    Software Update Note: Please don’t unzip or change the name of the file. Simply save it and upload it to the Model P100. If you are using a Mac, please right-click and “save as,” rather than downloading the file, to avoid automatic unzipping. Update from Local Files Via web interface: 1.

  • Page 23: Troubleshooting

    Troubleshooting RoomPerfect™ The calibration microphone is very sensitive and may pick up unwanted noise, including subsonic signals and background noise, which disturbs the measurements. If the signal is disturbed, it will take longer for the system to make a correct measurement. A measurement that has been disturbed by noise but completed will always be correct;...
  • Page 24 Retrieving and Sending an Error Log To retrieve an error log, you need to access the Model P100 via your browser. Here you can download a text file and email it to your Steinway Lyngdorf representative. 3D Compatibility Not Detected If the Model P100 isn´t fully booted, a Blu-ray player will not be able to detect its 3D compatibility.

  • Page 25: Network Setup

    Network Setup Connecting to Model P100 with a Network Cable It is possible to get access to the Model P100´s web interface via a direct cable connection between the Model P100 and a computer, or a connection via a hub or switch. If you have a direct cable connection to a laptop (with no switch or router between the two) the network cable must be a crossover type.

  • Page 26: Set Up A Fixed Ip Address In Windows Xp Or Windows 7

    Set Up a Fixed IP Address in Windows XP or Windows 7 Click Start / Control Panel / Network Connections to find the network connection that represents your connection to the Internet. Most often, this is labeled simply Local Area Connection. Right-click the connection and select Properties.

  • Page 27: Trademarks

    Rovi Corporation. Reverse engineering and disassembly are prohibited. Service Information In order to obtain warranty service, you must contact your original dealer or the Steinway Lyngdorf distributor of the region or country where you are located. If you have trouble locating an authorized representative, please contact service@steinwaylyngdorf.com.
