- Page 1 Installation Guidelines Milano II - 500mm Wall Basin with Shroud Wall Basin Model MBSM850.1 Shroud Model MBSM852 General Dimensions RECOMMENDED HEIGHT ~800-820...
- Page 2 INSTALLATION • Place the basin at the required position. Basin Top Line • Mark the line for the top of the basin (recommended to be 800 - 820mm above finished floor level). • Remove the basin, and mark the anchoring points 60mm below the required top line, and 200mm around centerline of basin (refer to diagram 1 and 2).
