Marbletrend Madeira Basin Mixer Installation Instructions

INSTALLATION INSTRUCTIONS
Basin and Sink Mixers
Congratulations on your purchase of Marbletrend tapware, we are confident that this
quality product will serve you reliably for many years.
These instructions apply to the following products:
Component diagram
Model
Madeira Basin Mixer
Madeira Tall Basin Mixer
Madeira Sink Mixer Curved Form
Madeira Sink Mixer Square Form
Sardina Basin Mixer
Sardina Tall Basin Mixer
Sardina Sink Mixer Curved Form
Sardina Sink Mixer Square Form
Mixer body
Base flange
with O-ring
Flexi-hoses
Base-nut
Taphole Max bench
Code diameter thickness
mm mm
MTM121 35 45
MTM223 35 45
43
MTM403 35
MTM423 35 40
MTS121 35 45
MTS223 35 45
MTS403 35 43
MTS423 35 40
Lever handle
Cover button
Aerator
Threaded
base
Bench/Basin top
Rubber
gasket
