LINEAR
LS SQAURE GANTRY ASSEMBLED
Page 1
SQUARE CANOPY ASSEMBLY INSTRUCTIONS
rear top
typical lug
channel
and plastic
washers
front glass
front channel
front track
EXPLODED DIAGRAM AND PARTS
When using lugs a white washer is to be
placed on each side of the glass.
Lugs should be screwed in finger tight.
Perspex rear
doors
top glass
corner
side glass
holder
side glass
U channel
door
handels
rear bottom
channel
Contact us on
COSSIGA.COM
Advertisement
Table of Contents
Related Manuals for Cossiga Linear Square Canopy
Summary of Contents for Cossiga Linear Square Canopy
- Page 1 U channel EXPLODED DIAGRAM AND PARTS LS SQAURE GANTRY ASSEMBLED When using lugs a white washer is to be placed on each side of the glass. Lugs should be screwed in finger tight. Contact us on COSSIGA.COM Page 1...
- Page 2 Put the two side glass U channel Position rear track. Remove pieces on each side line up with double sided tape and stick front and side edges. This is also down. a guide for front glass track. Contact us on COSSIGA.COM Page 2...
- Page 3 U shaped holders in the U on top placing a white rubber channel. Screw in lugs on side washer on each side of glass. placing a white rubber washer on each side of glass. Contact us on COSSIGA.COM Page 3...
- Page 4 Position black corner holders Position front track - same as pieces - connect to top and side rear track. Remove double sided glass. There is a left and a right tape and stick down. holder piece. Contact us on COSSIGA.COM Page 4...
- Page 5 The front that need to go on to the glass before it is glass should be able to pivot forwards and pushed into glass channel. back - roughly on 45 degree angle. Contact us on COSSIGA.COM Page 5...
- Page 6 Place three locating screws into three holes across a white washer on the inside of the glass. the top glass with nuts underneath. use white washers each side of glass. Contact us on COSSIGA.COM Page 6...
- Page 7 LINEAR SQUARE CANOPY ASSEMBLY INSTRUCTIONS Perspex doors are then placed in Note: For LS4 /5 /6 units fit the top glass tracks. support bar in the centre and on top of the light box. Contact us on COSSIGA.COM Page 7...
