Summary of Contents for ASROCK Z390M-STX MXM

  • Page 2 Version 1.0 Published September 2018 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 AUSTRALIA ONLY Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage caused by our goods. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Motherboard Layout Front Panel Rear Panel Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (SO-DIMM) Installing Mobile PCI Express Module (MXM) Onboard Headers and Connectors M.2 WiFi/BT Module and Intel® CNVi (Integrated WiFi/BT) Installation Guide M.2_SSD (NGFF) Module Installation Guide (M2_1, M2_3) M.2_SSD (NGFF) Module Installation Guide (M2_2)
  • Page 5 Advanced Mode 4.3.1 UEFI Menu Bar 4.3.2 Navigation Keys Main Screen OC Tweaker Screen Advanced Screen 4.6.1 CPU Configuration 4.6.2 Chipset Configuration 4.6.3 Storage Configuration 4.6.4 ACPI Configuration 4.6.5 USB Configuration 4.6.6 Trusted Computing Tools Hardware Health Event Monitoring Screen Security Screen 4.10 Boot Screen...

  • Page 6: Chapter 1 Introduction

    1.1 Package Contents • Z390M-STX MXM / B360M-STX MXM Motherboard (Micro-STX Form Factor) • Z390M-STX MXM / B360M-STX MXM Quick Installation Guide • Z390M-STX MXM / B360M-STX MXM Support CD • 1 x I/O Panel Shield...

  • Page 7: Specifications

    1151) (Up to TDP 65W CPU) • 5+1 Power Phase design • Supports Intel® Turbo Boost 2.0 Technology Chipset • Intel® Z390 (for Z390M-STX MXM) • Intel® B360 (for B360M-STX MXM) Z390M-STX MXM: Memory • Dual Channel DDR4 Memory Technology • 2 x DDR4 SO-DIMM Slots...
  • Page 8 Z390M-STX MXM / B360M-STX MXM Onboard • Intel® UHD Graphics Built-in Visuals and the VGA outputs Graphics can be supported only with processors which are GPU integrated. • Supports Intel® UHD Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel®...
  • Page 9 • 1 x Mini DisplayPort • 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) Z390M-STX MXM: • 2 x USB 3.1 Gen1 Ports (Supports ESD Protection (Full Spike Protection)) • 2 x USB 3.1 Gen2 Ports (Supports ESD Protection (Full Spike...
  • Page 10 • 1 x RGB LED Header Connector * Supports in total up to 12V/3A, 36W LED Strip • 1 x Addressable LED Header (for Z390M-STX MXM only) * Supports in total up to 5V/3A, 15W LED Strip • 2 x CPU Fan Connectors (4-pin) * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.

  • Page 11: Motherboard Layout

    1.3 Motherboard Layout Z390M-STX MXM Top View CPU_FAN1 CPU_FAN2 DC Jack Mic In USB 3.1 Gen2 USB_10 USB 3.1 Gen1 T: USB8 B: USB9 USB 3.1 Gen2 USB_1 USB 3.1 Gen2 T: USB6 B: USB7 CLRCMOS1 Headphone / Headset BIOS...
  • Page 12 Z390M-STX MXM / B360M-STX MXM Bottom View Intel Chipset CLRCMOS2 CMOS Battery...
  • Page 13 No. Description CPU Fan Connector (CPU_FAN1) 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_A1, DDR4_B1) CPU Fan Connector (CPU_FAN2) USB 2.0 Header (USB_2_3) USB 2.0 Header (USB_4_5) System Panel Header (PANEL1) 3W Audio AMP Output Wafer Header (SPEAKER1) RGB LED Header (RGB_LED1) Addressable LED Header (ADDR_LED1) Clear CMOS Pad (CLRCMOS1) 5-Pin GPU Fan Connector (GPU_FAN1)
  • Page 14 Z390M-STX MXM / B360M-STX MXM B360M-STX MXM Top View CPU_FAN1 CPU_FAN2 DC Jack Mic In USB 3.1 Gen2 USB_10 USB 3.1 Gen1 T: USB8 B: USB9 USB 3.1 Gen2 USB_1 USB 2.0 T: USB6 B: USB7 CLRCMOS1 Headphone / Headset...
  • Page 15 Intel Chipset CLRCMOS2 CMOS Battery...
  • Page 16 Z390M-STX MXM / B360M-STX MXM No. Description CPU Fan Connector (CPU_FAN1) 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_A1, DDR4_B1) CPU Fan Connector (CPU_FAN2) USB 2.0 Header (USB_2_3) USB 2.0 Header (USB_4_5) System Panel Header (PANEL1) 3W Audio AMP Output Wafer Header (SPEAKER1)

  • Page 17: Front Panel

    1.4 Front Panel No. Description No. Description Headphone/Headset Jack (AUDIO1) USB 3.1 Gen1 Type-C Port (USB_10) USB 3.1 Gen2 Type-A Port (USB_1) Microphone Input (AUDIO2)

  • Page 18: Rear Panel

    Z390M-STX MXM / B360M-STX MXM 1.5 Rear Panel Z390M-STX MXM No. Description No. Description DC Power Din Jack USB 3.1 Gen2 Ports (USB_6_7) (Supports 19V Power Adapters) HDMI Port (HDMI) LAN RJ-45 Port* Mini DisplayPort (DP2) HDMI Port (HDMI1) DisplayPort (DP_1) USB 3.1 Gen1 Ports (USB_8_9)
  • Page 19 B360M-STX MXM: No. Description No. Description DC Power Din Jack USB 2.0 Ports (USB_6_7) (Supports 19V Power Adapters) HDMI Port (HDMI) LAN RJ-45 Port* Mini DisplayPort (DP2) HDMI Port (HDMI1) DisplayPort (DP_1) USB 3.1 Gen1 Ports (USB_8_9) * There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port...

  • Page 20: Chapter 2 Installation

    Z390M-STX MXM / B360M-STX MXM Chapter 2 Installation This is an Micro-STX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 21: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1151-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 22 Z390M-STX MXM / B360M-STX MXM...
  • Page 23 Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 24: Installing The Cpu Fan And Heatsink

    Z390M-STX MXM / B360M-STX MXM 2.2 Installing the CPU Fan and Heatsink...

  • Page 25: Installing Memory Modules (So-Dimm)

    2.3 Installing Memory Modules (SO-DIMM) This motherboard provides two 260-pin DDR4 (Double Data Rate 4) SO-DIMM slots. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4 slot; otherwise, this motherboard and SO-DIMM may be damaged. The SO-DIMM only fits in one correct orientation.
  • Page 26 Z390M-STX MXM / B360M-STX MXM...

  • Page 27: Installing Mobile Pci Express Module (Mxm)

    2.4 Installing Mobile PCI Express Module (MXM) This motherboard provides a Mobile PCI Express Module (MXM) Slot. Installing a Type A MXM Card (70mm)
  • Page 28 Z390M-STX MXM / B360M-STX MXM...
  • Page 30 Z390M-STX MXM / B360M-STX MXM Installing a Type B MXM Card (105mm)
  • Page 32 Z390M-STX MXM / B360M-STX MXM...
  • Page 33 Installing a Type B+ MXM Card (105mm-113mm) 7.6mm 7.6mm...
  • Page 34 Z390M-STX MXM / B360M-STX MXM...
  • Page 36 Z390M-STX MXM / B360M-STX MXM...

  • Page 37: Onboard Headers And Connectors

    2.5 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power (9-pin PANEL1) button, reset button and...
  • Page 38 Z390M-STX MXM / B360M-STX MXM Serial ATA3 Connectors These two SATA3 (see p.7, No. 12 and 13) connectors support SATA (see p.10, No. 11 and 12) data cables for internal storage devices with up to 6.0 Gb/s data transfer rate.
  • Page 39 This header is used to connect (3-pin ADDR_LED1) Addressable LED extension cable DO_ADDR (see p.6, No. 9) which allows users to choose VOUT (for Z390M-STX MXM from various LED lighting only) effects. Caution: Never install the Addressable LED cable in the wrong orientation; otherwise, the cable may be damaged.

  • Page 40: Wifi/Bt Module And Intel® Cnvi (Integrated Wifi/Bt) Installation Guide

    Z390M-STX MXM / B360M-STX MXM 2.6 M.2 WiFi/BT Module and Intel® CNVi (Integrated WiFi/BT) Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (Key E) supports type 2230 WiFi/BT module and Intel®...
  • Page 41 Step 3 Gently insert the WiFi/BT module or Intel® CNVi (Integrated WiFi/ BT) into the M.2 slot. Please be aware that the module only fits in one orientation. Step 4 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module.
  • Page 42 Z390M-STX MXM / B360M-STX MXM 2.7 M.2_SSD (NGFF) Module Installation Guide (M2_1, M2_3) The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA.
  • Page 43 Step 4 Move the standoff based on the module type and length. The standoff is placed at the nut location A by default. Skip Step 4 and 5 and go straight to Step 6 if you are going to use the default nut. Otherwise, release the standoff by hand.
  • Page 44 Z390M-STX MXM / B360M-STX MXM M.2_SSD (NGFF) Module Support List Vendor Interface ADATA SATA3 AXNS381E-128GM-B ADATA SATA3 AXNS381E-256GM-B ADATA SATA3 ASU800NS38-256GT-C ADATA SATA3 ASU800NS38-512GT-C ADATA PCIe3 x4 ASX7000NP-128GT-C ADATA PCIe3 x4 ASX8000NP-256GM-C ADATA PCIe3 x4 ASX7000NP-256GT-C ADATA PCIe3 x4 ASX8000NP-512GM-C...
  • Page 45 TEAM PCIe3 x4 TM8FP2240G0C101 TEAM PCIe3 x4 TM8FP2480GC110 Transcend SATA3 TS512GMTS600 Transcend SATA3 TS512GMTS800 V-Color SATA3 VLM100-120G-2280B-RD V-Color SATA3 VLM100-240G-2280RGB V-Color SATA3 VSM100-240G-2280 V-Color SATA3 VLM100-240G-2280B-RD SATA3 WDS100T1B0B-00AS40 SATA3 WDS240G1G0B-00RC30 PCIe3 x4 WDS256G1X0C-00ENX0 (NVME) PCIe3 x4 WDS512G1X0C-00ENX0 (NVME)
  • Page 46 Z390M-STX MXM / B360M-STX MXM 2.8 M.2_SSD (NGFF) Module Installation Guide (M2_2) The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Ultra M.2 Socket (M2_2) supports 2242/2260/2280 M.2 PCI Express module up to Gen3 x4 (32 Gb/s).
  • Page 47 Step 3 Move the standoff based on the module type and length. The standoff is placed at the nut location D by default. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut. Otherwise, release the standoff by hand.
  • Page 48 Z390M-STX MXM / B360M-STX MXM Step 6 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw NUT2 NUT1 as this might damage the module.
  • Page 49 M.2_SSD (NGFF) Module Support List Vendor Interface ADATA SATA3 AXNS381E-128GM-B ADATA SATA3 AXNS381E-256GM-B ADATA SATA3 ASU800NS38-256GT-C ADATA SATA3 ASU800NS38-512GT-C ADATA PCIe3 x4 ASX7000NP-128GT-C ADATA PCIe3 x4 ASX8000NP-256GM-C ADATA PCIe3 x4 ASX7000NP-256GT-C ADATA PCIe3 x4 ASX8000NP-512GM-C ADATA PCIe3 x4 ASX7000NP-512GT-C Apacer PCIe3 x4 AP240GZ280 Corsair...
  • Page 50 Z390M-STX MXM / B360M-STX MXM TEAM PCIe3 x4 TM8FP2240G0C101 TEAM PCIe3 x4 TM8FP2480GC110 Transcend SATA3 TS256GMTS400 Transcend SATA3 TS512GMTS600 Transcend SATA3 TS512GMTS800 V-Color SATA3 VLM100-120G-2280B-RD V-Color SATA3 VLM100-240G-2280RGB V-Color SATA3 VSM100-240G-2280 V-Color SATA3 VLM100-240G-2280B-RD SATA3 WDS100T1B0B-00AS40 SATA3 WDS240G1G0B-00RC30 PCIe3 x4...

  • Page 51: Polychrome Rgb

    2.9 Polychrome RGB Polychrome RGB is a lighting control utility specifically designed for unique individuals with sophisticated tastes to build their own stylish colorful lighting system. Simply by connecting the LED strip, you can customize various lighting schemes and patterns, including Static, Breathing, Strobe, Cycling, Music, Wave and more.
  • Page 52 Z390M-STX MXM / B360M-STX MXM Connecting the Addressable RGB LED Strip (for Z390M-STX MXM only) Connect your Addressable RGB LED strip to the Addressable LED Header (ADDR_LED1) on the motherboard. ADDR_LED1 DO_ADDR VOUT 1. Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.

  • Page 53: Chapter 3 Software And Utilities Operation

    Chapter 3 Software and Utilities Operation 3.1 Installing Drivers The Support CD that comes with the motherboard contains necessary drivers and useful utilities that enhance the motherboard’s features. Running The Support CD To begin using the support CD, insert the CD into your CD-ROM drive. The CD automatically displays the Main Menu if “AUTORUN”...

  • Page 54: Chapter 4 Uefi Setup Utility

    Z390M-STX MXM / B360M-STX MXM Chapter 4 UEFI SETUP UTILITY 4.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. You may run the UEFI SETUP UTILITY by pressing <F2> or <Del> right after you power on the computer, otherwise, the Power-On-Self-Test (POST) will continue with its test routines.

  • Page 55: Ez Mode

    4.2 EZ Mode The EZ Mode screen appears when you enter the BIOS setup program by default. EZ mode is a dashboard which contains multiple readings of the system’s current status. You can check the most crucial information of your system, such as CPU speed, DRAM frequency, SATA information, fan speed, etc.

  • Page 56: Advanced Mode

    Z390M-STX MXM / B360M-STX MXM 4.3 Advanced Mode The Advanced Mode provides more options to configure the BIOS settings. Refer to the following sections for the detailed configurations. To access the EZ Mode, press <F6> or click the "EZ Mode" button at the upper right corner of the screen.

  • Page 57: Navigation Keys

    4.3.2 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter>...

  • Page 58: Main Screen

    Z390M-STX MXM / B360M-STX MXM 4.4 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. Favorite Display your collection of BIOS items. Press F5 to add/remove your favorite items.

  • Page 59: Oc Tweaker Screen

    4.5 OC Tweaker Screen In the OC Tweaker screen, you can set up overclocking features. Because the UEFI software is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.
  • Page 60 Z390M-STX MXM / B360M-STX MXM BCLK Aware Adaptive Voltage BCLK Aware Adaptive Voltage enable/disable. When enabled, pcode will be aware of the BCLK frequency when calculating the CPU V/F curves. This is ideal for BCLK OC to avoid high voltage overrides.
  • Page 61 GT Current Limit Configure the current limit of the GT slice. A lower limit can protect the CPU and save power, while a higher limit may improve performance. GT Frequency Configure the frequency of the integrated GPU. DRAM Configuration DRAM Tweaker Fine tune the DRAM settings by leaving marks in checkboxes.
  • Page 62 Z390M-STX MXM / B360M-STX MXM Command Rate (CR) The delay between when a memory chip is selected and when the first active command can be issued. Secondary Timing Write Recovery Time (tWR) The amount of delay that must elapse after the completion of a valid write operation, before an active bank can be precharged.
  • Page 63 Third Timing tREFI Configure refresh cycles at an average periodic interval. tCKE Configure the period of time the DDR4 initiates a minimum of one refresh command internally once it enters Self-Refresh mode. Turn Around Timing tRDRD_sg Configure between module read to read delay. tRDRD_dg Configure between module read to read delay.
  • Page 64 Z390M-STX MXM / B360M-STX MXM tWRRD_dr Configure between module write to read delay. tWRRD_dd Configure between module write to read delay. tWRWR_sg Configure between module write to write delay. tWRWR_dg Configure between module write to write delay. tWRWR_dr Configure between module write to write delay.
  • Page 65 IOL Offset (CH B) Configure IO latency offset for channel B. RFR Delay (CH A) Configure RFR Delay for Channel A. RFR Delay (CH B) Configure RFR Delay for Channel B. ODT Setting ODT WR (A1) Configure the memory on die termination resistors' WR for channel A1. ODT WR (B1) Configure the memory on die termination resistors' WR for channel B1.
  • Page 66 Z390M-STX MXM / B360M-STX MXM DQ Driving Adjust DQ Driving for better signal. Default is 26. Command Driving Adjust Command Driving for better signal. Default is 20. Control Driving Adjust Control Driving for better signal. Default is 20. Clock Driving Adjust Clock Driving for better signal.
  • Page 67 Reset On Training Fail Reset system if the MRC training fails. MRC Fast Boot Enable Memory Fast Boot to skip DRAM memory training for booting faster. Voltage Configuration CPU Core/Cache Voltage Configure the voltage for the CPU Core/Cache. CPU Load-Line Calibration CPU Load-Line Calibration helps prevent CPU voltage droop when the system is under heavy load.

  • Page 68: Advanced Screen

    Z390M-STX MXM / B360M-STX MXM 4.6 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, ACPI Configuration, USB Configuration and Trusted Computing.. Setting wrong values in this section may cause the system to malfunction.

  • Page 69: Cpu Configuration

    4.6.1 CPU Configuration Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved. Active Processor Cores Select the number of cores to enable in each processor package. CPU C States Support Enable CPU C States Support for power saving.
  • Page 70 Z390M-STX MXM / B360M-STX MXM Hardware Prefetcher Automatically prefetch data and code for the processor. Enable for better performance. Adjacent Cache Line Prefetch Automatically prefetch the subsequent cache line while retrieving the currently requested cache line. Enable for better performance.

  • Page 71: Chipset Configuration

    4.6.2 Chipset Configuration Primary Graphics Adapter Select a primary VGA. Above 4G Decoding Enable or disable 64bit capable Devices to be decoded in Above 4G Address Space (only if the system supports 64 bit PCI decoding). VT-d Intel® Virtualization Technology for Directed I/O helps your virtual machine monitor better utilize hardware by improving application compatibility and reliability, and providing additional levels of manageability, security, isolation, and I/O performance.
  • Page 72 Z390M-STX MXM / B360M-STX MXM DMI ASPM Support This option enables/disables the control of ASPM on CPU side of the DMI Link. PCH DMI ASPM Support This option enables/disables the ASPM support for all PCH DMI devices. Share Memory Configure the size of memory that is allocated to the integrated graphics processor when the system boots up.
  • Page 73 Deep Sleep Configure deep sleep mode for power saving when the computer is shut down. Restore on AC/Power Loss Select the power state after a power failure. If [Power Off] is selected, the power will remain off when the power recovers. If [Power On] is selected, the system will start to boot up when the power recovers.

  • Page 74: Storage Configuration

    Z390M-STX MXM / B360M-STX MXM 4.6.3 Storage Configuration SATA Controller(s) Enable/disable the SATA controllers. SATA Controller Speed Indicates the maximum speed the SATA controller can support. SATA Mode Selection [AHCI] Supports new features that improve performance. [Intel RST Premium (RAID)] Combine multiple disk drives into a logical unit.

  • Page 75: Acpi Configuration

    4.6.4 ACPI Configuration Suspend to RAM Select disable for ACPI suspend type S1. It is recommended to select auto for ACPI S3 power saving. I219 LAN Power On Allow the system to be waked up by I219 LAN. RTC Alarm Power On Allow the system to be waked up by the real time clock alarm.

  • Page 76: Usb Configuration

    Z390M-STX MXM / B360M-STX MXM 4.6.5 USB Configuration XHCI Hand-off This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver.

  • Page 77: Trusted Computing

    4.6.6 Trusted Computing Security Device Support Enable or disable BIOS support for security device.

  • Page 78: Tools

    Z390M-STX MXM / B360M-STX MXM 4.7 Tools UEFI Tech Service Contact ASRock Tech Service if you are having trouble with your PC. Please setup network configuration before using UEFI Tech Service. SSD Secure Erase Tool Use this tool to securely erase SSD.
  • Page 79 Network Configuration Use this to configure internet connection settings for Internet Flash. Internet Setting Enable or disable sound effects in the setup utility. UEFI Download Server Select a server to download the UEFI firmware.

  • Page 80: Hardware Health Event Monitoring Screen

    Z390M-STX MXM / B360M-STX MXM 4.8 Hardware Health Event Monitoring Screen This section allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, fan speed and voltage. Fan-Tastic Tuning Select a fan mode for CPU Fans 1&2, or choose Customize to set 5 CPU...
  • Page 81 GPU Fan1 Setting Select a fan mode for GPU_FAN1, or choose Customize to set 5 GPU temperatures and assign a respective fan speed for each temperature. CPU Fan 2 Setting Select a fan mode for CPU Fan 2, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.

  • Page 82: Security Screen

    Z390M-STX MXM / B360M-STX MXM 4.9 Security Screen In this section you may set or change the supervisor/user password for the system. You may also clear the user password. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility.

  • Page 83: Boot Screen

    4.10 Boot Screen This section displays the available devices on your system for you to configure the boot settings and the boot priority. Fast Boot Fast Boot minimizes your computer's boot time. In fast mode you may not boot from an USB storage device. The VBIOS must support UEFI GOP if you are using an external graphics card.
  • Page 84 Z390M-STX MXM / B360M-STX MXM Boot Failure Guard Message If the computer fails to boot for a number of times the system automatically restores the default settings. CSM (Compatibility Support Module) Enable to launch the Compatibility Support Module. Please do not disable unless...

  • Page 85: Exit Screen

    4.11 Exit Screen Save Changes and Exit When you select this option the following message, “Save configuration changes and exit setup?” will pop out. Select [OK] to save changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option the following message, “Discard changes and exit setup?”...
