Clas Ohlson Pineapple Quick Start Manual

Solar Light
Art.no 36-7559, 36-7560 Model TN-7017, TN-7013
Please read the entire instruction manual before using the product
and then save it for future reference. We reserve the right for
any errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services.
Safety
• Handle the product with care, making sure not to damage
the surface of the solar cell and ensuring that it is not
covered with dust or affected by other contaminants.
• The product must not be changed or modified in any way.
• Do not let children play with the product.
Instructions for use
• When placing the light outdoors, make sure that it has
access to maximum sunlight and is not affected by other
light sources such as street lights.
• When the battery is fully charged, the light will shine for
approximately 6 hours at dusk/in the dark.
1. Set the power switch on the bottom of the solar cell to ON.
2. Place the light in a suitable outdoor location. Push the ground
stake into the ground and adjust the angle of the solar cell
so that it can receive as much sunlight as possible.
3. The light comes on automatically at dusk (as long as
the battery has been charged).
If the light does not shine
• Make sure that the power switch is set to the ON position.
• The battery is discharged. Make sure the solar cell is
exposed to sunlight.
• The surface of the solar cell is dirty. Carefully wipe the solar
cell clean using a damp cloth.
UNITED KINGDOM • customer service tel: 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston upon Thames, Surrey, KT1 1JZ
Care and maintenance
Clean the product using a damp cloth. Use only mild cleaning
agents, never solvents or corrosive chemicals.
The rechargeable battery connected to the solar cell may need
to be replaced:
1. Undo the two screws on the base of the solar cell
and remove the back cover. Be careful not to damage
the cables and the circuit board.
2. Replace the battery (see Specifications) making sure that it
is fitted with the correct polarity. The battery must only
be replaced with an equivalent rechargeable battery.
3. Screw the back cover back on.
Responsible disposal
This symbol indicates that this product
should not be disposed of with general
household waste. This applies throughout
the entire EU. In order to prevent any harm to
the environment or health hazards caused by
incorrect waste disposal, the product must
be handed in for recycling so that the material
can be disposed of in a responsible manner.
When recycling your product, take it to your
local collection facility or contact the place of
purchase. They will ensure that the product is
disposed of in an environmentally sound manner.
Specifications
36-7559 Pineapple
Rechargeable battery 1 × 1.2 V, AAA/HR03 300 mAh NiMH
Charging time Approximately 8 hours
(in continuous sunlight)
Operating time Approximately 6 hours
(when fully charged)
Operating temperature −10 to 50 °C
Height 65 cm
36-7560 Flamingo
1 × 1.2 V, AAA/HR03 300 mAh NiMH
Rechargeable battery
Charging time Approximately 8 hours
(in continuous sunlight)
Approximately 6 hours
Operating time
(when fully charged)
Operating temperature −10 to 50 °C
61 cm
Height
