Clas Ohlson SXY81040CP-WW-P060 Instruction Manual

Solar String Light
Art.no 36-6974 Model SXY81040CP-WW-P060
Please read the entire instruction manual before use and
then save it for future reference. We reserve the right for any
errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services.
Safety
Important
• Handle the product with care, making sure not to damage
the surface of the solar cell and ensuring that it is not
covered with dust or affected by other contaminants.
• Never attempt to repair or modify the product in any way.
• Repairs must only be carried out by authorised service
personnel and only using genuine spare parts.
• The battery must only be replaced with a rechargeable battery.
• Never let children play with the product.
Information
The string light can also be
powered by a battery pack
or a mains adaptor (both sold
separately) to enable them
to be used all year round.
Disconnect the solar cell and
replace it with either a battery
pack or mains adaptor.
Assembly
Information
• When placing the product outdoors, make sure that it has
access to maximum sunlight and is not affected by other
light sources such as street lights.
• When the battery is fully charged, the light will shine for
approximately 8 hours in the dark.
GREAT BRITAIN • customer service tel: 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk postal 10 – 13 Market Place, Kingston Upon Thames, Surrey, KT1 1JZ
Solar cell
Placed on a ground spike
1. Attach the ground spike 2. Adjust the angle of
to the solar cell and the solar cell so that it
then push the spike into can receive as much
the ground. sunlight as possible.
Fastened to a structure such as a wall
1. Remove the nuts/bolts on
the bracket on the back of
the solar cell.
2. Using the bracket as a guide,
mark out the position of
the mounting holes on the wall.
3. Use an appropriate type
of screw or fastener for
the material and mount
the bracket to the wall.
Important: Make sure that there are no electrical wires
or water pipes in the wall where you intend to drill/screw.
4. Screw the solar cell onto the bracket.
5. Adjust the angle of the solar cell so that it receives as much
sunlight as possible.
Lighting
Hang the string light in the desired location.
Instructions for use
1. Connect the lights and
the solar cell's plugs.
2. Set the switch on the back
of the solar cell to ON.
3. The lights will come on automatically at dusk.
Care and maintenance
• Clean the product using a slightly damp cloth. Use only mild
cleaning agents, never solvents or corrosive chemicals.
• Replacing the battery, when required:
1. Remove the 4 screws 2. Change the battery and
on the back of make sure that it is inserted
the solar cell. with the correct polarity.
Troubleshooting
What to do if the lights do not shine.
• Make sure the switch is in the ON position.
• The battery is discharged. Make sure the solar cell is
exposed to sunlight.
• The solar cell is dirty. Clean it by wiping with a damp cloth.
Responsible disposal
This symbol indicates that this product should not
be disposed of with general household waste.
This applies throughout the entire EU. In order
to prevent any harm to the environment or
health hazards caused by incorrect waste
disposal, the product must be handed in for
recycling so that the material can be disposed
of in a responsible manner. When recycling
the product, take it to your local collection facility or contact
the place of purchase. They will ensure that the product is
disposed of in an environmentally sound manner.

Specifications

1 × AA/HR06 NiMH 800 mAh
Rechargeable battery
Charging time 8 hours (in continuous sunlight)
Operating time 8 hours (when fully charged)
Operating temperature −10 to 50 ºC
4.2 m
Length
