Summary of Contents for Sterilight Aquasana SC200-A
- Page 1 Installation, Operation and Maintenance Owner’s Manual Aquasana, Inc. 6310 Midway Road Haltom City, TX 76117 CUSTOMER SERVICE Mon-Fri 8am-8pm CST 866-NO-BOTTLE 866-662-6885 520192-R_RevA...
- Page 2 WATER CONFIDENCE Each component of your Aquasana Powered by Sterilight system has been designed and developed through extensive research and development to be part of an overall system that operates safely and ef- get genuine ficiently over its entire lifetime.
- Page 3 Congratulations , you have just purchased the Aquasana Powered by Sterilight UV Disinfection system. By purchasing this device, you have taken the first step in ensuring the safety of your water supply by using a totally non- intrusive, physical disinfection method.
-
Page 4: Table Of Contents
Table of Contents: Parts / Schematic Breakdown Safety Instructions Water Chemistry Installing Your UV Disinfection System Disinfection Procedure Operating and Maintenance Instructions Operation Troubleshooting 10-11 Dose Flow Chart Specifications *CSA/UL certification with approved power cord and lamps only. Potential Safety Measures Hazard UV Exposure Never illuminate UV Lamp outside of the UV Chamber. - Page 5 Symbols: Protective Caution Ground Electrical Fragile Warning WEEE (waste electrical or Eye Protection electronic equipment)* * This symbol indicates that you should not discard wasted electrical or elec- tronic equipment (WEEE) in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center.
-
Page 6: Parts / Schematic Breakdown
System Components: Controller 214 fused quartz sleeves with fire polished ends POWER - 100-240V/50-60HZ QS-001 FOR SC200-A BA-ICE-C COBALT SYSTEM QS0-410 FOR SC410-A lamp connector gland nut RN-001 IEC replacement power cords for Cobalt (sold separately) 260010 NORTH AMERICAN (NEMA 5-15P), 3-PRONG GROUNDED o-ring 602637... -
Page 7: Safety Instructions
Safety Instructions: WARNING - Always shut-off water flow and release water pressure before servicing. WARNING - to guard against injury, basic safety precautions should be observed, including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS. CAUTION - Always disconnect power before servicing. DANGER - To avoid possible electric shock, special care should be taken since water is present near electrical equipment. -
Page 8: Water Chemistry
Water Chemistry: Water quality is extremely important for the optimum performance of your UV disinfection system. The following levels are recommended for installation: • Iron: < 0.3 ppm (0.3 mg/L) • Hardness*: < 7 gpg (120 mg/L) • Turbidity: < 1 NTU •... - Page 9 It must be noted that the system will require supplementary disinfection of the distribution system if any water is used during a by-pass condition. In addition, during by-pass, the water will NOT be disinfected and the attached “DO NOT CONSUME THE WATER” tag (included with the system), should be physically installed on the by-pass assembly until such time as the system is sanitized and returned to service.
- Page 10 Mount the remove ICE controller horizontally to the wall, near the reactor chamber. Ideally place the controller above the reactor and away from any water connection point, to prevent any water from potentially leaking onto the controller by means of a leak at a connection point or a “sweating”...
-
Page 11: Disinfection Procedure
Disinfection Procedure: UV disinfection is a physical process and does not add any potentially harmful chemicals to the water. As UV does not provide a disinfection residual, it is imperative that the entire distribution system located after the UV be chemically disinfected to ensure that the water is free from any bacteriological contaminants. -
Page 12: Operating And Maintenance Instructions
OPERATION • Always disconnect power before performing any work on the disinfection system. • Regularly inspect your disinfection system to ensure that the power indicators are on and no alarms are present. • Replace the UV lamp annually (or biennially if seasonal home use) to ensure maximum disinfection. - Page 13 Quartz Sleeve Replacement / Cleaning: Mineral deposits and sediment may accumulate on the quartz sleeve decreasing the UV energy required for adequate disinfection. Good maintenance of filtration equipment will reduce the accumulation of residues. If necessary, remove the quartz sleeve and clean with a commercially available scale remover (CLR, Lime-Away, etc.) and a lint free cloth.
-
Page 14: Operation
Operation: Controller: 1. Lamp life remaining (days): The controller tracks the number of days of operation of the lamp and the controller. The default screen will display the total lamp life remaining (in days). The controller will count down the number of days remaining until the lamp requires changing (365 days to 1 day). At “0”... -
Page 15: Troubleshooting
Troubleshooting: TROUBLESHOOTING GUIDE Symptom Possible Causes Solutions • replace filter cartridge with appropriate 5 micron cartridge Sediment filter clogged Pressure Drop Note: check source water supply as fluctuations may occur in source pressure • clean sleeve with scale cleaner and eliminate Quartz sleeve is stained source of staining problem (ie. -
Page 16: Dose Flow Chart
DISPLAY FAULT MODES LED display reads • lamp life expired - countdown is at “0” days “A3” • press reset button for a deferred alarm, replace UV lamp • controller is in lamp failure mode LED display is • power system down, allowing it to reset itself; apply power in order to blank confirm that the controller is able to power lamp •... -
Page 17: Specifications
Specifications: MODEL SC200-A SC410-A 56.8 lpm 111.2 lpm US Public Health (15 gpm) (29.4 gpm) 16mJ/cm (3.4 m /hr) (6.7 m /hr) 30.3 lpm 59.3 lpm VIQUA Standard (8 gpm) (15.7 gpm) 30 mJ/cm (1.8 m /hr) (3.6 m /hr) 22.7 lpm 44.5 lpm NSF/EPA... - Page 18 UV Filter Kit Installation Guide Rhino ® Whole House Water Filter Direction of flow The control module must be mounted higher than the UV system. Position control module to allow for a drip loop on the cord. Mount UV filter. Sub-micron Post-Filter Attach mounting...
Need help?
Do you have a question about the Aquasana SC200-A and is the answer not in the manual?
Questions and answers
Sterilight Model # SC00-A is leaking at the lamp connector
To fix a leak at the lamp connector on a Sterilight SC200-A, follow these steps:
1. Turn Off the System – Shut off the water supply and power to the system before making any adjustments.
2. Check the O-Ring – Inspect the O-ring at the lamp connector for damage or improper seating. Replace it if necessary.
3. Tighten the Gland Nut – Ensure the gland nut is securely tightened but not over-tightened, as this can damage the seals.
4. Verify Proper Installation – Ensure all components, including the quartz sleeve and lamp, are correctly aligned and seated.
5. Restart and Check for Leaks – Slowly turn the water supply back on and monitor for leaks.
If the leak persists, replacing the affected parts such as the O-ring or gland nut may be necessary.
This answer is automatically generated
