SeaSoft MobilGate - 128d Manual

MobilGate - 128d
MobilGate-128d
doors and barriers with 2 voltage-less contact type inputs and 4 low voltage low current relay
outputs. The 2 relay outputs allow the configuration of 128 phone numbers to control the gates
remotely with a free call based on caller ID recognition. The 2 relay outputs can be triggered by
SMS orders received from previously configured phone numbers. Relays operated with a free call
which can be maximum of 9999 seconds (about 3 hours). After the given time expires, the relays
turn off automatically and return to their original state.
1. Operation of MobilGate-128d
The GSM gate opener is equipped with a carrier-
independent industrial GSM module; thus it is ready for
an SMS communication with a prepaid or subscription
SIM card without PIN code. The data which is necessary
for operation, for instance SMS number of the service
provider, users' numbers, output and input names etc. can
be configured by downloading them into the device or
sending an SMS with a certain content. In the case there
is any change of the inputs, the module name, module
number, the appropriate input name and status are also
sent via SMS. The detailed messages provide possibility
to be able to easily identify the appropriate device in case
of having more than one. Input and output status with every parameter can be queried by sending a
corresponding SMS. Configuration SMSs are confirmed after reception, and and an correct
configuration SMS will result in an error message. The module does not discard the previously set
SeaSoft Ltd. www.seasoft.hu - www.mobil-control.eu
is an industrial GSM module developed for remotely controlling doors, garage
can be triggered for pre-determined duration, and the relays operated
with SMSs can be turned on and off permanently. The recognition of
maximum 128 phone numbers allows to set up entitlements for 128
users. The general inputs can be used arbitrarily for transmitting gate
error signals, burglary alarm center's signals or panic signals. Users
are informed about input changes via SMS with pre-configured
content. Certain electronic devices, such as heaters, air conditioners,
light devices etc. can be turned on and off with relay outputs
operated via SMSs, thus the function of gate opener can be
broadened with many supplements. Its power voltage is 10-30Vdc,
which can be supplied by a power adapter. Its setup can be
configured with our free downloader software via USB port, or by
sending several different configuration SMS remotely. Each input
and output can be labeled with a max. 16-character long name. The
configuration of the SMS relay output commands which trigger the
relays to be on or off also can be set. The module has a 4-character
passcode in order to prevent any unauthorized personnel to disable
or reconfigure the module. The module has internal timers, thus the
output relays are triggered for a configured time when calls occur,
Gate and barrier control GSM module with
2 inputs and 2 outputs for 128 phone numbers
