- Page 1 ACT AS3424S 24 x 10GE Layer 3 Switch Installation Guide Revision B...
- Page 2 AS3424S Hardware Installation Guide ACT AS3424S 10G Layer 3 Switch Hardware Installation Guide ACT Document Number: ACT AS3424S Hardware Installation Guide Installation Guide Revision B Copyright © 2018 Ascent Communication Technology Limited. All rights reserved. Reproduction in any manner whatsoever without the express written permission of Ascent Communication Technology is strictly forbidden.
- Page 3 Table of Contents 1 ASCENT AS3424S Introduction ....................4 1.1 Appearance Description for Standard Configuration ····················································· 4 1.2 ASCENT AS3424S Systematic Characteristic Parameters ··············································· 5 1.3 ROHS Description ··········································································································· 6 2 Chapter 2 Installation Preparation ..................7 2.1 Caution of Usage ············································································································ 7 2.2 Safety Advice ··················································································································...
- Page 4 The section describes the characteristics and parameters of ASCENT AS3424S and gives an overview of ASCENT AS3424S. The built-in ports of ASCENT AS3424S are: 24 10GE SFP+ ports, 2 40/100GE QSFP+ ports, 1 console port, 1 gigabit management port and 1 USB interface. See table 1-1.
- Page 5 AS3424S Hardware Installation Guide Figure 1-2 Back template of the ASCENT AS3424S switch Table 1-3 Parts at the back template of the ASCENT AS3424S switch Abbrev. Name Description Grounding column The grounding must be fine. PWR2 Power slot dual power backup, hot swap...
- Page 6 AS3424S Hardware Installation Guide Output current: 5A(MAX) ＜75W Full Power Consumption Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com Page 6 of 22...
- Page 7 Similar to other electronic products, the semiconductor chip easily gets damaged if you power on or off abruptly and frequently. To restart up the switch of ASCENT AS3424S, you have to open the power on-off after the power is cut down for three to five seconds.
- Page 8 AS3424S Hardware Installation Guide Put off ornaments, such as ring, necklace, watch and bracelet, before you operate under live working. When metal articles connect the power to the ground, short circuit happens and components may be damaged. Pull out the AC power socket and close the direct-current power before operating on the machine box or working beside the power source.
- Page 9 AS3424S Hardware Installation Guide The switch can be installed on the desk or the cabinet. The location of the machine box, cabinet planning and indoor cabling are very important for normal system’s function. Short distance between devices, bad ventilation and untouchable control plate will cause maintenance problems, systematic faulty and breakdown.
- Page 10 AS3424S Hardware Installation Guide The tools and devices to install the ASCENT AS3424S switch are not provided by the ASCENT AS3424S switch. You yourself need to prepare them. The following are the tools and devices needed for the typical installation of the ASCENT AS3424S switch: ...
- Page 11 Installing the machine box on the cabinet The ASCENT AS3424S switch can be directly put on the smooth and safe desk. Do not put things weighing 4.5 kg or over 4.5 kg on the top of the switch. Note Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com...
- Page 12 The detailed operations are shown in Figure 3-1. Figure 3-3 Fixing the machine box of the switch The switch shown in figure 3-1 does not represent the material ASCENT AS3424S. Warning After the brackets are installed, install the switch on the cabinet. See Figure 3-2.
- Page 13 Remark Output Input The cable is used to connect the console port of ASCENT AS3424S and the outside monitoring device. One end is RJ45 8-core plug, and the other end of the console cable is DB9. The RJ45 plug Note is put into the socket of the console port on the ASCENT AS3424S switch.
- Page 14 ASCENT AS3424S can adopt five types of direct-through/cross network cables when it connects other Ethernet terminals. Figure 3-6 Connecting the 1000Base-TX port and other Ethernet terminals The switch shown in figure 3-8 does not represent the material ASCENT AS3424S. Warning Table 3-1 Pins of Gigabit RJ45...
- Page 15 Sending/receiving the paraphase of the data 3 TP3- The ASCENT AS3424S switch has 24 10GE SFP+ ports. Each port has its corresponding indicator: 1 to 24. You can connect the SFP+ optical module to the SFP+ port and then you can connect other Ethernet terminal devices through the optical cable.
- Page 16 You can connect the QSFP+ optical module to the optical port and then you can connect other Ethernet terminal devices with 10GE optical ports through the MPO-4*LC optical cable. ASCENT AS3424S provides with 1 USB2.0 interface. Before electrically starting up the switch, perform the following checkups after the switch is installed: ...
- Page 17 4. Open the cover by holding two sides of the cover towards the direction of the arrow key shown in the following figure: The switch shown in the above figure does not represent the material ASCENT AS3424S. Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com...
- Page 18 AS3424S Hardware Installation Guide When the cover is opened, put it aside. The mainboard of the system appears. Warning After taking off the cover, put it horizontally and avoid it to be crushed or collided. Otherwise, the machine box is hard to install.
- Page 19 9600 bps, eight data bits, no sum check bit, one stop bit and no traffic control. The LED indicator shows that the switch is running. The following table shows the indicators of the ASCENT AS3424S switch and their description: Abbrev. Name...
- Page 20 AS3424S Hardware Installation Guide If the indicator flickers, there is data transmission. 1 to SFP+ port If the indicator is always on, the system is normally linked. 24(LINK/ACT) indicator If the indicator is off, the port is not linked. If the indicator flickers, there is data transmission.
- Page 21 AS3424S Hardware Installation Guide Figure 5-3 QSFP+ port indicator Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com Page 21 of 22...
- Page 22 Phone: +84 243 795 5917 WEB: www.ascentcomtec.com EMAIL: sales@ascentcomtec.com Specifications and product availability are subject to change without notice. Copyright © 2018 Ascent Communication Technology Limited. All rights reserved. Ver. ACT_AS3424S_10GE_Switch_Installation_Guide_V1b_Oct_2018 Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com Page 22 of 22...
