TE Connectivity 58075-1 Instruction Sheet

PROPER USE GUIDELINES
Cumulative Trauma Disorders can result from the prolonged use of manually powered hand tools. Hand tools are intended for occasional use
and low volume applications. A wide selection of powered application equipment for extended-use, production operations is available.
Figure 1

1. INTRODUCTION

These instructions deal with the safety, installation,
Operation and maintenance of the Pistol Grip
Pneumatic Handle Assembly 58075-1. See Figure 1.
Pistol Grip Pneumatic Handle Assembly 58075-1
accepts interchangeable terminating heads that
terminate wires in connectors. To ensure accurate
termination of wires, setup adjustments, and head
maintenance, refer to the instructions packaged with
the terminating head.
Dimensions in this instruction sheet are in metric
NOTE
units [with U.S. customary units in brackets].
Figures are for reference only and are not drawn to
i
scale.
Reasons for reissue of this instruction sheet are
provided in Section 9, REVISION SUMMARY.

2. SAFETY PRECAUTIONS AND COMPANY CONTACT

2.1. Safety

Safeguards are designed into this application
equipment to protect operators and maintenance
personnel from most hazards during equipment
operation. However, certain safety precautions must
be taken by the operator and repair personnel to avoid
© 2011 Tyco Electronics Corporation, a TE Connectivity Ltd. Company
All Rights Reserved
*Trademark
TE Connectivity, TE connectivity (logo), and TE (logo) are trademarks. Other logos, product and/or Company names may be trademarks of their respective owners.

Pistol Grip Pneumatic
Handle Assembly 58075-1
personal injury, as well as damage to the equipment.
For best results, application equipment must be
operated in a dry, dust-free environment. Do not
operate equipment in a gaseous or hazardous
environment.
Carefully observe the following safety precautions
before and during operation of the equipment:
2.2. Contact

CALL TOLL FREE 1-800-722-1111 (CONTINENTAL
UNITED STATES AND PUERTO RICO ONLY)
The Tooling Assistance Center offers a means of
providing technical assistance when required.
In addition, Field Service Specialists are available to
provide assistance in the adjustment or repair of the
application equipment when problems arise which
your maintenance personnel are unable to correct.
When calling the Tooling Assistance Center regarding
service to equipment, it is suggested that a person
familiar with the device be present with a copy of the
manual (and drawings) to receive instructions. Many
difficulties can be avoided in this manner.
When calling the Tooling Assistance Center, be ready
with the following information:
TOOLING ASSISTANCE CENTER 1-800-722-1111
PRODUCT INFORMATION 1-800-522-6752
•
ALWAYS wear appropriate ear protection.
•
ALWAYS wear approved eye protection when
operating powered equipment.
•
ALWAYS keep guard(s) in place during normal
operation.
•
ALWAYS disconnect the tool from its power
source when performing maintenance on the
equipment.
•
NEVER wear loose clothing or jewelry that may
catch in moving parts of the application equipment.
•
NEVER insert hands into installed application
equipment.
•
NEVER alter, modify, or misuse the application
equipment.
1. Customer name
2. Customer address
3. Person to contact (name, title, telephone number,
and extension)
4. Person calling
This controlled document is subject to change.
For latest revision and Regional Customer Service,
visit our website at www.te.com
