MONTERINGSBESKRIVNING
ASSEMBLY INSTRUCTION
NOMONO DUBBELSTATIV / DUO STAND
1
2
3
MONTERA FOT OCH STÄLLFOT PÅ
SAMTLIGA ELBEN MED MF6S M6X20
MOUNT FOOT AND ADJUSTABLE FOOT
ON COLUMN USING MF6S M6X20
MONTERA BENKOPPLINGEN MED MF6S
M8X16
MOUNT THE CONNECTION BETWEEN
THE COLUMNS USING MF6S M8X16
MONTERA SARGARNA MED MF6S 6X12
PLACERA TRAFON MELLA NSARGARNA
MOUNT THE FRAMES TO THE
COLUMNS USING MF6S M6X12
PLACE THE POWER SUPPLY BETWEEN
THE FRAMES
2017-11-01
M488-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the NOMONO DUO STAND and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Horreds NOMONO DUO STAND

Summary of Contents for Horreds NOMONO DUO STAND

  • Page 1 MONTERINGSBESKRIVNING ASSEMBLY INSTRUCTION NOMONO DUBBELSTATIV / DUO STAND M488-1 MONTERA FOT OCH STÄLLFOT PÅ SAMTLIGA ELBEN MED MF6S M6X20 MOUNT FOOT AND ADJUSTABLE FOOT ON COLUMN USING MF6S M6X20 MONTERA BENKOPPLINGEN MED MF6S M8X16 MOUNT THE CONNECTION BETWEEN THE COLUMNS USING MF6S M8X16 MONTERA SARGARNA MED MF6S 6X12 PLACERA TRAFON MELLA NSARGARNA MOUNT THE FRAMES TO THE...
  • Page 2 MONTERINGSBESKRIVNING ASSEMBLY INSTRUCTION NOMONO DUBBELSTATIV / DUO STAND M488-1 MONTERA FÖRSTÄRKNINGSSTAGEN MED MF6S M6X8. TRYCK PÅ TÄCKPROPPAR PÅ SKRUVSKALLARNA MOUNT THE SIDESUPPORTS USING MF6S M6X8. MOUNT END CAPS TO THE SCREW HEADS MONTERA BORDSSKIVORNA PÅ SARGAR OCH FÖRSTÄRKNINGSSTAG MED STRX 5,0X17 MOUNT THE TABLETOPS TO FRAMES AND SIDESUPPORTS USING STRX 5,0X17...
