Summary of Contents for Xada XA2200
- Page 1 XA2200 QUICK START GUIDE FCC ID:2AUII-XA2200 IC: 25460-XA2200...
- Page 2 Rev. Issue Date Revisions Effect Page Revised By 2019/10/30 Initial Issue Tomasz 2020/02/14 Add Step 9 –for CAP setting Page.7 Stanly Cheng and modified the description “country” code setting.
- Page 3 LAN cable though the right connector directly to your computer, then go to the http://192.168.100.1 page. Step 2- Login Locate the label on the bottom of your Xada device, type the KEY to log in to the product management interface.
-
Page 4: Step 3- Password Configuration
For future network management enter your secure password on every Xada unit. Step 4 – Enter Setup Wizard For your first Xada unit, select Create New Network, and go to Step 5. For additional Xada unit(s) select Join an Existing Network and skip to Step 6. - Page 5 Step 6 – Join an Existing Network (FOR ADDITIONAL XADA UNIT) For additional Xada unit(s) please enter the identical network and pass- word as your first Xada unit.
- Page 6 Step 7 – Network Connection Guide (FOR YOUR FIRST XADA UNIT) Yours main Xada unit must connnect the left connector to your internet gateway, and the right connect to our corporate LAN network. Step 8–Network Connection Guid (FOR ADDITIONAL XADA UNIT)
- Page 7 Step 9 –for CAP setting Step 1: Select “Setup Wizard” Setup 2: Click “Create New Network”. Step 3: Host Name: ⚫ The name of your device showing on Mesh Topology. Set Up Wi-Fi Network: ⚫ Assign the name (SSID) to your Wi-Fi interface. Assign the password to your Wi-Fi interface.
-
Page 8: Front View
Product Overview Front view: Top view: Description Description Power Input connector Reset button LAN RJ45 connector LED Light indicator LAN RJ45 connector... -
Page 9: Regulatory Statements
No Unauthorized Modifications: Do not make any changes or modifications to this product without the prior express written approval of Xada Technologies Ltd. Any changes or modifications made without express written approval could void the user’s authority to operate this product. - Page 10 No warranty of accuracy is given concerning the contents of the information contained in this publication. To the extent permitted by law no liability (including liability to any person by reason of negligence) will be accepted by Xada Technologies Ltd., its subsidiaries or employees for any direct or indirect loss or damage caused by omissions from or inaccuracies in this document.
- Page 11 Mechanical Specifications Dimension (L)135mm x (W)165mm x (H)46.5mm Color White ID drawing Wireless AP System Specifications PCBA Form Factor Wireless AP Main Board 100mm x 125mm x 1.6mm Chipset Main board: Qualcomm IPQ4019 +QCA8072 Wi-Fi Standard IEEE802.11a/b/g/n/ac Wi-Fi Bands 2.4GHz, 5 GHz MU-MIMO Qualcomm IoT Connectivity TxBF...
- Page 12 RBG LED x3 (Wi-Fi, States, WAN) m-PCIe x1 (PCIe, USB2.0) + Nano SIM ⚫ Internal I/O UART0 Debug console ⚫ ⎓ Power input Input supply for host I/O: Type-C 9V ℃ Operating Temperature 0~50 ℃ Storage Temperature 0~50 Environment Support Humidity...
- Page 13 © 2019 Xada Technologies Ltd. 1F., No. 2, Ln. 150, Sec. 5, Xinyi Rd., Xiny District, 110 Taipei City, Taiwan Phone: + 886-2-23451878 Web: https://xada.tech/...
