Technical Data - ASR Basis Exclusive Manual

ASR Audio Systems Friedrich Schaefer, D- 35 745 Herborn +49 (27 72) 42 905
7.0

Technical Data (

Signal-to-noise-ratio: (depends on settings)
with 5 mV MC input signal and 1 volt output:
with 0.5 mV MC input signal and 1 volt output:
Frequency response:
Distortion factor:
Input impedance:
Input capacity:
Gain :
Output impedance:
Dimensions & weights:
(width x depth x height)
ASR Basis Exclusive (main unit)
ASR Battery Power Supply:
Our address :
ASR Audio Systeme
Friedrich Schaefer
Hohe Straße 700, House 5A,
D 35 745 Herborn / Germany
Phone +49 ( 27 72 ) 42 905
Fax +49 ( 27 72 ) 40 488
E- Mail : ASR@ASRAudio.com
Internet : www.ASRAudio.com
High End Phono-Pre-Amplifier ASR Basis Exclusive version 2010
Effective date: July 2010 )
from 3 Hz to 200 kHz (+/- 3dB), RIAA Correction
better than (+/- 1dB) between 20 and 20 kHz
from 0,5V to 8VAC Output (100 Ohm load) at 1 kHz
< 0.01%, from 20Hz to 20 kHz < 0.05%
MC: adjustable between 5 and 10 K Ohms
MM: adjustable between 10 and 47 K Ohms
switch able between 100, 320 and 570 pF
adjustable between + 32 dB and +64 dB
less than 50 Ohm
43 x 37 x 10 cm, 10 kg (16,9' x 14,6' x 3,2', 22 lbs)
46 x 33 x 15 cm, 26 kg (18,4' x 13,0' x 5,9', 58 lbs)
Subject to change without notice.
© July 2010 Friedrich Schaefer, ASR Audio
> 77dB
> 68 dB
Page 17
