Specifications

Multiload 5 LFP
Charger Type
Input Voltage
Input Power 154 W
Output Voltage 12 V DC
Output Current 5 A
Minimum Start Voltage
1 V
Back Drain 4 mA
Current Fuse Rating 250 V AC, T3,15 A
Charge Control
Soft Start
Bulk 5 A up to 13,8 V
Constant voltage
Absorption until current drops to
0,75 A
Analyse
Completion 1,5 A to 14,5 V
Constant 14,5 V until
Maximization current drops to
0,75 A
Float
13,4 V - 13,8 V
Maintain
5-1 A
Efficiency
Thermal Protection
Cooling Fan
-20 °C to 50 °C, output power is reduced
Ambient Temperature
The 12V charger will automaticallyp rotection if the
Over Voltage Protection
Battery Range
Deep Cycle
10 – 50 Ah
Types of Batteries
Dimensions (L×W×H) 197 x 116 x 62 mm
Weight 1,05 kg
Multiload 7 LFP Multiload 10 LFP
8 stage automatic
220 – 240 V~, 50/60 Hz
215 W 307 W
12 V DC 12 V DC
7 A 10 A
1 V 1 V
4 mA 4 mA
250 V AC, T3,15 A 250 V AC, T3,15 A
25% of the rated set current up to 11 V
7 A up to 13,8 V 10 A up to 13,8 V
Constant voltage
Constant voltage until
until current drops to
current drops to 1,5 A
1,05 A
Monitors voltage for 3 minutes
2,1 A to 14,5 V 3 A to 14,5 V
Constant 14,5 V until
Constant 14,5 V until
current drops to
current drops to 1,5 A
1,05 A
13.6V, 100% Current
13,4 V - 13,8 V 13,4 V - 13,8 V
7-1,4 A 10-2 A
Approx. 85 %
65 °C +/- 5 °C
Automatic temperature controlled
automatically at high temperatures
voltage is higher than 15.5 V
14 – 70 Ah 20 – 100 Ah
12 V LiFePO4-Batteries
197 x 116 x 62 mm 197 x 116 x 62 mm
1,05 kg 1,1 kg
42
Specifications
Multiload 12 LFP
Charger Type
Input Voltage
Input Power 332 W
Output Voltage 12 V DC
Output Current 12 A
Minimum Start Voltage
1 V
Back Drain 4 mA
Current Fuse Rating 250 V AC, T3,15 A
Charge Control
Soft Start
25% of the rated set current up to 11 V
Bulk 12 A up to 13,8 V
Constant voltage until
Absorption
current drops to 1,8 A
Analyse
Completion 3,6 A to 14,5 V
Constant 14,5 V until
Maximization
current drops to 1,8 A
Float
13,4 V - 13,8 V
Maintain
12-2,4 A
Efficiency
Thermal Protection
Cooling Fan
-20 °C to 50 °C, output power is reduced
Ambient Temperature
The 12V charger will automaticallyp rotection if the
Over Voltage Protection
Battery Range
Deep Cycle
24 – 120 Ah
Types of Batteries
Dimensions (L×W×H) 197 x 116 x 62 mm
Weight 1,1 kg
Multiload 15 LFP Multiload 20 LFP
8 stage automatic
220 – 240 V~, 50/60 Hz
415 W 554 W
12 V DC 12 V DC
15 A 20 A
1 V 1 V
4 mA 4 mA
250 V AC, T3,15 A 250 V AC, T3,15 A
15 A up to 13,8 V 20 A up to 13,8 V
Constant voltage
Constant voltage until
until current drops to
current drops to 3 A
2,25 A
Monitors voltage for 3 minutes
4,5 A to 14,5 V 6 A to 14,5 V
Constant 14,5 V until
Constant 14,5 V until
current drops to
current drops to 3 A
2,25 A
13.6V, 100% Current
13,4 V - 13,8 V 13,4 V - 13,8 V
15-3 A 20-4 A
Approx. 85 %
65 °C +/- 5 °C
Automatic temperature controlled
automatically at high temperatures
voltage is higher than 15.5 V
30 – 150 Ah 40 – 200 Ah
12 V LiFePO4-Batteries
217 x 116 x 62 mm 217 x 116 x 62 mm
1,28 kg 1,28 kg
