INTERFACE FEATURES
• 31 Band graphic EQ
• 6 Inputs, 10 individually assignable outputs
• Independent equalization on each of the 10 outputs
• Independent high pass, low pass, and bandpass filters
• Each channel can be delayed independently up to 10ms
• Chime control for GM/Chrysler vehicles
• Clipping detection and limiting circuits
• Bass knob included
AxxessInterfaces.com
Axxess 10-Channel Digital Signal Processor
• Retains OE voice prompts (SYNC® and OnStar®)
• Retains factory chimes including parking sensor and cross path
detection alerts
• Settings adjusted via Bluetooth® in a smart device application (tablet
or mobile phone), compatible with both Android and Apple devices
• Read, write, and store configurations for future recall
• Password protect feature available in the mobile app
• Micro-B USB updatable
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
AXDSP-X
I N S T A L L A T I O N I N S T R U C T I O N S
TABLE OF CONTENTS
Preface ....................................................................2
Installation Options ...............................................2
Installation .............................................................3
Connections ........................................................ 4-7
AXDSP-X app ..................................................... 8-17
Pinout ....................................................................18
Specifications ....................................................... 19
INTERFACE COMPONENTS
• AXDSP-X interface
• AXDSP-X harness (16-pin & 20-pin)
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties • Multimeter
Apple App Store
Google Play Store
iOS 12.1 or higher
REV. 1/30/2020 INSTAXDSP-X
Advertisement
Related Manuals for Axxess AXDSP-X
Summary of Contents for Axxess AXDSP-X
-
Page 1: Table Of Contents
AXDSP-X app ............. 8-17 Pinout ..............18 Specifications ............19 INTERFACE COMPONENTS • AXDSP-X interface • AXDSP-X harness (16-pin & 20-pin) TOOLS & INSTALLATION ACCESSORIES REQUIRED • Crimping tool and connectors, or solder gun, INTERFACE FEATURES solder, and heat shrink • Tape • Wire cutter • 31 Band graphic EQ •... -
Page 2: Preface
Use Metra part number E-123 (sold separately) for best results. Adding a subwoofer to an existing radio: The AXDSP-X can also grow as your stereo system grows. Start off by adding a subwoofer, then This feature offers the Installer the ability to add an aftermarket subwoofer to an existing add on from there. -
Page 3: Installation
2. Plug the 20-pin AXDSP-X harness into the AXDSP-X. 3. Plug the 16-pin AXDSP-X harness into the AXDSP-X. 4. Download and install the AXDSP-X app from the Google Play Store or Apple App Store. 5. Using the app, select the vehicle. 6. Connect the amp turn-on wire from the AXDSP-X. - Page 4 Orange - Control Wire Optional Black - Chassis Ground Yellow - Battery Power Red - Accessory Power AXDSP-X (included) Assignable Outputs Labeled CH 6-10 An SPDT relay, Metra part number Any remaining wires E-123, must be used if more than...
- Page 5 Factory Radio Orange - Control Wire Wire information on page 17 (RCA Jacks shown cut off) These outputs can be used for AXDSP-X (included) additional sub amps, or for adding onto the system at a later date RCA Jacks (sold separately) Blue/White - Amp Turn-On Wire REV.
- Page 6 Factory Radio Wire information on page 17 Orange - Control Wire Assignable Inputs Labeled CH 6-10 (RCA Jacks shown cut off) AXDSP-X (included) An SPDT relay, Metra part number E-123, must be used if more than one amplifier will be installed...
-
Page 7: Axdsp-X App
AXDSP-X APP Setup Instructions • General information tab for installing the AXDSP-X. Continued on the next page REV. 1/30/2020 INSTAXDSP-X... - Page 8 Bluetooth Connection • Scan - Press this button to start the Bluetooth pairing process, then select the AXDSP-X from the mobile device. The AXDSP-X must be powered during this process. Confirmation that you are connected will show in the top left corner of the app.
- Page 9 AXDSP-X APP (CONT.) Configuration • Identify - Click this button to confirm that the AXDSP-X is connected properly. If so, a chime will be heard from the front left speaker. • Reset to Defaults - Resets the AXDSP-X to factory settings. During the reset process the amplifiers will shut off for 5-10 seconds.
- Page 10 • About - Displays information about the app, vehicle, AXDSP-X, and mobile device. • Set Password - Assign a 4-digit password to lock the AXDSP-X. If no password is desired, use “0000”. This will clear out any currently set password. It is not necessary to lock down the AXDSP-X when setting a password.
- Page 11 • Group - Used to join channels together. Example, left front woofer/ midrange and left front tweeter will be considered simply left front to the AXDSP-X. The letter M denotes the speaker assigned as the master speaker. • Invert - Will invert the phase of the speaker.
- Page 12 AXDSP-X APP (CONT.) Crossover Adjust • If installing a subwoofer, the front and rear outputs will default to a 100Hz high pass filter to keep the low frequency signals out of the full range speakers. If a subwoofer is not being installed, change the front and rear crossover points down to 20Hz for a full range signal, or to the lowest frequency the speakers will play to.
- Page 13 AXDSP-X APP (CONT.) Equalizer Adjust • All channels can be adjusted independently within this tab with 31 bands of available equalization. It is best to tune this by using an RTA (Real Time Analyzer). • The Gain slider on the far left is for the channel selected.
- Page 14 AXDSP-X APP (CONT.) Delay Adjust • Allows a delay of each channel, up to 10 milliseconds. First measure the distance (in inches) from each speaker to the listening position, then enter those values. If a delay is desired, add to the desired channel(s), up to 99 inches.
- Page 15 • Clipping Level - Use this feature to protect sensitive speakers like tweeters from being driven past their capabilities. If the output signal of the AXDSP-X clips the audio will be reduced by 20dB. Turning down the stereo will allow the audio to come back at a normal level.
- Page 16 AXDSP-X APP (CONT.) Locking Down Data Last and the most important. You must lock down your configuration!!!
-
Page 17: Pinout
PINOUT Input Connector Output Connector CH9 CH10 CH9 CH10 Input 6 - Subwoofer Right Input Black - Chassis Ground Input 5 - Subwoofer Left Input Pink - CAN-HI Blue/White - Amp Turn-On Purple RCA Jack - User Assignable Output Purple RCA Jack - Rear Right Input * Blue/Pink - CAN-LO Red/White - Future Use Green RCA Jack - User Assignable Output Green RCA Jack - Rear Left Input * Brown - Future Use... -
Page 18: Specifications
SPECIFICATIONS Specifications General Input Impedance 1M Ohm Operating Voltage 10 - 16VDC Input Channels 6 High/Low level Selectable Standby Current Draw ~7mA Input Options High Level or Low Level Operation Current Draw ~150mA Input Type Differential-Balanced Adjustments/Controls Application via Bluetooth Input Voltage 12VDC, Signal Sense 0 - 28v Peak to Peak... - Page 19 REV. 1/30/2020 INSTAXDSP-X...
- Page 20 AXDSP-X I N S T A L L A T I O N I N S T R U C T I O N S Having difficulties? We’re here to help. Contact our Tech Support line at: 1-800-253-TECH Or via email at: techsupport@metra-autosound.com...
