HS-3030 Operator’s Manual Contents 1.0 Unit Operation ............................1 1.1 Power Up Sequence ........................1 1.2 Types of Inputs ..........................1 1.3 Status Display ..........................2 1.4 Zone LEDs ............................2 1.5 Buzzer............................. 2 1.6 Operator Keys..........................3 1.7 Alarm List ............................6 1.8 LCD and Keypad..........................
HS-3030 Operator’s Manual 1.0 Unit Operation The operation of the HS1 and HS2 programs are almost identical. This chapter applies to both programs. Those functions that are different are noted. 1.1 Power Up Sequence The power up sequence of the panel is started in the following ways: power is applied to the panel;...
HS-3030 Operator’s Manual • Non-Reporting: These are non-latching inputs. They are also referred to as Non-Fire. There is no requirement that these inputs cause any action whatsoever. They use the supervisory LED for annunciation. They can operate only relays and control modules. The LEDs, relays and control modules will follow the non-reporting input's status.
HS-3030 Operator’s Manual • Medium: This indicates any new supervisory conditions. The pattern is 200ms on/off. • Slow: This indicates any new trouble conditions. The pattern in 500ms on/off. 1.6 Operator Keys These are located below the Status Display. They are not visible through the front door. There are...
Page 8
HS-3030 Operator’s Manual Action System System Reset resets part or all of the system. Reset • The green LED flashes when the system, or part of the system, can be reset. • The yellow LED flashes when there are conventional smoke detector circuits in alarm.
Page 9
HS-3030 Operator’s Manual Action Test Mode Places panel into test mode. Press again to return to normal mode. The yellow LED will flash while in test mode. This function can be set to Privilege Level 0 or 1. It follows the Disconnect privilege level (set in MHI). During test mode, the remote annunciator zone LEDs becomes non-latching for the zone(s) under test.
HS-3030 Operator’s Manual Action Manual This will cause the programmed control modules to reset after the system has been Restart reset in general. This is an MEA (New York City) requirement. Releaser Disconnect, Relay Disconnect, Signal Disconnect, Common Disconnect, and Test Mode can be made to time out automatically after 4 hours.
HS-3030 Operator’s Manual Line 2: date and Zone Number Line 4: description of event (alarm, trouble, ground, restore, etc.) or 2) Line 1: time, sequence number, and Condition Code Line 2: date and Zone Number Line 3: description of event...
Page 12
HS-3030 Operator’s Manual The display shows the device address in the top left corner and the current condition codes in the top right corner (see section 2.2 for a description of the condition codes). The second line shows the headings for the third line, which contains the analog values sent from the device.
Page 13
HS-3030 Operator’s Manual The screen of a single screen event shows: Line 1: time, sequence number, and date Line 2: Condition Code and Zone Number (see section 2.1) Line 4: description of event (alarm, trouble, ground, restore, etc.) The first screen of a two screen event shows: Line 1: time, sequence number, and date Line 2: Condition Code and Zone Number (see section 2.1)
HS-3030 Operator’s Manual 1.9 Silent Walk Test The Silent Walk Test allows for single person testing of the system. This is done by providing an audio output that can be used by a radio with a microphone input. The system will produce tones through the audio output jack to give the inspector a positive indication of system behaviour.
HS-3030 Operator’s Manual 2.0 Supplementary Information 2.1 Diagnostic LEDs There are 6 LEDs in the middle of the right edge of the Inner Door Assembly for diagnostic purposes. They are used as follows: 1. extended memory in use 2. addressable database in use 3.
Page 16
HS-3030 Operator’s Manual Zone Number PPP:ZZ.SSS Format: Control Panel Number Panel Zone Panel Panel Description Description Zone Zone General Alarm Comlink 3 Initiating Circuit 1 Comlink 6 Initiating Circuit 2 Printer Port Initiating Circuit 3 Addressable Modules Comlink Initiating Circuit 4...
Switch (Zone 83): Switch Number Hot Key Activation (Zone 90): Function Number of the Hot key pressed Memory Overflow (Zone 91): 000 - HS-3030 panel 001 - CoProcessor for circuits 1..8 002 - CoProcessor for circuits 9..16 003 - CoProcessor for circuits 17..24...
Page 18
CoProcessor that is off-line. Devices are not being monitored by the system. If a reboot of the HS-3030 does not fix the problem, the addressable input module for those circuits will need to be replaced.
Page 19
HS-3030 Operator’s Manual Message Description List the status of the 8 bell circuits and the 2 auxiliary power circuits. BBBBBBBBAA Each column represents one circuit. A dot (.) indicates a normal 1234567812 condition, an S indicates a short, an O indicates an open and a G ..
Page 20
HS-3030 Operator’s Manual Message Description This is indicative of a network communications fault. Network Reboot negative counters Required will automatically be generated by the unit. The time has not been set since the panel has been Rebooted. The time time not set displayed on the clock may be wrong.
Page 21
HS-3030 Operator’s Manual Message Description One or more of the addressable input circuit modules have been coprocessor class changed from either Class A or B to the other. Reboot the panel to clear changed this trouble. The operating program requires more extend RAM then the panel not enough ram actually has.
Page 24
HARRINGTON SIGNAL INC. FIRE ALARM Harrington Signal Inc. 2519 4th Avenue Moline, IL 61265...
