- Page 1 21 Redfisher Owner’s Manual Revised June 2020 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Hewesboats.com (772)-465-0631...
- Page 2 Forum, where you can ask questions, get nswers and join other Hewes owners to discuss all applications of your boat. We’re proud to have you as a member of the Hewes family! Tight lines and screaming drags! Scott Deal President and CEO Maverick Boat Group 3207 Industrial 29th St.
-
Page 3: Table Of Contents
Table of Contents 21 Redfisher Specifications ..................... 4 Pre-Operation Checklist ......................5 Maintenance & Cleaning ....................... 6 Engine Break-In Period ......................7 Switch Panel ..........................8 Fuel-Water Separator & Drain ....................9 Bilge ............................10 Systems ............................11 Trolling Motor Wiring .......................12 Battery Switch and Breaker Panel ..................14... -
Page 4: Redfisher Specifications
21 Redfisher Specifications L.O.A........................21’ 06” BEAM..............………………….…....8’ 06” DRAFT..........................14” WEIGHT W/ ENGINE..................2,850 LBS. FUEL CAPACITY....................50 GAL. DEADRISE @ TRANSOM..................15 DEG. MAXIMUM H.P......................350 MAX CAPACITIES…………………………………..…...…….…6 PERSONS OR 1,200 LBS. Fuel Fill Livewell Console Rod Rack Rigging Box Forward Storage / Anchor Hanger (optional) -
Page 5: Pre-Operation Checklist
Pre-Operation Checklist We recommend you print this document and store it at the helm station. Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Hewes.com (772)-465-0631... -
Page 6: Maintenance & Cleaning
Maintenance Hewes advises owners that maintenance and repairs should be performed at an authorized Hewes Dealer. The following information is general in nature and should not be considered a repair manual or guidelines set forth by Maverick Boat Group. Cleaning Each Hewes boat is constructed using the finest materials and components available. -
Page 7: Engine Break-In Period
DO NOT operate the boat if the engine stop switch system does not function properly. Go to a Hewes Dealer to have this resolved immediately. The lanyard should be securely attached to the boat operator at all times that the engine is on. -
Page 8: Switch Panel
Yamaha Command Link Gauges your Yamaha engine owner’s manual located in the Hewes Duffel Bag. Hewes Duffel Bag Along with your boat, you received a Duffel Bag with your new Hewes. Inside the Duffel Bag are the following items: o Large Livewell Standpipe o Short Livewell Standpipe o 1.5”... -
Page 9: Fuel-Water Separator & Drain
Fuel-Water Separator & Drain Fuel-Water Separator Each Hewes is equipped with a fuel water separator to ensure maximum performance and protect the outboard engine from contaminated gasoline. The fuel separator is a metal, cylindrical unit secured to the forward section of your starboard aft rigging box. -
Page 10: Bilge
If the bilge pump is working and pumping water, but the water level in the bilge does not go down, you likely have a leak which requires immediate attention. Remove your boat from the water and see your local Hewes dealer to have the bilge area inspected for possible leaks. -
Page 11: Systems
Use bilge cleaner products to remove any obvious stains. Consult your authorized Hewes dealer for recommended types of bilge cleaners. Systems Ball Valves Ball valves can be used to serve several purposes. They allow seawater to enter the boat, in the case of livewells, and they also act as a safeguard to stop water from entering. -
Page 12: Trolling Motor Wiring
Trolling Motor Wiring Trolling Motor/Wiring System Your Hewes 21 Redfisher comes standard with a 36V trolling motor wiring system. A trolling motor mounting plate was built into the bow of your Hewes during the manufacturing process. To attach a trolling motor, please go to your nearest Hewes dealer. - Page 13 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Hewesboats.com (772)-465-0631...
-
Page 14: Battery Switch And Breaker Panel
Battery Switch and Breaker Panel Battery Switch and Breaker Panel The battery switch panel comes as standard equipment on the 21 Redfisher. Power from the battery to the battery switch is protected with a 30-amp inline fuse. On a single battery system, the battery is wired to the number 1 side of the switch. A dealer installed option would be a Dual Battery Setup. -
Page 15: Props & Trim Tabs
Props & Trim Tabs Props Prop selection on your Redfisher is determined by your local Hewes dealer but based on recommendations made by Maverick Boat Group and Yamaha Marine to give your boat the maximum overall performance. Different prop designs may improve performance or can be tailored to enhance specifics of boat and motor performance. - Page 16 Pushing the bottom of the switch (Up) will raise the tabs and lift the bow out of the water for better running performance. To achieve the best running performance with your Hewes, use the engine trim in conjunction with your trim tabs to find the perfect amount of lift and a safe, comfortable ride.
-
Page 17: Fuel System
Self-Bailing Cockpit & Livewell Self-Bailing Cockpit The cockpit on the 21 Redfisher is designed to be self-bailing, meaning that all the water that comes into the cockpit will be directly drained overboard. This keeps the boat from acquiring standing water and allows the boat to drain at all times, including while the boat is docked. - Page 18 Hewes dealer immediately. Livewell System The new and improved livewell system on the 21 Redfisher keeps bait alive longer than any other system on the market. It has a dual inflow system and a unique drain system that prevents dead zones and quickly expels any harmful chemicals (such as ammonia) from the water.
-
Page 19: Wiring
Wiring A wiring diagram of your Hewes has been included to help troubleshoot any electrical problems or to add additional electronics or electrical connections. We recommend you use a trained marine electrician for all electrical issues. - Page 20 Hewes Main Harness To Console Pin # Function Wire Color Nav Lts (Instrumentation) Grey Nav Lts Grey Anc Lt (Console) Grey/White Anc Lt (T‐TOP) Grey/White Pin C T‐Top Recept Horn Orange/White Spreader Lt Blue/Black Pin A T‐Top Recept Overhead Lts Blue/Green Pin B T‐Top Recept...
-
Page 21: Optional Features
Optional Features Power Poles Power Poles come as an option with the Hewes Redfisher and give the boat operator the ability to quickly and quietly stop the boat while in shallow water. Whether you want to enjoy a view, or you’ve stumbled upon a group of tailing redfish, the power pole will stop the boat quickly and easily. -
Page 22: Redfisher Wire Diagram
21 Redfisher Wire Diagram Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Hewes.com (772)-465-0631... -
Page 23: Redfisher Water System
21 Redfisher Water System Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Hewes.com (772)-465-0631... -
Page 24: Redfisher Fuel System
21 Redfisher Fuel System Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Hewes.com (772)-465-0631... -
Page 25: Upholstery Care & Cleaning Guide
Upholstery Care & Cleaning Guide Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Hewes.com (772)-465-0631... -
Page 26: Warranty
Your relationship with your local Hewes dealer should never end with the delivery of your new boat. Your local Hewes dealership is where you will take your boat for service and repair, as well as to address any warranty issues. Hewes is fortunate to have an outstanding dealer network selling and servicing our boats.
