- Page 1 EROAD Ehubo® Installation Guide...
- Page 3 3. Install the Ehubo by connecting it to the vehicle. 4. Complete the installation by following the Ehubo’s on-screen guide. Refer to “Replacement Installation” on page 10 if you are installing a replacement Ehubo © 2015 EROAD. Doc 100200AD1.7. 12/2015.
-
Page 4: Important Safety Information
Ehubo vary from each country and state. Please familiarize yourself with the laws of the jurisdiction(s) in which the vehicle will be operated in prior to installing and using the Ehubo. Driving laws place the responsibility on the driver to correctly install and use GPS driver aids. It is therefore the Customer’s sole responsibility to install and use the Ehubo in a manner that complies... - Page 5 • Avoid fitting the Ehubo in a location that could cause injury to a driver or passenger in a crash. This includes potential head strike zones on the windshield or dashboard, or other locations where a deploying airbag may contact the Ehubo.
-
Page 6: Inside The Box
Inside the box Open your Ehubo box and check that everything is inside. EROAD Ehubo® Installation Guide EROAD EROAD Ehubo Ehubo mount (pre-fitted wiring loom) This installation guide Fuse kit Mounting High–strength adhesive tape (permanent/switched power) Alcohol wipe plate (optional, for tape mount) 2 x ¾”/ 19mm screws + washers... - Page 7 Choose a location that does not expose the Ehubo to excessive temperature or vibration.
- Page 8 The Ehubo needs a permanent power source and a good view of the sky to operate optimally. While the vehicle is off, the Ehubo will shut down to a low power mode and will draw a very small current from the vehicle supply. Remove the Ehubo permanent power fuse if the vehicle is in storage or parked up for more than a month to avoid discharging the vehicle battery.
- Page 9 NOTE: If the screen remains black or if you cannot successfully complete the instructions on the screen, the wiring of the Ehubo may not be quite right. Please refer to the Wiring Diagrams in this Installation Guide or to the Troubleshooting section and adjust your wiring.
-
Page 10: Wiring Diagram - Standard
Wiring Diagram – Standard Note: Ensure wiring is neatly routed to under the dash EROAD Dashboard Fuses must be fitted at connection point. This is to protect the wire in case of a short Cut wire loop and connect fuse inline... - Page 11 • Below is the connection diagram showing the additional input connections. Example inputs include things such as PTO, lights, generator etc. Note: Ensure wiring is neatly routed to under the dash EROAD Dashboard Permanent Power (12V or 24V) YELLOW Switched Power (Engine on/o ) BLACK...
-
Page 12: Replacement Installation
Replacement installation To replace an existing Ehubo, NOTE: Turn off the engine - disconnect the power cable from the existing Ehubo and prior to replacing the Ehubo - connect it to the replacement Ehubo. Follow these simple steps: Remove the... - Page 13 Pull the sticker and screen protection film off the Ehubo screen. To complete the installation, follow the instructions on the screen. At the end of the process the Ehubo Home screen will appear, and the installation is complete. Please place the uninstalled Ehubo in the replacement...
-
Page 14: Troubleshooting
Troubleshooting This section will provide some solutions if the installation of your Ehubo is unsuccessful or the Ehubo doesn’t perform as expected. SCENARIO SYMPTOM SOLUTION Permanent Power • Ehubo screen remains off • Check that Permanent Power is not connected has been properly connected to •... - Page 15 GOOGLE PROTOCOL BUFFER SOFTWARE LICENSE THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY EXPRESS OR IMPLIED Copyright 2008, Google Inc. WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A All rights reserved.
- Page 16 INNOVATION AND INTEGRITY EROAD.COM...
