  • Page 1 MCP100 Installation Guide 80-J4866-2 Rev. G October 2015...
  • Page 2 Omnitracs endeavors to ensure that the information in this document is correct and fairly stated, but Omnitracs is not liable for any errors or omissions. Published information may not be up to date, and it is important to confirm current status with Omnitracs.

  • Page 3: Table Of Contents

    Media Display Unit (MDU) ................2-4 Display Cable .....................2-4 Using the MDU ...................2-4 Mobile Application Server (MAS) ..............2-5 Accessory Cables for the MCP100—Standard and Full Function ....2-6 Speaker Switch Cable ................2-6 Power Cable ....................2-6 Backup Battery ....................2-6 Remote Control Device (RCD) .................2-7 Optional Accessories for the MCP100 ..............2-7...
  • Page 4 Installation Guidelines ..................4-2 Safety, Reliability, and Accessibility ............4-2 Typical Installation Sequence ................4-2 Typical Installation Locations for the Terrestrial MCP100 ........ 4-3 Typical Installation Locations for the Satellite MCP100 ........4-4 Conventional Vehicle Types ..............4-4 Straight Truck Vehicle Types (All Makes) ..........4-7 Cabover Engine Vehicle Types (All Makes) ..........
  • Page 5 TDM Cable Installation ................6-3 Connecting the TDM Cable to the MAS ............6-3 Chapter 7 Terrestrial Antenna Installation General Installation Guidelines .................7-2 Option A—Antenna Installation Using VHB Tape ..........7-2 Antenna Surface Preparation ..............7-2 Option B—Mount Method Installation Using Hardware ........7-3 Mount Surface Preparation ................7-3 Routing the Terrestrial Antenna Cable .............7-4 Connecting the Antenna Cable to the TDM ............7-4 Chapter 8 Satellite Data Modem (SDM) Installation...
  • Page 6 Verifying Data Source Connectivity .............. 11-14 Chapter 12 System Verification What Is Basic MCP100 System Verification? ..........12-2 Performing System Verification ............... 12-2 How to Find the MCP100 Unit Address (UA) ........... 12-2 MCP100 System Screens ................12-3 System Screen ..................12-3 OVT/CDMA Screens................12-5 SDM Screens ..................
  • Page 7 Chapter 13 Performance Monitoring Verification Performance Monitoring System Overview ............13-2 Performance Monitoring System Verification ..........13-2 Conducting a Road Test ................13-2 Performance Monitoring System Display Screens .........13-4 Summary Screen ..................13-4 Performance Screen .................13-5 Violations Screen ..................13-6 Parameters Screen ...................13-7 Odometer Screen ..................13-8 PTO Screen....................13-9 Installer Screen ..................13-10 Special Alert Display Notifications ..............13-13...
  • Page 8 Chapter 17 Compact Display Unit (CDU) Installation CDU Overview ....................17-2 General Installation Guidelines for Selecting a Mounting Location ....17-2 IMPORTANT SAFETY INFORMATION ..........17-2 Installing the CDU Mount ................17-3 Attaching the CDU to the Mounting Bracket ..........17-4 Connecting the CDU Cable to the Accessory Cable ........
  • Page 9 Sending a Scan ....................24-4 Cleaning the Scanner ..................24-5 Return Material Authorization (RMA) Process ..........24-5 Appendix A Wiring Diagrams and Charts Satellite MCP100 Electrical Diagram ............... A-2 Terrestrial MCP100 Electrical Diagram ............A-3 MCP100 Wiring Diagram ................. A-4 Power Cable Pin Callouts ................A-5 Terrestrial Data Modem (TDM) Cable 25-Pin Connector Callouts ....
  • Page 10 Appendix F Component and Document Information DCNs for Documents Referenced in this Guide ..........F-2 MCP100 System Component MCNs Referenced in this Guide ....... F-2 MCNs for Sealants and Lubricants Referenced in this Guide ......F-6 MCN for Omnitracs-recommended Torque Wrench Referenced in this Guide F-6 BCS Solutions Scanner Parts List ..............
  • Page 11 Appendix G Feedback Form Feedback Form ....................G-1 Company Information ................G-1 Documentation Content ................G-2 Documentation Format ................G-3 Glossary 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 12 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 13: Important Safety Information

    If you are a Third-party Device Manufacturer or Application Developer, it is your responsibility to provide appropriate warnings regarding the safe use of your device(s) in conjunction with Omnitracs equipment. Applications should not require the driver to divert his attention from the road while driving a vehicle.
  • Page 14 Safety Advice Important Safety Information 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 15: Chapter 1 How The Mcp100 Works

    • In Canada, call 800-863-9191 Note This guide combines satellite and terrestrial MCP100 information and installation procedures. Most of the information is applicable to both versions of the MCP100. Where appropriate, indicates satellite only indicates terrestrial only 80-J4866-2 Rev. G...

  • Page 16: Mcp100 Overview

    • Provides dispatchers with vehicle location and position history information by tracking the location of each MCP100 using latitude and longitude or distance and direction from landmarks (usually large towns and cities). • Drivers can inform the dispatcher of road conditions or problems.

  • Page 17: Mcp100 Component Description

    • Within the NOC is the Network Management Computer (NMC), which receives and handles information traffic. • Located at Omnitracs, LLC, in Las Vegas, NV. Omnitracs Dispatch • Software on the trucking company’s dispatch computer and dispatcher’s interface with the MCP100.

  • Page 18: Data Satellite And Gps Network

    • MCP100 receives positioning data from the GPS receiver, which is integrated inside the antenna to determine location. • Position data from the MCP100 is forwarded to dispatch whenever information is sent to a vehicle and acknowledged, and whenever a driver sends information.

  • Page 19: Cdma Wireless Network And Pcs

    • Sends vehicle location information to the NOC. • Each MCP100 has its own unique unit address which is the serial number on the MAS. This address is used by the NMC to route information to the correct vehicle. The unit address for a particular vehicle changes if the MAS in the vehicle is replaced.
  • Page 20 - Mobile application server (MAS)— Unit which contains the operating circuitry and memory for the MCP100. The “black box” of the platform. - Media display unit (MDU)—Standard display unit for the MCP100, which the driver uses to transmit information with the dispatcher. Consists of a keyboard and a color touchscreen LCD display.
  • Page 21 Component Overview Topics in this chapter provide information on the basic components of the MCP100. • For planning and installation instructions, see Chapters 4–11. • For optional accessory installation, refer to Optional Accessories for the MCP100 on page 2-7. MCP100 Masterpack .

  • Page 22: Mcp100 Masterpack

    MCP100 Masterpack Component Overview MCP100 Masterpack The MCP100 masterpack includes: • Satellite data modem (SDM) • Mobile application server (MAS) • Terrestrial Antenna • Backup battery • Terrestrial data modem (TDM) • Remote control device (RCD) • Media display unit (MDU) •...

  • Page 23: Satellite Data Modem (Sdm)

    • Robust sealing mechanism for use in all outdoor environments. • Rugged, lightweight housing with the same bolt pattern as the OmniTRACS antenna communication unit (ACU) for ease of installation. • Gyroscopic-based steering algorithm for quick satellite signal reacquisition in the event of a momentary loss of signal.

  • Page 24: Tdm Cable

    Remove just prior to attaching the cable to the MDU. Using the MDU To navigate the MDU touchscreen: use your fingers, or a standard PDA stylus (not provided by Omnitracs). 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 25: Mobile Application Server (Mas)

    Component Overview Mobile Application Server (MAS) DO NOT use for navigating the MDU touchscreen: pencils, pens, metal objects, or any other devices which could possibly scratch the touchscreen. To clean the MDU: use a soft cloth and either plain water, glass cleaner, or mild soap. Do not spray any liquid directly onto the MDU.

  • Page 26: Accessory Cables For The Mcp100-Standard And Full Function

    05AAA_044BQMCP Caution When vehicle power is lost to the MCP100, the backup battery allows the MAS to shut down gracefully and properly store data. Without a healthy battery installed, there is a high probability of experiencing data loss or corruption.

  • Page 27: Remote Control Device (Rcd)

    • Flexible mounting methods using either very high bond tape (VHB) that sticks the RCD to the dash, or screws. • Backlight keypad with navigation and other critical function keys. Optional Accessories for the MCP100 Accessory Chapter Performance Monitoring system...

  • Page 28: Optional Accessories For The Mcp100

    Optional Accessories for the MCP100 Component Overview 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 29: Chapter 3 General Wiring And Installation Guidelines

    General Wiring and Installation Guidelines Topics in this chapter provide the Omnitracs-approved general methods for making connections to cables and wires and the proper connectors to use to avoid potential problems. Making Electrical Connections .........

  • Page 30: Making Electrical Connections

    Making Electrical Connections Approved Omnitracs Electrical Connectors The only Omnitracs-approved electrical connectors are crimp butt splices and crimp ring terminals. Omnitracs recommends Nylon insulated, seamless butt connectors with inspection windows. Heat-shrinkable butt connectors are preferred. When butt splicing multiple wires on one end of a butt splice and a different number of wires on the other end, step-down butt splices are recommended.

  • Page 31: Butt Splicing

    General Wiring and Installation Guidelines Butt Splicing Butt Splicing • Omnitracs recommends Nylon insulated, seamless butt connectors with inspection windows. • Heat-shrinkable butt connectors are preferred. Butt splicing can be done inside and outside the cab or enclosure. See Butt Splicing...

  • Page 32: Crimping

    Crimping General Wiring and Installation Guidelines Crimping • When crimping a butt-spliced wire or cable, be sure the insulated butt splice is crimped using the insulated position on the crimp tool and not the crimping “tooth” of the tool. • Crimping butt splices incorrectly can result in a severed wire and a failed wire connection. Caution DO NOT crimp on the crimp “tooth.”...
  • Page 33 General Wiring and Installation Guidelines Crimping Note The objective is to apply only the necessary pressure to crimp the butt splice closed and hold the wire connections together. Do not apply so much pressure as to crush the butt splice and sever the wire or the insulation on the wire.
  • Page 34 Crimping General Wiring and Installation Guidelines Crimping locations Outside crimp (insulated wire) Outside crimp (insulated wire) Inside crimp (stripped wire) Inside crimp (stripped wire) 03AAA_273 Verify that the crimps are good and the wires have not been damaged. Do a pull test. Pull on both ends of the wires to ensure a solid butt-spliced connection exists.
  • Page 35 Use a minimum of two layers of seal tape to completely wrap the connection. • 3M industrial tape (tape sealant, vinyl/rubber mastic) is available in a 10’ roll from Omnitracs (MCN# 800-01788-0168). To find a local or nationwide supplier, visit ® http://www.3m.com (Mastic, Scotch Vinyl).
  • Page 36 Crimping General Wiring and Installation Guidelines Strain Relief With or Without Weather Protection Tape If there is sufficient wire available for the Four-Finger Wrap Method: Wrap a wire around four fingers of a hand, one full loop, so that the wire loop is longer than the wrapped butt splice.
  • Page 37 General Wiring and Installation Guidelines Crimping Caution Failure to cut the tie wraps flush to the lock head can result in minor injury. Cut tie wrap flush with lock head. 04AAA_25a Firmly tug on the butt-spliced wire connection to make sure the tie wraps do not pull loose.

  • Page 38: Ring Terminals

    Ring Terminals General Wiring and Installation Guidelines Ring Terminals When making electrical connections, crimp ring terminals onto the ends of the wires to ensure good contacts. A properly crimped ring terminal has these characteristics: • The barrel crimping indent is well-formed and properly positioned. •...

  • Page 39: General Installation Guidelines

    General Wiring and Installation Guidelines General Installation Guidelines General Installation Guidelines • Determine the most direct and protected route when routing cables to connect the components to each other and to the vehicle. Refer to Chapter • The standard cable length for the power, display, and accessory cables is 20 feet. - If you are working with a tilt cab, a longer cable may be necessary.
  • Page 40 Routing and Protecting Cables General Wiring and Installation Guidelines Special Exterior Routing Guidelines • Always use convoluted tubing to protect the cables. Secure the cables to the vehicle with tie wraps at approximately 18" intervals. • Route away from exhaust pipes and moving parts. If an exhaust pipe or moving part must be crossed, use extra tie wraps and route the cable in such a manner that if the tie wrap fails, the cable will be caught or rest on a safe part (not hot or moving).
  • Page 41 General Wiring and Installation Guidelines Routing and Protecting Cables Access Holes • Use existing holes for cable routing. • If you drill, drill the smallest hole for the purpose: - 1-1/2" hole is recommended for cables with a 9-pin DSUB connector, e.g., SDM cable. - 1"...
  • Page 42 Routing and Protecting Cables General Wiring and Installation Guidelines 3-14 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 43 Installation Planning Topics in this chapter provide guidelines for planning a basic Omnitracs MCP100 installation. Installation Guidelines ..........

  • Page 44: Installation Guidelines

    • Make sure there are no loose components/cables and no unsecured components. • Use solid mounting surfaces. • Do not modify or design your own mounts without first obtaining Omnitracs approval (applies domestically only). • Mount the terrestrial antenna in locations where the unit will receive uninterrupted and undegraded GPS satellite signals.

  • Page 45: Typical Installation Locations For The Terrestrial Mcp100

    Installation Planning Typical Installation Locations for the Terrestrial MCP100 Locate and Install Remote control device (RCD), see Chapter Accessories. Terrestrial data modem (TDM), see Chapter MAS, see Chapter After you install the MCP100 components, see Chapter 12 to perform system verification.

  • Page 46: Typical Installation Locations For The Satellite Mcp100

    Typical Installation Locations for the Satellite MCP100 Installation Planning Typical Installation Locations for the Satellite MCP100 CB or Stereo Speaker Media Display Unit SDM Cable Accessory Connections (e.g., RMWL, J1708, RCD, TTS) Power Connections Remote Control Device Speaker Cable Display Cable...
  • Page 47 Installation Planning Conventional Vehicle Types Freightliner FLD Freightliner • MAS—Install on side wall or hang under bunk. Existing heater A pillar - Install so there is always SD card slot access. • MDU—Attach to electrical access panel behind gearshift. Electrical Panel Display •...
  • Page 48 Conventional Vehicle Types Installation Planning - Cables enter/exit cab through firewall high on passenger side. Look for rubber plugs. - Drill a 1-1/2" hole in floor of side box for SDM cable. A hole already exists in the firewall to route cables to the passenger side fuse panel. Volvo Volvo •...

  • Page 49: Straight Truck Vehicle Types (All Makes)

    • In most tilt cab vehicles, this routing requires a longer Longer Cable cable than the standard cable. Power Bus/ • When ordering the MCP100, specify the length of the Switch cable(s) you need. Pivot Point 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 50: Tools And Supplies Recommended For Installations

    • Electrical Tape Items marked with a bullet (•) are considered necessary, must-have tools and supplies required to perform an installation. Additional tools may be required to facilitate certain installations and for maintenance. Omnitracs Approved Sealants Sealant, Lubricant, or Liquid Acceptable For...

  • Page 51: For Technical Questions, Contact Omnitracs Customer Support

    ......... For technical questions, contact Omnitracs Customer Support.

  • Page 52: General Installation Guidelines

    General Installation Guidelines Mobile Application Server (MAS) Installation General Installation Guidelines Install the backup battery into the MAS. Install the MAS into the mounting surface. Connect the accessory and power cables to the MAS. Installing the Backup Battery into the MAS Install the backup battery before installing the MAS.

  • Page 53: Installing The Mas

    Mobile Application Server (MAS) Installation Installing the MAS Rotate the backup battery into a horizontal position and place in the MAS. Battery Pack Pull Tab Captive Torx # 10 Screw I U I U I / 0 I / 0 05AAA_44AQMPC Close door and tighten the T10 Torx screws using a hand tool.
  • Page 54 Selecting a Mounting Location Mobile Application Server (MAS) Installation 05AAA_237 D S P L S D M I / 0 P W R 1" 1" 3" 3" 1" 1" DSPL I / 0 Location and Orientation • When possible, do not install the MAS on the floor of the vehicle. •...

  • Page 55: Securing The Mas

    This ensures that there will be enough battery power left to start and run the vehicle. Do not wire the MCP100 through any LVD device as this will affect the normal operation of the system. When the LVD is engaged:...

  • Page 56: Power Cable Wire Connections

    Power Cable Wire Connections Mobile Application Server (MAS) Installation Power Cable Wire Connections • Vehicle battery supplies power to the MAS. • The three required connections that you must make at the fuse end of the power cable: - Chassis ground - labeled “BAT RTN” - +12/24 VDC Battery (Main) (unswitched) - labeled “BAT+”...

  • Page 57: Grounding Guidelines

    Metal surface Paint Installing the Accessory Cable • Connects the MCP100 to the RCD for text-to-speech, the J1708/1587 data link, and other vehicle inputs and optional system devices. • Provides necessary wiring for optional system features, such as display screen disabling, the Performance Monitoring system, Trailer Tracks asset management, buzzer, RMWL, panic button and other security devices.
  • Page 58 VIO/RED BLU/YEL BLU/VIO 06AAA_125T2 Full Function Omnitracs MCP100 Accessory Cable • Connects accessories and options, and the RCD and speaker to the MAS for text-to- speech (TTS) play. • Supports wiring for the CDU, Axle, RPM, PTOP, and PTOC. TTRACS...

  • Page 59: Cable Run

    • Installation instructions for optional accessories which use the accessory cable are provided in later chapters of this guide. • Before connecting the accessory cable to the MCP100, inspect the connectors to make sure they are not damaged and the pins are not bent. Do not attempt to straighten bent pins.
  • Page 60 Connecting Cables to the MAS Mobile Application Server (MAS) Installation 5-10 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 61 Customer Support is staffed 24 hours a day, 365 days a year: • In the United States, call 800-541-7490 • In Canada, call 800-863-9191 Note The TDM is only used with the terrestrial MCP100. 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 62: General Installation Guidelines

    General Installation Guidelines Terrestrial Data Modem (TDM) Installation General Installation Guidelines Install the TDM. Connect the TDM cable to the TDM. Connect the TDM Cable to the MAS. Installing the TDM Install the TDM on top of the MAS where indicated by the pre-installed dual-lock tape (a ™...

  • Page 63: Installing The Tdm Cable

    Terrestrial Data Modem (TDM) Installation Installing the TDM Cable Installing the TDM Cable • Connects TDM to MAS. TDM Cable Installation Plug the 9-pin DSUB connector into the SDM slot of the MAS. Plug the 25-pin connector into the TDM. 07AAA_56A Connecting the TDM Cable to the MAS Inspect the connector for bent pins.
  • Page 64 Connecting the TDM Cable to the MAS Terrestrial Data Modem (TDM) Installation 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 65: Chapter 7 Terrestrial Antenna Installation

    Customer Support is staffed 24 hours a day, 365 days a year: • In the United States, call 800-541-7490 • In Canada, call 800-863-9191 Note The flat antenna is only used with the terrestrial MCP100. 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 66: General Installation Guidelines

    General Installation Guidelines Terrestrial Antenna Installation General Installation Guidelines Orient the antenna on the exterior of the vehicle roof. Connect and route the cable. Connect the antenna cable to the TDM. The antenna can be installed using tape or screws. •...

  • Page 67: Option B-Mount Method Installation Using Hardware

    Terrestrial Antenna Installation Option B—Mount Method Installation Using Hardware Apply the tape primer evenly across the vehicle mounting surface. Wait five minutes before installing the antenna bracket. Remove the backing from the VHB tape. Position the vertical bracket assembly up to the mounting surface.

  • Page 68: Routing The Terrestrial Antenna Cable

    Routing the Terrestrial Antenna Cable Terrestrial Antenna Installation Routing the Terrestrial Antenna Cable The antenna cable connects the antenna to the TDM. • Run direction—Start at the antenna and run the cable down to the TDM. • Run location—Route the cable internally or externally. •...

  • Page 69: Chapter 8 Satellite Data Modem (Sdm) Installation

    Satellite Data Modem (SDM) Installation Topics in this chapter provide guidelines for installing the MCP100 SDM. General Installation Guidelines ........

  • Page 70: General Installation Guidelines

    Omnitracs determines to have failed as a result of installation on the headache rack. • DO NOT paint the SDM. Painting the SDM will degrade the performance of the MCP100 and void the unit warranty. The SDM mount may be painted.

  • Page 71: Installing Mounting Bolts

    Satellite Data Modem (SDM) Installation Installing Mounting Bolts Vehicles Without Airdams • On a vehicle without an airdam and/or the mount is on the rear of the cab, orient the SDM so the SDM cable connection faces toward the side of the vehicle. See page 3-11 cable routing examples.

  • Page 72: Line-Of-Sight Requirements

    Line-of-Sight Requirements Satellite Data Modem (SDM) Installation Line-of-Sight Requirements • SDM requires an unobstructed line-of-sight view to the satellite in order to clearly send and receive signals. • SDM must be able to send and receive the signals at a 12° angle above the horizontal plane of the unit.

  • Page 73: Trailer Swing Area

    Satellite Data Modem (SDM) Installation Trailer Swing Area Trailer Swing Area • DO NOT position the mount in the rear center of the vehicle. The corner of the trailer could hit the SDM when the vehicle turns sharply. • When positioning the SDM on the mount, protect the SDM connector by turning the antenna so it faces the side and NOT the back of the trailer.

  • Page 74: Sdm Cable Run

    SDM Cable Run Satellite Data Modem (SDM) Installation • The SDM connector is weather-resistant; do not weather-proof the SDM connector. Caution Do not use refrigeration/tar tape on the SDM connector. SDM Cable Run • Run direction—Start at the SDM mount and run the cable down to the MAS. •...

  • Page 75: Connecting The Sdm Cable To The Mas

    Satellite Data Modem (SDM) Installation Connecting the SDM Cable to the MAS Drill an access hole through the bottom of the cab so it enters where the MAS is installed. See Access Holes on page 3-13. Store and coil excess cable near the MAS. Caution Do not tie the cable to the headache rack.
  • Page 76 Connecting the SDM Cable to the MAS Satellite Data Modem (SDM) Installation 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 77: Chapter 9 Media Display Unit (Mdu) Installation

    MAS........For technical questions, contact Omnitracs Customer Support.

  • Page 78: General Installation Guidelines

    General Installation Guidelines Media Display Unit (MDU) Installation General Installation Guidelines Install the MDU holster and MDU. Route and connect the cable to the MDU. Connect the MDU cable to the MAS. Selecting a Mounting Location IMPORTANT SAFETY INFORMATION Do not locate the display unit where it obstructs the driver’s field of vision, distracts the driver from the driving task, or interferes with the driver’s operation of controls or displays.

  • Page 79: Installing The Mdu Holster Using Well-Nut Fasteners

    Media Display Unit (MDU) Installation Installing the MDU Holster Using Well-nut Fasteners Hole Mount Tie Wrap and Self Drilling Screw Media Display Unit (MDU) Additional information for selecting an installation location: • Nothing should be installed on the windshield that obstructs the area swept by the windshield wipers or obstructs the driver’s sight to the road and highway signs and signals.

  • Page 80: Installing The Mdu Cable

    Installing the MDU Cable Media Display Unit (MDU) Installation Pass the 10-32 machine screws through the holster and mounting holes and tighten until snug. Mounting Surface Holster Installing the MDU Cable • Connects MDU to MAS. MDU Cable Run • Run direction—In most vehicles, the display unit is mounted in the dash area. Route the cable from the MDU to the MAS with the coiled end of the cable at the MDU and the uncoiled end routed to the MAS.

  • Page 81: Inserting The Mdu Into The Holster

    Media Display Unit (MDU) Installation Inserting the MDU into the Holster Straight Bent OM/E-0093-50 Ch 6 • Make sure the rubber grommet fits in the grooves of the MDU. • Make sure the flat side of the grommet is facing up. Install and tighten the cable strain tie wraps on the back of the MDU.

  • Page 82: Connecting The Mdu Cable To The Mas

    Connecting the MDU Cable to the MAS Media Display Unit (MDU) Installation Push top of display into upper holster tab Holster Holster Push bottom of display into lower holster tabs 05AAA_224 Connecting the MDU Cable to the MAS Inspect the connector for bent pins. Only hand-tighten the thumb screws on the connector.

  • Page 83: Mdu Touchscreen Calibration

    Media Display Unit (MDU) Installation MDU Touchscreen Calibration MDU Touchscreen Calibration If you are tapping any of the icons on the touchscreen and the screen is not responding quickly, the touchscreen may not be calibrated properly. To recalibrate the MDU touchscreen settings, from the Home screen: •...
  • Page 84 MDU Touchscreen Calibration Media Display Unit (MDU) Installation 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 85: Chapter 10 Text-To-Speech (Tts) Installation

    Text-to-Speech (TTS) Installation Topics in this chapter provide guidelines for installing the remote control device (RCD) and speaker switch cable for the MCP100 text-to-speech (TTS) feature. General Installation Guidelines ........

  • Page 86: General Installation Guidelines

    VHB tape. If you use the nutserts, you will need 4-40 x 0.375- 0.412 screws. These screws are not supplied by Omnitracs. Remove the paper backing from the VHB tape and firmly press the RCD onto the mounting surface.

  • Page 87: Selecting A Speaker

    Speaker Requirements There are two basic speaker requirements for TTS: • Only one speaker should be connected to the MCP100 for text-to-speech play, otherwise the volume will be very low. • An 8-ohm speaker, such as a standard CB speaker or standard truck audio speaker, should be used for text-to-speech play.

  • Page 88: Option 1-Connecting To An Existing Or Shared Speaker

    Option 1—Connecting to an Existing or Shared Speaker Text-to-Speech (TTS) Installation Option 1—Connecting to an Existing or Shared Speaker Test the audio system prior to installation. Remove audio/radio. Locate the speaker wires to be used for message playback. Refer to Radio Connector Pin Callouts on page A-13.

  • Page 89: Connecting Speaker Switch Cable To Accessory Cable

    Text-to-Speech (TTS) Installation Connecting Speaker Switch Cable to Accessory Cable Butt splice the black VEH AUDIO IN - wire on the speaker switch cable to the negative (-) speaker wire that leads from the audio. Tie wrap loose cabling and reconnect/replace the radio. Connecting Speaker Switch Cable to Accessory Cable Butt splice the yellow MAS SPKR + wire on the speaker switch cable to the blue/yellow SPKR + wire on the accessory cable.

  • Page 90: Option 2-Connecting To A Dedicated 8-Ohm Speaker

    Option 2—Connecting to a Dedicated 8-ohm Speaker Text-to-Speech (TTS) Installation Option 2—Connecting to a Dedicated 8-ohm Speaker Connect the dedicated speaker for text-to-speech play directly to the accessory cable: Butt splice the blue/yellow SPKR + wire on the accessory cable to the positive (+) wire that leads from the speaker.
  • Page 91 ........11-14 For technical questions, contact Omnitracs Customer Support. Customer Support is staffed 24 hours a day, 365 days a year: •...

  • Page 92: Chapter 11 Vehicle Data Bus Connections

    MCP100. J1939 Data Bus Omnitracs applications only support 2007 and newer trucks with ECMs that support the SAE J1939-71, Rev. Nov 2006 standard. • High speed (250 Kb/sec) data bus.

  • Page 93: Vehicle Data Source Selection

    J1708 /J1587 low-speed data bus and the J1939 high-speed data bus. The truck year, make, and model, as well as the Omnitracs applications used determine which data bus to use. If you do not know which data source to use, contact your Omnitracs representative for assistance.

  • Page 94: J1939 Pre-Installation Check Out

    J1939 Pre-installation Check Out Vehicle Data Bus Connections J1939 Pre-installation Check Out Prior to beginning any installation, start the vehicle and verify that the vehicle is in good working order, has no faults, and no check engine lights display. Resistance Test (to Verify that J1939 Is Present) Turn ignition OFF.

  • Page 95: Checking The Mcp100 Accessory Cable

    Use the repeater cable when the distance between the MAS and J1939 bus connection point exceeds 10 feet. Also use option 1 for any after market installations. Connect the MCP100 accessory cable to the CAN repeater. A CAN repeater cable is required for this procedure (see...

  • Page 96: Making The Connection

    Making the Connection Vehicle Data Bus Connections In order for the MCP100 to receive J1939 data, the MAS CAN/J1939 wires must be connected to the truck’s J1939 CAN bus in the vehicle. Follow all SAE guidelines when connecting to the vehicle’s J1939 data bus.
  • Page 97 Vehicle Data Bus Connections Making the Connection Connect the CAN repeater cable to the CAN 6-pin Molex plug on the MCP100 accessory cable. CAN 1 Connector 6-pin Mole x connector PIN 4 PIN 4 PIN 4 PIN 6 PIN 6...

  • Page 98: Option 2-Connecting J1939 Using The Converter Cable

    TRUCK ECM 08AAA_048 In order for the MCP100 to receive J1939 data, the MAS CAN/J1939 wires must be connected to the truck’s J1939 CAN bus in the vehicle. Follow all SAE guidelines when connecting to the vehicle’s J1939 data bus.
  • Page 99 Measure the J1939 bus resistance at the diagnostic connector. It should read 60 ohms. Locate the CAN 4-pin Molex connector on the MCP100 accessory cable. Connect the CAN converter cable to the CAN 4-pin Molex plug on the MCP100 accessory cable.

  • Page 100: Option 3-Connecting Directly To J1939

    TRUCK ECM 08AAA_ In order for the MCP100 to receive J1939 data, the MAS CAN/J1939 wires must be connected to the truck’s J1939 CAN bus in the vehicle. Follow all SAE guidelines when connecting to the J1939 data source.

  • Page 101: Making The Connection

    Making the Connection Making the Connection Locate the J1939 CAN wires on the MCP100 accessory cable. These are usually located either in the truck’s B pillar or in the center of the dash. Connect J1939 CAN wires to truck’s J1939 stub.

  • Page 102: Connecting J1708 /J1587

    Because there usually is not much slack in the engine data diagnostic connector wires, be careful in cutting and splicing to them. Splice the brown J1708+ wire from the accessory cable to the DATA+ (pin F) wire of the engine diagnostic connector. Reconnect the wires. MCP100 Accessory Cable Butt Splice To vehicle...
  • Page 103 Vehicle Data Bus Connections Connecting J1708 /J1587 Splice the red J1708- wire from the accessory cable to the DATA- (pin G) wire of the engine diagnostic connector. Start the vehicle and verify that the truck is in good working order and displays no dash faults.

  • Page 104: Verifying Data Source Connectivity

    • The light indicator will be green when a data source is enabled to receive data from that source. • Data source must be active to increment data. If you have any questions, contact Omnitracs Customer Support. Note Tap the Green Light/Red Light icon located along the bottom of the screen to display the VDS Summary screen and note the data source and LED status.
  • Page 105 Vehicle Data Bus Connections Verifying Data Source Connectivity Verify Data Source VDS must be configured to J1939. Verify data is present. Verify the following data fields are showing green and incrementing to confirm that J1939 data is present: • Speed •...
  • Page 106 Verifying Data Source Connectivity Vehicle Data Bus Connections 11-16 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 107: Chapter 12 System Verification

    Form......12-20 For technical questions, contact Omnitracs Customer Support. Customer Support is staffed 24 hours a day, 365 days a year: •...

  • Page 108: What Is Basic Mcp100 System Verification

    It is a functional system check that should be performed after installation or service to verify that the MCP100 is operating properly. Performing System Verification Shortly after you power up the MCP100, the Driver Warning screen displays. Scroll through the icons. Tap the System icon to access the Display screens on the following pages.

  • Page 109: Mcp100 System Screens

    • Shows the mobile unit (MCP100) ID, e.g., 105000xxx. • Tells the dispatcher the correct address for sending messages to the vehicle. • If the MCP100 is replaced, this field will display a different address. 80-J4866-2 Rev. G 12-3 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 110: Out

    • This number increases as the MCP100 receives new messages, and decreases as they are read. Usr Msgs Indicates the number of text messages the MCP100 has in the queue to Pending be sent. All Msgs...

  • Page 111: Ovt/Cdma Screens

    System Verification OVT/CDMA Screens OVT/CDMA Screens Tap the OVT/CDMA tab to access antenna information about the MCP100, such as signal strength. There are five OVT/CDMA screens, which you navigate by tapping the screen and then using the arrow keys to move from screen to screen.

  • Page 112: Sdm Screens

    SDM Screens System Verification SDM Screens Tap the SDM tab to access antenna information about the MCP100, such as signal strength. Field Description Serial Number The serial number of the SDM. FL C/No • Signal strength received from the data satellite (the forward signal).

  • Page 113: Gps Screen

    The last received latitude value. Longitude The last received longitude value. Mode Indicates the MCP100’s GPS status: • 3-D is displayed if the receiver is able to view three or more GPS satellites. Under normal performance, a 3-D mode will be displayed.
  • Page 114 Config Screen System Verification Field Description Powerdown • Number of minutes after ignition is turned OFF when the MCP100 will go into sleep mode. • Configured by dispatch. Wakeup • The frequency the MCP100 wakes up from sleep mode to check for dispatch messages.

  • Page 115: Battery Screen

    System Verification Battery Screen Battery Screen Tap the Battery tab whenever you want to see the state of the backup battery. Field Description Backup Battery Indicates the backup battery is detected. Results of last Indicates the voltage of the backup battery when last tested. test Next The date the next automatic test will be performed.

  • Page 116: Cer Screen

    Field Value CER Enabled/disabled If enabled, the MCP100 captures CER events. Speech Enabled/disabled If enabled, what is printed in the alert pop-ups is spoken. Hard Braking Minimum Speed Speed at which mobile unit detects hard brake events.

  • Page 117: Vds (Status) Screen

    System Verification VDS (Status) Screen VDS (Status) Screen • Access vehicle data services (VDS) information, by using the scroll bar and tapping the VDS (Status) tab. Field Value J1587 If vehicle is configured to receive data, the light is green if the vehicle is receiving data from the J1587 data source.
  • Page 118 VDS (Status) Screen System Verification Field Value Speed Speed of the vehicle. RPM of the vehicle. Temp Oil temperature. Accel Acceleration (throttle position) percentage. Fuel Life-to-date (LTD) fuel. 12-12 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 119: Flowchart-Basic Mcp100 System Verification

    System Verification Flowchart—Basic MCP100 System Verification Flowchart—Basic MCP100 System Verification Step 1 Step 2 Move unit to Turn ignition acquire network signal Step 3 Does See Chapter 5 MDU light up & display characters? in the Do backlight, volume, Omnitracs MCP...
  • Page 120 Flowchart—Basic MCP100 System Verification System Verification Step 10 Display Message screen. Send test message to dispatcher Step 11 See Chapter 7 Was message in the acknowledged Omnitracs MCP by dispatcher? Diagnostic Guide Step 12 Have dispatcher send test message to MCP...

  • Page 121: Basic Mcp100 System Verification Procedure

    Make sure the vehicle is in a good location. Satellite Terrestrial • If you are using the terrestrial MCP100, the vehicle should be in a location where the antenna is able to acquire a wireless communication network signal.
  • Page 122 Ctrl Delete in Chapter 6 in the MCP100 Diagnostic Guide. 05AAA_215C If the MCP100 was just installed, it may take as long as 5 minutes for the MCP100 to acquire the PCS network/satellite signal. 12-16 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 123 6. • If the Status is a numerical value, go to the appropriate diagnostic procedure for that value in the MCP100 Diagnostic Guide. Check the Database State field and verify that it is SyncComplete. This may take up to 10 minutes.
  • Page 124 Basic MCP100 System Verification Procedure System Verification Tap the GPS tab. Check that the Mode is 3-D or 2-D and that the LAST UPDATE field is incrementing every second. • If the Mode is 3-D or 2-D and the LAST UPDATE field is incrementing, go to step 9.
  • Page 125 Tap the Inbox tab to display the dispatcher’s message. • If the MCP100 received the message, go to step 14. • If the MCP100 did not receive the message, perform the diagnostic procedure in Chapter 7 in the MCP100 Diagnostic Guide.

  • Page 126: Omnitracs Mcp100 System Verification Form

    Omnitracs MCP100 System Verification Form You can make copies of the System Verification Form on the following page and record important information you may want to keep concerning the vehicle and the MCP100. 12-20 80-J4866-2 Rev. G...
  • Page 127 System Verification Omnitracs MCP100 System Verification Form 80-J4866-2 Rev. G 12-21 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 128 Omnitracs MCP100 System Verification Form System Verification 12-22 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 129 ....... . 13-16 For technical questions, contact Omnitracs Customer Support. Customer Support is staffed 24 hours a day, 365 days a year: •...

  • Page 130: Performance Monitoring System Overview

    Performance Monitoring System Overview The Performance Monitoring system is an optional MCP100 application that records vehicle and driver performance data. The data is then retrieved from the MCP100 by the host computer either manually or automatically at preset intervals. The hardware installation on the vehicle consists of: Connecting the MCP100 to the data link or the standard speed and RPM sensors.
  • Page 131 Performance Monitoring Verification Conducting a Road Test • Note the beginning mileage on the vehicle’s odometer. • Have a passenger compare the speed information on the MDU to the speedometer’s readout. Drive the vehicle at various speeds during the road test. •...

  • Page 132: Performance Monitoring System Display Screens

    Performance Monitoring System Display Screens Performance Monitoring Verification Performance Monitoring System Display Screens Summary Screen Data associated with the active driver since the last Performance Monitoring system data extract. Field Description Driver Active driver name. If no driver is currently logged on as the active driver, “UNIDENTIFIED”...

  • Page 133: Performance Screen

    Performance Monitoring Verification Performance Screen Performance Screen Data associated with the active driver since the last Performance Monitoring system data extract. Field Description Driver Active driver name. If no driver is currently logged on as the active driver, “UNIDENTIFIED” is displayed. Logged in since Number of minutes current driver has been logged in.

  • Page 134: Violations Screen

    Violations Screen Performance Monitoring Verification Violations Screen Data associated with the active driver since the last Performance Monitoring system data extract. Field Description Over RPM Displays while RPM time is accumulating. (>1800) Accumulates by one each time vehicle exceeds RPM threshold for longer than one minute.

  • Page 135: Parameters Screen

    Number of minutes the active driver has been logged in. Beep Unidentified driver beep period in minutes. Distance vehicle must travel before the MCP100 declares the Beginning of Trip and starts Trip_Run recording. End of Trip time threshold in minutes.

  • Page 136: Odometer Screen

    Odometer Screen Performance Monitoring Verification Odometer Screen Field Description Driver Active driver name. If no driver is currently logged on as the active driver, “UNDENTIFIED” is displayed. Logged in since Number of minutes current driver has been logged in. Life to Date Distance Total distance the vehicle has traveled in its lifetime if data is provided by the ECM, otherwise it is Life To Date Performance Monitoring system miles only.

  • Page 137: Pto Screen

    Performance Monitoring Verification PTO Screen PTO Screen Field Description Driver Active driver name. If no driver is logged on as the active driver, “UNIDENTIFIED” is displayed. Logged in since Number of minutes current driver has been logged in. Current state of the PTO (enabled or disabled). Delay Dispatch-configured time-to-start for PTO time.

  • Page 138: Installer Screen

    Performance Monitoring faults that are currently active. Field values are described in the table on page 13-12. J1708 Enabled The MCP100 is looking at the J1708/1587 data link for the Performance Monitoring data. J1708 Disabled The MCP100 is looking at standard and RPM sensors or J1708/ 1587 hybrid speed sensor for the Performance Monitoring data.
  • Page 139 Performance Monitoring Verification Installer Screen Data Missing Field Value Definitions Field Associated Value Meaning Effect Missing Road Speed Performance Monitoring system is not (MPH) receiving road speed from the ECM. Missing Engine Performance Monitoring system is not Speed (RPM) receiving engine speed from the ECM. Missing Total Performance Monitoring system is missing Distance...
  • Page 140 (e.g., wires reversed) causing a positive reading for speed while the vehicle is stationary. Bad Ignition Ignition OFF and speed or Problem with MCP100’s ignition line wiring or fuse. (MCP100) RPM non-zero. RPM Sensor Engine posted PID (194)

  • Page 141: Special Alert Display Notifications

    Performance Monitoring Verification Special Alert Display Notifications Special Alert Display Notifications Certain notifications can be configured to show when the MCP100 needs to warn or remind the driver of certain pending conditions. Warning Notifications Warning notifications are accompanied by an audible chirping beep sound from the display unit speaker.

  • Page 142: Power Take-Off (Pto) Overview

    Power Take-off (PTO) Overview Performance Monitoring Verification Power Take-off (PTO) Overview This option provides customers with the ability to log the time the vehicle engine is used for non-transportation purposes, such as when it is powering auxiliary devices. In order to log PTO time, one of the two PTO wires must be connected to the pump or compressor input.
  • Page 143 Performance Monitoring Verification PTOP (Power Take-off Pump)/PTOC (Power Take-off Compressor) B. Switched to Ground Circuits If you only have a switched circuit that is low activated to the ground to detect PTO time, a relay must be used, as shown in the configuration below. +12 VDC Ign switched +12 VDC (when active) PTOP/PTOC...

  • Page 144: Pto Data Input Verification Procedure

    PTO Data Input Verification Procedure Performance Monitoring Verification PTO Data Input Verification Procedure Turn the vehicle ignition ON. Turn the PTO device ON. Navigate to the PTO screen. • Tap the SensorTRACS (Performance Monitoring) icon. Note If Performance Monitoring is grayed out, Performance Monitoring system is not enabled.

  • Page 145: Chapter 14 Vehicle Maintenance Installation

    ....... 14-3 For technical questions, contact Omnitracs Customer Support. Customer Support is staffed 24 hours a day, 365 days a year: •...

  • Page 146: Feature Requirements

    Brake ABS valve (high) 65226 Brake ABS valve (low) 65226 Note For aftermarket installations, the MCP100 J1939 conversion cable is needed. E-mail notification must be setup by the CSR. Connecting the J1939 Wires Chapter 11 in this guide for detailed information.

  • Page 147: Vehicle Maintenance System Verification

    Vehicle Maintenance Installation Vehicle Maintenance System Verification Vehicle Maintenance System Verification Refer to the following MDU screens to verify vehicle maintenance: Go to the Vehicle Data Service (VDS) status screen. Tap the Home key and scroll down to the System icon. Tap the System icon and tap the VDS tab. Various screen fields are described below.
  • Page 148 Vehicle Maintenance System Verification Vehicle Maintenance Installation Tap the Home icon and scroll down to the Vehicle Maintenance icon. Note If the Vehicle Maintenance icon is not highlighted blue, the service is not enabled for the unit and must be turned on via the Customer Portal. Simulate an engine condition.
  • Page 149 Select the Monitor List tab to view the complete list of monitored Conditions. Verify that e-mail notification goes out upon detection of condition. If you do not receive e-mail notification, contact Omnitracs Customer Support at (800) 541-7490. 80-J4866-2 Rev. G 14-5 MAY CONTAIN U.S.
  • Page 150 Vehicle Maintenance System Verification Vehicle Maintenance Installation 14-6 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 151: Chapter 15 Critical Event Reporting (Cer) System Verification

    ..........15-3 For technical questions, contact Omnitracs Customer Support. Customer Support is staffed 24 hours a day, 365 days a year: •...

  • Page 152: Cer Overview

    CER Overview Critical Event Reporting (CER) System Verification CER Overview CER captures and reports critical event information such as: • hard braking events • stability control events (VDC) • lane departure warning (LDW) events • panic button events • manually triggered events The CER feature records a set of predefined data for the five minute period before a critical event occurs and the two minute period after a critical event is triggered.

  • Page 153: Cer System Verification

    Customer Portal. General Screen field definitions Field Description CER Enabled True or False. If true, the MCP100 captures CER events. Hard Braking Min The minimum speed at which mobile unit will start to detect hard brake Speed events.
  • Page 154 CER System Verification Critical Event Reporting (CER) System Verification Stability Control For stability control critical event reporting to work, the vehicle must be equipped and configured with a stability control system. To see if Stability Control is enabled and configured properly, tap the Roll Stability tab. Stability Control Screen field definitions Field Description...
  • Page 155 Critical Event Reporting (CER) System Verification CER System Verification Lane Departure For LDW to function, the vehicle must be equipped with an LDW system such as an Iteris box. Also verify that the mobile unit is installed on the correct bus. To access LDW information, tap the Lane Departure tab.

  • Page 156: Test System By Manually Reporting An Event

    Verify that the CER web application receives the CER event notification and the data surrounding the event is present. If the notification is not received at the CER web application then the NOC account could be set up incorrectly. Call Omnitracs Customer Support at 800-541-7490.

  • Page 157: Data Link Verification

    Critical Event Reporting (CER) System Verification Data Link Verification Data Link Verification To access vehicle data services (VDS) information, go to the System screen and tap the VDS (Status) tab. You may need to scroll to see the VDS (Status) tab. VDS field definitions Field Description...
  • Page 158 Data Link Verification Critical Event Reporting (CER) System Verification 15-8 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 159: Chapter 16 Trailer Tracks System Installation

    ........16-3 For technical questions, contact Omnitracs Customer Support. Customer Support is staffed 24 hours a day, 365 days a year: •...

  • Page 160: Trailer Tracks System Overview

    • Monitors trailer connects and disconnects and passes the information on to dispatch via the wireless communication network with the date, time, and location. • Monitors the refrigeration unit of a trailer. Hardware Requirements • The MCP100 accessory cable must be installed (see Chapter 5) on the mobile application server (MAS).

  • Page 161: Trailer Tracks System Verification

    Omnitracs for interoperability with the SAE standard PLC4Trucks ABS signal. These tests resulted in no adverse impact on the ABS warning function. Furthermore, Omnitracs is not aware of any interoperability issues in actual operation on vehicles in the marketplace. Trailer Tracks System Verification Enabling the Option for the Trailer Tracks System •...

  • Page 162: Trailer Connection/Disconnection

    Tap the TrailerTRACS (Trailer Tracks) icon. If a trailer is not currently connected, the status is None Connected. After the trailer is connected and the TrailerTRACS unit sends its ID to the MCP100, the trailer ID is updated on the display.

  • Page 163: Trailer Tracks Diagnostic Screen

    Number of ID packets from the TrailerTRACS unit since the ignition Second Number was turned ON. Second Line Number of seconds since the last ID packet was received from the Third Number TrailerTRACS unit by the MCP100. 80-J4866-2 Rev. G 16-5 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 164: Refrigeration Status Screen

    Refrigeration Status Screen Trailer Tracks System Installation Refrigeration Status Screen This feature is only available on tethered products. The reefer information on non-tethered is only transmitted directly to the Trailer Tracks website. Tap the TrailerTRACS (Trailer Tracks) icon. If a refrigeration unit is detected, a snowflake appears above the transmitter ID box. Tap the Transmitter box.
  • Page 165 The trailer’s TrailerTRACS unit ID. Refrigerator Stat # Number of refrigeration status messages sent from the refrigeration unit to the MCP100. When this number is incrementing regularly, your data is being sent from the refrigeration unit. The number is followed by a code that identifies the refrigeration unit’s manufacturer:...
  • Page 166 Refrigeration Status Screen Trailer Tracks System Installation 16-8 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 167: Chapter 17 Compact Display Unit (Cdu) Installation

    ..... . . 17-4 For technical questions, contact Omnitracs Customer Support. Customer Support is staffed 24 hours a day, 365 days a year: •...

  • Page 168: Cdu Overview

    Compact Display Unit (CDU) Installation CDU Overview The CDU is a user interface device that can be used to display an Omnitracs-provided navigation application. A driver can request a map to a specific destination and it will display on the device. The CDU’s display area is large enough to easily refer to the map while driving.

  • Page 169: Installing The Cdu Mount

    Installing the CDU Mount Omnitracs recommends using RAM Mounting Systems (National Products, Inc./ www.ram-mount.com) mounting hardware with the CDU. If another type of mounting hardware is used, it is the installer’s responsibility to ensure that the mounting bracket is robust enough to support the weight of the CDU (~2 lbs) without damaging the mounting surface.

  • Page 170: Attaching The Cdu To The Mounting Bracket

    Attaching the CDU to the Mounting Bracket Compact Display Unit (CDU) Installation If applicable, follow installation instructions from the third-party bracket mount manufacturer. Attaching the CDU to the Mounting Bracket Feed the CDU cable through the 7/8" hole in the dash to the location of the accessory cable.

  • Page 171: Chapter 18 Navigation Installation

    Navigation Installation Topics in this chapter provide guidelines and instructions for installing the Omnitracs navigation application. Introduction to Navigation ......... . .

  • Page 172: Introduction To Navigation

    CDU can be used as the user interface to operate the application. The CDU is a user interface device that can be used to display an Omnitracs-provided navigation application. A driver can request a map to a specific destination and it will display on the device.

  • Page 173: Chapter 19 Buzzer Installation

    Important, or Emergency messages (the message priority is assigned by the dispatcher). It is activated by the message waiting light circuit provided with each MCP100. It can be substituted for, or used with, the remote message waiting light (RMWL). Because the buzzer is very loud, an optional toggle switch can be installed to allow the driver to disable the buzzer.

  • Page 174: Mounting Location

    From Battery 06AAA_84 Connect the green MSG ALERT wire on the MCP100 accessory cable to the other terminal on the buzzer. This wire connects the buzzer to ground when activated by the MAS. It is activated when an Important or Emergency message is received by the MCP100.

  • Page 175: Chapter 20 Remote Message Waiting Light (Rmwl) Installation

    The RMWL can be used when the display unit is located where the driver cannot see the message waiting light. The RMWL illuminates whenever an Important, Sleepy Important, or Emergency message is received by the MCP100. Topics in this chapter include: Installing the Remote Message Waiting Light .

  • Page 176: Installing The Remote Message Waiting Light

    If the RMWL bulb burns out, use a GE53 replacement bulb. The light is protected by a 2-amp in-line fuse. Installation Verification Have the dispatcher, or Omnitracs Customer Support, 800-541-7490, send an Important or Sleepy Important message. Verify that the light comes ON.

  • Page 177: Chapter 21 Wired Panic Button Installation

    ..........21-4 For technical questions, contact Omnitracs Customer Support. Customer Support is staffed 24 hours a day, 365 days a year: •...

  • Page 178: Installing The Panic Button

    Washer 02AAA_23 WARNING When routing the cable, avoid any moving parts or sharp edges. Route the cable to where you make the accessory cable connections on the MCP100. 21-2 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 179 Wired Panic Button Installation Installing the Panic Button Locate and separate the blue/red PANIC_LOW and blue/black PANIC_HIGH wires from the other accessory wires on the accessory cable. Caution Always use the appropriate crimping tool for insulated terminals. Connect the blue/red PANIC_LOW and blue/black PANIC_HIGH wires to the two wires of the PANIC button.

  • Page 180: Installation Verification

    When the serial number is accepted, the number is read back and you receive a confirmation number. Press the 2 key to enter another MCP100 number or hang up to end the call. If this process is unsuccessful, hang up and call Omnitracs Customer Support at 800-541-7490 to speak with a representative.
  • Page 181 You can now press the panic button. You will have an hour to perform the test. When the test is complete, Omnitracs sends a fax and/or an e-mail to your designated contact confirming the MCP100s you tested and the number of times you pressed the panic button for each MCP100 during the test.
  • Page 182 Automated Panic Button Test System Dial-in Procedure Wired Panic Button Installation 21-6 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 183: Chapter 22 Wireless Panic Button Installation

    Overview This chapter discuss the remote transmitter and instructions for installing the wireless panic button (WPB). The WPB works by sending an over-the-air notification using the MCP100. The WPB is approved for use for Defense Transportation Tracking System (DTTS) carriers.

  • Page 184: Wireless Panic Button Kit

    Wireless Panic Button Kit Wireless Panic Button Installation Wireless Panic Button Kit The WPB kit contains: • Receiver (1) • Transmitters (2) Make sure that the sliding guard on each transmitter is snapped over the front, so that the PANIC button cannot accidentally be pushed.

  • Page 185: Additional Wireless Panic Button Accessories

    Wireless Panic Button Installation Additional Wireless Panic Button Accessories Additional Wireless Panic Button Accessories The following kit is also available: • Kit, Wireless Panic Spare XMTR Upgrade. Needed to replace lost or damaged transmitters. Tools and Supplies Needed for Installation The following tools are recommended for installing the WPB: •...

  • Page 186: Using The Remote Transmitter

    The AUX button is not immediately functional, but is available for performing additional functions as set up during installation. Contact an Omnitracs customer service representative before wiring this feature. To activate the AUX feature (if functional), press and release the AUX button.

  • Page 187: Test/Reset Feature

    The receiver should be mounted under the dash in a location that can easily be mounted with tie wraps, preferably near the fuse panel or near the entrance of the MCP100 power cable. The WPB receiver harness should be wired and checked for proper voltages (see...

  • Page 188: Panic Wire Installation

    Securely attach the white with red stripe (PANIC) wire from the WPB power harness to the white (PANIC) from the relay harness using a butt splice. Securely attach the blue/red (PANIC_LOW) wire from the MCP100’s accessory cable to the brown (AUX1 RTS) wire on the relay harness using a butt splice.
  • Page 189 Wireless Panic Button Installation Panic Wire Installation MCP100 Mobile Application Server (MAS) Antenna I U I U Power Cable I / 0 I / 0 44-Pin MCP Accessory Connector Black Black Wired Panic Button Ground Orange 15-Amp Fuse +12 Volt Power...

  • Page 190: Voltage Check

    Voltage Check Wireless Panic Button Installation Voltage Check 03AAA_135 Caution Do not use a voltage test light, as damage to the WPB receiver or vehicle may occur. Now that you have connected the WPB power harness, using a voltmeter, check the voltages on the four wires at the end of the 18-pin connector.

  • Page 191: Antenna Placement

    Wireless Panic Button Installation Antenna Placement Antenna Placement The antenna should be placed as high as possible, away from metal obstructions. For sleeper cabs with airdams, place the antenna as high as possible in a vertical position. Preferred placement 1 to 6 inches (5 to 10 cm) Alternative placement 1 to 6 inches...

  • Page 192: Final Connection

    If more than one location has been set up for your company, you will hear a list of locations. Press the number key that corresponds with your current location and press the # key. When prompted, enter the MCP100 serial number and press the # key. 22-10 80-J4866-2 Rev. G...

  • Page 193: Wireless Panic Button Battery

    When the serial number is accepted, the number is read back and you receive a confirmation number. Press the 2 key to enter another MCP100 number or hang up to end the call. If this process is unsuccessful, hang up and call Omnitracs Customer Support at 800-541-7490 to speak with a representative.

  • Page 194: Wireless Panic Button Battery Replacement

    Wireless Panic Button Battery Replacement Wireless Panic Button Installation Wireless Panic Button Battery Replacement Follow these steps to properly replace the WPB transmitter battery. Pry open the transmitter at the seam to separate the two halves of the transmitter unit. Be careful not to lose the chain.
  • Page 195 Wireless Panic Button Installation Wireless Panic Button Battery Replacement Ensure that the unit is operating by pushing any button except the red PANIC button to light the red LED in the upper left corner. will light 03AAA_29 80-J4866-2 Rev. G 22-13 MAY CONTAIN U.S.
  • Page 196 Wireless Panic Button Battery Replacement Wireless Panic Button Installation 22-14 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 197 • In the United States and Canada, call 800-796-6345 • Outside these areas, call 949-458-0500 To enable the printer function only, contact Omnitracs Customer Support. Customer Support is staffed 24 hours a day, 365 days a year: • In the United States, call 800-541-7490 •...

  • Page 198: Wiring Configuration

    Wiring Configuration In-Cab Printer Installation Wiring Configuration The printer can be connected to the MCP100 in the vehicle using the standard or full function accessory cable. Installation Guidelines Location Install the printer in the cab of the vehicle in a location that is convenient and safe. This can be on a vertical or horizontal surface.

  • Page 199: Installing The Printer

    • You may also use the optional velcro mount. Install the printer in the bracket. Install the printer power cable: Run the printer power cable from the printer to the MCP100 power cable connections. Connect the printer GND wire to CHASSIS_GND.

  • Page 200: Installation Verification

    Press O or CTRL-P. • If the Confirmation to print pop-up screen displays, print a message. • If the Confirmation to print pop-up screen does not display, call Omnitracs Customer Support at 800-541-7490 to have the print function enabled. Return Material Authorization (RMA) Process Request an RMA from O’Neil Printers.
  • Page 201 For technical support, contact BCS Solutions: • In the United States and Canada, call 800-555-5555 For initial support only, contact Omnitracs Customer Support. Customer Support is staffed 24 hours a day, 365 days a year: • In the United States, call 800-541-7490 •...

  • Page 202: Installation Guidelines

    Installation Guidelines In-Cab Scanner Installation Installation Guidelines Install the scanner in the cab of the vehicle in a location that is convenient and safe. This can be on a vertical or horizontal surface. The scanner cannot obscure the driver’s view of the road.

  • Page 203: Calibrating The Scanner

    In-Cab Scanner Installation Calibrating the Scanner Connect the 15-pin DSUB cable end of the scanner to the MAS. Determine where to locate the scanner. If installing the holster, use four VHB adhesive pads (self-tapping screws optional). If mounting the scanner only, use dual-lock tape. Go to Scanner Mounting Option on page 24-2 Holster Mounting Option on page 24-2...

  • Page 204: Sending A Scan

    Sending a Scan In-Cab Scanner Installation Tap the Calibrate button. Wait a few minutes for the calibration to complete. Tap the Scan tab to return to the scanning home screen. Sending a Scan On the Home screen, tap the Scanner icon. Insert the paper, face down.

  • Page 205: Cleaning The Scanner

    In-Cab Scanner Installation Cleaning the Scanner Identify what you’re sending and tap the Send button. When asked to confirm, tap the Yes button. Cleaning the Scanner Tap the Options tab. Insert the cleaning paper. Tap the Clean button. Wait a few minutes while the scanner draws through the cleaning paper and cleans the scanner.
  • Page 206 Return Material Authorization (RMA) Process In-Cab Scanner Installation 24-6 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 207 Wiring Diagrams and Charts Topics in this appendix provide wiring diagrams and pin description charts for the MCP100 and accessories. Satellite MCP100 Electrical Diagram ........

  • Page 208: Satellite Mcp100 Electrical Diagram

    Satellite MCP100 Electrical Diagram Wiring Diagrams and Charts Satellite MCP100 Electrical Diagram DSPL DSPL I / 0 Back & Backspace +9 VDC to +32 VDC " Enter Caps Shift Power Cable Shift Vehicle Battery Delete Ctrl 10 AMP Chassis 3 AMP...

  • Page 209: Terrestrial Mcp100 Electrical Diagram

    Wiring Diagrams and Charts Terrestrial MCP100 Electrical Diagram Terrestrial MCP100 Electrical Diagram Terrestrial Antenna Terrestrial Data Modem DSPL DSPL I / 0 Back & Backspace +9 VDC to +32 VDC Caps " Enter Shift Shift Power Cable Vehicle Battery Ctrl...

  • Page 210: Mcp100 Wiring Diagram

    MCP100 Wiring Diagram Wiring Diagrams and Charts MCP100 Wiring Diagram MCPWiring Diagram Satellite Data Modem and Mount Full Function Terrestrial Antenna CDU Connector CAN1 Connector SDM Cable Antenna Cable T errestrial Data Modem I/O Cable TDM Cable Display Cable Mobile Application Server...

  • Page 211: Power Cable Pin Callouts

    Wiring Diagrams and Charts Power Cable Pin Callouts Power Cable Pin Callouts SIGNAL COLOR 8 (BAT RTN) BLACK 15 (BAT RTN) BLACK 7 (TAMPER) BLACK 14 (BAT RTN) BLACK 6 (ID) 5 (IGNITION) WHITE 3AMP Switched 12VDC Fuse 2 (BAT+) 12 VDC YELLOW 9 (BAT+) 12 VDC YELLOW...

  • Page 212: Terrestrial Data Modem (Tdm) Cable 25-Pin Connector Callouts

    Terrestrial Data Modem (TDM) Cable 25-Pin Connector Callouts Wiring Diagrams and Charts Terrestrial Data Modem (TDM) Cable 25-Pin Connector Callouts SIGNAL LOOP/RTN TAMPER RTC_BACKUP MDM_TX+/COM1_TX+ MDM_TX-/COM1_TX- MDM_RX+/COM1_RX+ MDM_RX+/COM1_RX+ To TDM To MAS 06AAA_130T 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 213: Satellite Data Modem (Sdm) Cable 9-Pin Connector Callouts

    Wiring Diagrams and Charts Satellite Data Modem (SDM) Cable 9-Pin Connector Callouts Satellite Data Modem (SDM) Cable 9-Pin Connector Callouts SIGNAL Drain TAMPER PWR 9.9-11.5VDC PWR 9.9-11.5VDC 06AAA_130 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 214: Standard Accessory Cable Pin Callouts

    Standard Accessory Cable Pin Callouts Wiring Diagrams and Charts Standard Accessory Cable Pin Callouts BLU/GRN BLU/RED PANIC_LOW BLU/BLK PANIC_HIGH MSG ALERT VIO/ORN VIO/RED BLU/YEL BLU/VIO 06AAA_125T1 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 215: Full Function Accessory Cable Pin Callouts

    Wiring Diagrams and Charts Full Function Accessory Cable Pin Callouts Full Function Accessory Cable Pin Callouts BLU/GRAY PIN 29 BLU/GRN PIN 2 BLU/RED PANIC LOW PIN 28 BLU/BLK PANIC HIGH PIN 30 YEL/BLU DIGIN 2 PIN 8 YEL/BRN DIGIN 3 PIN 24 MSG ALERT PIN 39...

  • Page 216: Media Display Unit (Mdu) Connector Pin Callouts

    Media Display Unit (MDU) Connector Pin Callouts Wiring Diagrams and Charts Media Display Unit (MDU) Connector Pin Callouts SIGNAL COLOR Gray Ground Green Black Blue +9VDC Orange Yellow Violet +9VDC Ground To MAS To MDU COLOR SIGNAL Ground Black Gray Orange +9 VDC Violet...

  • Page 217: Six-Pin Data Link Connector Pin Callouts

    Wiring Diagrams and Charts Six-pin Data Link Connector Pin Callouts Six-pin Data Link Connector Pin Callouts 08AAA_050 SIGNAL J1708/J1587 DATA LINK+ J1708/J1587 DATA LINK- +12VDC PLUG P/N:23507136 BATTERY GROUND PLUG P/N:23507136 80-J4866-2 Rev. G A-11 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 218: Nine-Pin Data Link Connector Pin Callouts

    Nine-pin Data Link Connector Pin Callouts Wiring Diagrams and Charts Nine-pin Data Link Connector Pin Callouts 08AAA_051 SIGNAL BATTERY GROUND +12VDC J1939 DATA LINK+ J1939 DATA LINK- J1939 SHIELD J1708/J1587 DATA LINK+ J1708/J1587 DATA LINK- PLUG PLUG A-12 80-J4866-2 Rev. G MAY CONTAIN U.S.

  • Page 219: Radio Connector Pin Callouts

    Wiring Diagrams and Charts Radio Connector Pin Callouts Radio Connector Pin Callouts Common Radio and Harness Front Drivers Side Speaker Wire (B5) Notches Note: Connector tabs on this side Front Drivers Side Speaker Wire (B6) SIGNAL SIGNAL RR + SPEAKER RR - SPEAKER PARK LIGHTS RF + SPEAKER...

  • Page 220: Can Converter Cable

    CAN Converter Cable Wiring Diagrams and Charts CAN Converter Cable SIGNAL COLOR BLACK / ORANGE 24 CAN BUS CAN BUS CAN BUS BLUE / BLACK 24 CAN_B (TX) BLACK / BLUE 24 CAN_A (RX) ORANGE / BLACK 24 COLOR SIGNAL CAN_D (PWR) BLACK / RED 22 CAN_H...

  • Page 221: Appendix B Environmental And Power Requirements

    Environmental and Power Requirements Topics in this appendix provide environmental and power requirements for the MCP100 and accessories. MCP100 Environmental and Power Requirements ......

  • Page 222: Mcp100 Environmental And Power Requirements

    Power +9 to +32 Volts DC Operating at +12V using CDU, RCD, and MCP100 draws a maximum of 1.8 amps from speaker switch cable only—no accessories. the battery (24 W). Operating at +12V without using CDU.

  • Page 223: Appendix C Standard Rma Procedure

    For customers, to return failed equipment, go to Omnitracs Customer Portal at https://customer.omnitracs.com For service centers only, please return equipment to Omnitracs at the following address. Make sure that the RMA number is marked clearly on the outside of the box.
  • Page 224 Standard RMA Procedure 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 225 Upgrading the MCP100 Using Secure Digital Cards An MCP100 is normally upgraded with software by sending it over-the-air using satellite transmissions. However, there may be occasions when upgrades are necessary using secure digital (SD) cards, for example, when there is an operating system (OS) upgrade and when upgrades need to be performed very quickly.

  • Page 226: Appendix D Upgrading The Mcp100 Using Secure Digital Cards

    Upgrading the MCP100 Using Secure Digital Cards Checking the Software Versions Installed Shortly after you power up the MCP100, the user interface screen displays. Scroll down to the System icon and tap the icon. Tap the System tab to access system information about the MCP100.

  • Page 227: Sd Card Instructions

    • Organize files on the SD card so the MAS can read them. - Software is available on the Customer Portal, or you can check with an Omnitracs representative for more information on where to get the software and how the files need to be organized.

  • Page 228: Upgrading The Mas Operating System And Mas Software

    Upgrading the MAS Operating System and MAS Software Upgrading the MCP100 Using Secure Digital Cards After the upgrade process finishes and the MDU screen shows the application icons or the driver warning screen, remove the SD card and confirm the upgrade is complete by checking the MAS software version on the System Information screen.

  • Page 229: Upgrading The Sdm Software

    Upgrading the MCP100 Using Secure Digital Cards Upgrading the SDM Software Keep MAS OS SD card in slot until the right LED goes to solid green. When the right LED is solid green, the OS upgrade is complete. This should take about 3–5 minutes.

  • Page 230: Upgrading The Mdu Software

    Upgrading the MDU Software Upgrading the MCP100 Using Secure Digital Cards Turn vehicle ignition to ON. Insert SDM SW SD card into slot on MAS with label side down/metal strips facing up. Wait approximately six minutes and then check the SDM software level.
  • Page 231 Preventive Maintenance Inspection Topics in this appendix provide steps for inspecting the mobile application server (MAS), the media display unit (MDU), the terrestrial antenna and terrestrial data modem (TDM), the satellite data modem (SDM), and the Trailer Tracks system. uHow Often Should Inspections Be Performed? .

  • Page 232: Uhow Often Should Inspections Be Performed

    Often Should Inspections Be Performed? Preventive Maintenance Inspection How Often Should Inspections Be Performed? • Omnitracs recommends inspections be performed at least once every 90 days. • During normally scheduled vehicle preventive maintenance inspections. Inspecting the Mobile Application Server (MAS)
  • Page 233 Check the left side LED indicator on the MAS. Normally, the left side LED indicator will be Left Side LED blinking blue. Refer to Chapter 13 in the MCP100 Diagnostic Guide for other LED states. Check to make sure the cables are stored DSPL...

  • Page 234: Inspecting The Media Display Unit (Mdu

    Check the Results of last test and verify that the battery is Good. • If the battery shows a failure, Bad—12000, go to Chapter 16 in the MCP100 Diagnostic Guide. Inspecting the Media Display Unit (MDU) Verify proper MDU operation: •...
  • Page 235 Preventive Maintenance Inspection Inspecting the Media Display Unit (MDU) Verify the MDU keys and screen are clean. Omnitracs recommends that you use a soft cloth and either plain water, glass cleaner, or mild soap to gently clean the surfaces of the MDU as well as the display screen.

  • Page 236: Inspecting The Terrestrial Antenna And Tdm, And The Satellite Data Modem (Sdm

    Inspecting the Terrestrial Antenna and TDM, and the Satellite Data Modem (SDM) Preventive Maintenance Inspection Inspect the underside of the MDU to make sure the tie wraps are securely tightened and the cable is not damaged. The illustration to the left is the underside of the MDU showing the tie wraps.
  • Page 237 Check the TDM lights. Normally, the left-side Connectors LED will be blinking green and the right-side LED will be off. Refer to Chapter 9 in the MCP100 Diagnostic Guide for other TDM light states. Go to step 9. to complete the terrestrial...

  • Page 238: Verifying Trailer Tracks System Connections

    Verifying Trailer Tracks System Connections Make sure all 7-way connection points have been cleaned, inspected, and greased. Omnitracs recommends that you use dielectric grease on the connection points. Brushes 04AAA_164A Check the 7-way coil cord for nicks, cuts, or abrasions.
  • Page 239 Preventive Maintenance Inspection Verifying Trailer Tracks System Connections Make sure there is voltage (12–24V) on pin 7 at all 7-way connection points (on the tractor and trailer). Make sure you connect to ground (pin 1) as well when performing this step. Receptacle The illustrations at left show the connection at the tractor and at the trailer.
  • Page 240 Verifying Trailer Tracks System Connections Preventive Maintenance Inspection Connect a test transmitter to the truck. Turn IGN to ON. Access the Trailer Tracks ID screen by selecting the Trailer icon and verifying that the Trailer Tracks transmitter’s ID displays. Test with a Known, Transmitter Good Trailer Tracks Transmitter...
  • Page 241 Component and Document Information Topics in this appendix provide document control numbers (DCNs) and material control numbers (MCNs) for the different documents and MCP100 components referred to in this guide. MCP100 System Component MCNs Referenced in this Guide ....

  • Page 242: Dcns For Documents Referenced In This Guide

    Outdoor Unit Mount Installation Guide TL80-6270-1 MCP100 Diagnostic Guide 80-J4867-2 How to Use the Wireless Panic Button Remote 80-J6060-1 Transmitter (Visor Card) MCP100 System Component MCNs Referenced in this Guide System component Illustration Latest MCN Alternate MCNs Notes Satellite data...
  • Page 243 Component and Document Information MCP100 System Component MCNs Referenced in this Guide System component Illustration Latest MCN Alternate MCNs Notes Compact CV90-J8899 Display Unit (CDU) Mobile 10-J9313-x application (terrestrial) server (MAS) 10-J3015-x I U I U (satellite) Weight 3.25 lbs.
  • Page 244 MCP100 System Component MCNs Referenced in this Guide Component and Document Information System component Illustration Latest MCN Alternate MCNs Notes Power cable 45-J9992-20 05AAA_041A Accessory CV90-J9284-20 This cable is the cable (standard standard cable. with converter connector) 05AAA_ 038T Accessory...

  • Page 245: Mcp100 System Component Mcns Referenced In This Guide

    Component and Document Information MCP100 System Component MCNs Referenced in this Guide System component Illustration Latest MCN Alternate MCNs Notes CAN repeater CV90-J9954-A42 cable CAN BUS CAN BUS CAN BUS 5 amp fuse (for 65-53011-1 Trailer Tracks) 5 Amp Fu...

  • Page 246: Mcns For Sealants And Lubricants Referenced In This Guide

    Sealant, Mastic Butyl Rubber .125" x 2" x 12" Black 755-12528-0003 Seal, Coax Plastic 1/2" x 3/32" x 10" Strips OEM Pkg 755-01910-0001 MCN for Omnitracs-recommended Torque Wrench Referenced in this Guide Tool Torque wrench for replacing the radome 800-01730-0017...

  • Page 247: Appendix G Feedback Form

    Weekly Monthly Never Only when I have questions If you don’t use an Omnitracs manual on a regular basis, please indicate the reason: (check all that apply) Prefer calling customer service Too busy to look in manual Don’t have a copy Other __________________________________________________________________ If you haven’t used an Omnitracs manual, stop here and return the survey.

  • Page 248: Documentation Content

    Documentation Content Feedback Form Documentation Content Please indicate your opinion of the information included in the MCP100 Installation Guide: Too detailed Right amount of information Not detailed enough How often do you find what you’re looking for in the manual?

  • Page 249: Documentation Format

    How important is it for you to receive a paper copy of the documentation from Omnitracs? Very important Important Not important What would be the best way for you to learn about the Omnitracs MCP100? Product training manual Computer-based training Video tape Other ______________________________________________________________...
  • Page 250 Documentation Format Feedback Form 80-J4866-2 Rev. G MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...

  • Page 251: Glossary

    44-Pin I/O Accessory Cable. See Full Function Accessory Cable and Standard Accessory Cable. Bad MCP Status. When an MCP100 fault has been detected, the Status field will display 10000/10001, 12000/12001, 13000/13001, or 22000/22001. See specific Status numbers, or MCP100 Diagnostic Guide for details on status codes.
  • Page 252 (ECU). See J1939 Network and Traditional Sensors Network. J1708 Enabled. “J1708 enabled” means that the MCP100 has been set up to look at J1708 data via the J1708/1587 data link. The dispatch computer operator must send a message to the MCP100 that “tells”...
  • Page 253 NMC. See Network Management Computer. NOC. See Network Operations Center. NO SIGNAL Light. An indicator light on the display that comes on if the MCP100 has lost contact with the data satellite and is searching for the satellite signal. Odometer Screen. The MCP100 display unit screen that displays the life-to-date (LTD) value and sensor calibration information.
  • Page 254 Positioning System. See Global Positioning System. Power Cable. Connects the vehicle 12/24 volt power source and system ground to the mobile application server. Printer. Provides the driver with a hard copy of the MCP100 forward or return message screen display. RCD. See Remote Control Device.
  • Page 255 J1708/1587 data link. Standard Accessory Cable. Connects the MCP100 to the J1708/1587 data link, as well as other vehicle inputs and optional system devices. This cable provides the necessary wiring for optional system features such as display screen disabling, Performance Monitoring system, Trailer Tracks system, panic button, TTS, RCD, Printer, and Scanner.
  • Page 256 System Screen. The Firmware Version screen displays the different software versions (and hardware versions) installed in the MCP100. The System icon (satellite dish) takes you to this screen; then tap the System tab. System Verification. A functional system check that should be performed after installation and periodically to verify that the MCP100 is operating properly.

Table of Contents
