x8
Pathlight (343-1786)
4W incandescent T5 bulb
DEAR CUSTOMER,
Congratulations on your purchase of a ENCHANTED GARDEN
home and provide many years of enjoyment. ENCHANTED GARDEN
professional quality. Ask your dealer about the many other ENCHANTED GARDEN
To ensure the maximum performance of your garden light, please read and save these instructions.
Replacement parts may be ordered by using the fixture model number and the part's name.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS
IMPORTANT SAFETY INSTRUCTIONS
• To reduce the risk of FIRE OR INJURY TO PERSONS turn off, unplug transformer and allow lamp to cool before replacing it. Lamp gets HOT quickly.
• Keep the lamp away from materials that may burn.
• WARNING - Risk of Electric Shock. Install all luminaires 10 feet (3.05 m) or more from a pool, spa or fountain.
• Install in accordance with all local codes and ordinances.
Only for use with low voltage power units with a maximum output rating of 15V, 300W per secondary.
FOR LANDSCAPE LIGHTING SYSTEMS ONLY. OUTDOOR USE ONLY.
THE DEVICE IS ACCEPTED AS A COMPONENT OF A LANDSCAPE LIGHTING SYSTEM WHERE THE SUITABILITY OF THE COMBINATION
SHALL BE DETERMINED BY CSA OR LOCAL INSPECTION AUTHORITIES HAVING JURISDICTION.
READ AND SAVE THESE INSTRUCTIONS
x2
Floodlight (343-1799)
4W incandescent T5 bulb
1-888-867-6095
343-0440
40W Transformer
with photosensor and timer
lighting product. Our products will help to enhance the beauty of your
®
offers a wide selection of lighting products of the highest
®
products that will help to create your own paradise.
®
CUSTOMER SERVICE
customerservice@niinorthern.com
•
Low Voltage
LANDSCAPE
LIGHTING KIT
Landscape wire
18 gauge • 50'• (15,24 m)
5004-343_0440-EN_110310
