By the CLICK function, you can send an analog audio signal to a musician (usually a drummer
or anybody else who needs a rhythmic reference) thru the CLICK output port (¼ inch
stereo standard jack) located on Megabeat Pro's rear panel.
Talking about MIDIfiles, the click signal will be automatically generated by the system
and, once all the related parameters will be set, no further operations are required.
Notes:
_ By enabling the CLICK mode, the PRELOAD function will be disabled and so all LINK
modes.
_ The CLICK function will work fine only if correctly programmed. It means you will have
to insert it according to the MIDIfile's rhythmic informations (please find you could
encounter, even if very seldom actually, some MIDIfiles programmed incorrectly where
music and rhythmic informations are not synchronized between them)
_You can get the click signal thru the CLICK stereo output located on Megabeat Pro's rear
panel
To enter the CLICK function programmable parameters, select UTILITY/MIDI SETUP
page, then "MIDI CLOCK OUT" function. Now, by pressing the "CHANGE" key or rotating
the "PAGE/VALUE" alpha-dial, you can choose among the following options:
DISABLED : MIDI clock and audio click both disabled.
MIDI
: MIDI clock enabled (better in "USER" mode) audio click disabled
CLICK
: Audio click enabled
Megabeat Pro
How using the "CLICK" function
PROGRAMMABLE PARAMETERS
MIDI SETUP
MIDI CLOCK OUT
RESET TYPE
MIDI SONG SEL
VOCALIZER INPUT
LYRICS SYLLAB.
VOLUME TYPE
SC88ST MODE
PRELOAD
SAVE |CLICK | CHANGE |
CLICK
GS RESET
FILTERED
MANUAL+SONG
ENABLED
GM SYSEX
DOUBLE
ENABLED
| EXIT
Megabeat Pro
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Charlie Lab Megabeat Pro
- Page 1 MIDIfile’s rhythmic informations (please find you could encounter, even if very seldom actually, some MIDIfiles programmed incorrectly where music and rhythmic informations are not synchronized between them) _You can get the click signal thru the CLICK stereo output located on Megabeat Pro’s rear panel PROGRAMMABLE PARAMETERS To enter the CLICK function programmable parameters, select UTILITY/MIDI SETUP page, then “MIDI CLOCK OUT”...
- Page 2 If you need to connect mono devices (i.e. monitors), be sure to use the “insert-type” cables (stereo jack into two mono jacks) or a cable as follows: “CLICK” output (Megabeat Pro) : stereo jack, by using one of its channels (left or right) “CLICK” input (i.e. monitor) : mono jack...
- Page 3 Megabeat Pro HOW RECORDING CLICK ON AUDIO FILES Enter the “AUDIO EDIT” page, select the file where you wanna insert click, then press the click key. By pressing the record key, the audio file will start and thru “VOCALIZER” and “MIXER” keys, you can manually record the click on the whole song.
- Page 4 Megabeat Pro _If you stop click recording while song is playing, the click will be automatically integrated within the remaining part of the song. This integration will be done according to the rhythmic informations contained in the last recorded measure. However, because the audio file features, it will be better to record click on the whole song (since starting to ending).
- Page 5 ©2000 Charlie Lab All the trade marks are registered Charlie Lab reserves the right to make changes both to hardware and to software without notice with the purpose to always make things better. In case differences are found between the current manual and the machine you own, please contact us.
