INSTALLATION AND CARE GUIDE
WOODBRIDGE
READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT
INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY
CAUSED BY INCORRECT HANDLING OR INSTALLATION OF THE PRODUCT. THESE
INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION.
CAUTION
THIS PRODUCT MUST BE SERVICED BY QUALIFIED PERSONNEL. ALWAYS UNPLUG
THE POWER CORD OR TURN OFF THE CIRCUIT BREAKER BEFORE SERVICE.
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
R
Or Email: help@woodbridgebath.com
www.woodbridgebath.com
LED MIRROR
2020606 REV. 1
1
Advertisement
Table of Contents
Related Manuals for Woodbridge LEM2028
Summary of Contents for Woodbridge LEM2028
- Page 1 INSTALLATION AND CARE GUIDE WOODBRIDGE LED MIRROR READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION.
- Page 2 TOOLS REQUIRED FOR INSTALLATION (NOT INCLUDED) OTHER TOOLS MAY BE REQUIRED Ø1/4" Drill Bit INSTALLATION DIMENSIONS 1.2" 0.2" 1.96" 0.4" MODEL LEM2028 20" 28" LEM3628 36" 28" LEM3636 36" 36" LEM4024 40" 24" www.woodbridgebath.com...
- Page 3 3" 3" When determining the mounting location for the LED mirror, make sure to provide a minimum 3” (76mm) clearance from the faucet and light fixture. www.woodbridgebath.com...
- Page 4 Level and mark the location MODEL LEM2028 10" 9" LEM3628 18" 9" LEM3636 18" 9" LEM4024 20" 9" Measure the center of the holes and mark the drilling locations ensure marking are leveled www.woodbridgebath.com...
- Page 5 For drywall installa�on, mark the hole loca�ons and drill Φ6mm holes for the drywall anchors. 0.6" Using a drill,make holes and fill with supplied plugs and screws. Leave a gap of 0.6" between the head of the screw and the wall www.woodbridgebath.com...
- Page 6 ELECTRIC CONNECTIONS ALL WIRING SHOULD BE DONE BY CERTIFIED ELECTRICIAN WARNING: Shut off power before wiring the cabinet. WARNING: An Electrical option cabinet must be wired to a 15 Amp GFI (Ground Fault lnterrupter) protected circuit when used in bathrooms and all other locations required by the National Electric Code.
- Page 7 Place the mirror against the wall and slide down as shown in image B Instruction for operating three keys lighted mirror Defogger switch Power switch Dimmer switch Touch the Defogger switch to turn the heating coils ON or OFF. Touch the power switch to turn the task light ON or OFF. Press and hold the dimmer switch to dim or brighten the task lights.
- Page 8 5 seconds later stop blinking, finishing adjusting Retain these installation instructions for future reference! Thank you for using WoodBridge products! Please don't hesitate to contact us if you have any questions or concerns. Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help@woodbridgebath.com...
