Summary of Contents for National Comfort Products COMFORT PACK D Series
- Page 1 R-410A - D MODELS COMFORT PACK PACKAGED THRU-THE-WALL AIR CONDITIONER WITH ELECTRIC HEAT INSTALLATION AND MAINTENANCE INSTRUCTIONS National Comfort Products 539 Dunksferry Road • Bensalem, PA 19020 • (215) 244-1400 • 1-800-523-7138 • Fax: (215) 244-9579 14299889-09-08-14...
- Page 2 TO REMOVE THE CHASSIS FROM THE CABINET: TURN OFF POWER TO THE UNIT. REMOVE THE LOWER ACCESS PANEL FROM THE CABINET. DISCONNECT THE DRAIN LINE FROM THE EVAPORATOR COIL DRAIN CONNECTION. DEPRESS AND HOLD THE RELEASE LATCH ON THE CHASSIS POWER WIRING CONNECTOR AND UNPLUG IT FROM THE CABINET POWER WIRING CONNECTOR.
-
Page 3: Installation
National Comfort Products 539 Dunksferry Road • Bensalem, PA 19020 • (215) 244-1400 • 1-800-523-7138 • Fax: (215) 244-9579 COMFORT PACK PACKAGED THROUGH-THE-WALL AIR CONDITIONER WITH ELECTRIC HEAT INSTALLATION AND MAINTENANCE INSTRUCTIONS chassis, 29” of open area must be left unobstructed in front of NOTE: These installation and maintenance instructions the access panels. - Page 4 Comfort Pack Dimension Drawing 31 7/16" 28" 7 11/16" 15 13/16" 11 1/16" 1 25/32" 7/8" 3 9/16" 1 17/32" 43" 24” 23 9/16” OPENING 7 15/16” OPENING 15/16”...
-
Page 5: Maintenance
wires between the cooling chassis and cabinet. The controls Electrical enclosure cover must be removed to allow access to the screws holding the indoor blower cover plate to the cooling chassis and All wiring must be installed in accordance with applicable cabinet. -
Page 6: Replacement Parts Guide
REPLACEMENT PARTS GUIDE To assure accurancy in providing the correct parts, please provide the unit model designation and serial no. with the parts order. The model designation breakdown is shown below: CABINET CHASSIS ITEM DESCRIPTION PART NO. MODEL ITEM DESCRIPTION PART NO. - Page 7 REPLACEMENT PARTS GUIDE (Continued...) CABINET ITEM DESCRIPTION PART NO. MODEL CP41.0-E Base 14256642 Indoor Coil 14208305 Outdoor Coil 14208307 Compressor (LG Rotary) 14210235 Dual Run Capacitor 40/5 14225372 TXV (BBIZE-1-GA) 14275839 CP41.5-E-LG Base 14256642 Base (Bristol) 14256613 Indoor Coil 14208305 Outdoor Coil 14208354 Compressor (LG Rotary)
-
Page 8: Wiring Schematic/Electric Heat - 5 - 7 & 10Kw
Wiring Schematic/Electric Heat - 5 - 7 & 10KW 5,7,10 kw Heating SEQ1 T-STAT BLUE Black Low Press Switch Cooling EVAP MTR TO RELAY 1 TO 5 1 High - Red Mode Terminal 2 Medium High - Yellow Cool - 6 BLUE Note 1: 3 Medium - Blue Heat - 5 ORANGE... -
Page 9: Wiring Schematic/Electric Heat - 15Kw
Wiring Schematic/Electric Heat - 15KW 15KW Heating SEQ1 T-STAT BLUE Low Press Switch COND MTR Cooling EVAP MTR TO RELAY 1 TO 5 1 High - Red Mode Terminal 2 Medium High - Yellow Cool - 6 BLUE Note 1: 3 Medium - Blue Heat - 5 ORANGE Fan ON delay in cooling... - Page 10 Wiring Schematic/Electric Heat - 5 - 7 & 10KW 5,7,10 kw Heating SEQ1 T-STAT YELLOW Black Low Press Switch Cooling EVAP MTR TO RELAY 1 TO 5 1 High - Red Mode Terminal 2 Medium High - Yellow Cool - 6 BLUE Note 1: 3 Medium - Blue Heat - 5 ORANGE...
- Page 11 Wiring Schematic/Electric Heat - 15KW 15KW Heating SEQ1 T-STAT BLUE Low Press Switch COND MTR Cooling EVAP MTR TO RELAY 1 TO 5 1 High - Red Mode Terminal 2 Medium High - Yellow Cool - 6 BLUE Note 1: 3 Medium - Blue Heat - 5 ORANGE Fan ON delay in cooling...
- Page 12 (B) provide a replacement unit. National Comfort Products will not be responsible for: local transportation, removing, related service, labor, diagnosis calls, refrigerant, costs incurred for returning defective parts, damage or repairs required due to faulty installation or improper application by others, damage as a result of fire, wind, floods, lightning, accidents, or corrosive atmosphere.
- Page 14 COMFORT PACK - Packaged Thru-the-Wall A/C with Electric Heat Installation Instructions - Rev 09/08/14...
