  • Page 1 ENGINEERED SOLUTIONS Jellyfish Filter ® Owner’s Manual Filter...

  • Page 2: Table Of Contents

    FILTER! ® Contech Engineered Solutions would like to thank you for selecting the Jellyfish Filter to meet your project’s stormwater treatment needs. With proper inspection and maintenance, the Jellyfish Filter is designed to deliver ongoing, high levels of stormwater pollutant removal.
  • Page 3 ADDITIONAL RISER SECTION (IF NEEDED) OUTLET PIPE (GROUTED IN OR BOOTED) DECK ASSEMBLY CARTRIDGE RECEPTACLES BACKWASH POOL WEIR CONTROL SECTION (WITH JELLYFISH DECK) INLET PIPE (GROUTED IN OR BOOTED) GASKET (AT EACH JOINT) SEPARATOR SKIRT (MANHOLE ONLY) BASE SECTION Jellyfish Filter Owner’s Manual...

  • Page 4: Owner Specific Jellyfish Product Information

    Chapter 1 .0 – Owner Specific Jellyfish Filter Product Information Below you will find a reference page that can be filled out according to your Jellyfish Filter specification to help you easily inspect, maintain and order parts for your system.

  • Page 5: Jellyfish Filter System Operations & Functions

    This backwash process extends the service life of the cartridges and increases the time between maintenance events. For additional details on the operation and pollutant capabilities of the Jellyfish Filter please refer to additional details on our website at www.ContechES.com.

  • Page 6: Components & Cartridges

    2.1 – Components and Cartridges The Jellyfish Filter and components are depicted in Figure 2 below. Jellyfish Filter Components FIGURE 2 Personnel Access Equipment Access Manhole Structure Outlet Pipe Inlet Pipe Hi-Flo Cartridges with Lid (inside backwash pool) Maintenance Access Wall...

  • Page 7: Jellyfish Membrane Filtration Cartridges Assembly

    2.2 – Jellyfish Membrane Filtration Cartridge Assembly The Jellyfish Filter utilizes multiple membrane filtration cartridges. Each cartridge consists of removable cylindrical filtration “tentacles” attached to a cartridge head plate. Each filtration tentacle has a threaded pipe nipple and o-ring. To attach, insert the top pipe nipples with the o-ring through the head plate holes and secure with locking nuts.

  • Page 8: Inspection And Maintenance Overview

    A minimum of quarterly inspections during the first year of operation to assess the sediment and floatable pollutant The primary purpose of the Jellyfish® Filter is to capture and remove accumulation, and to ensure proper functioning of the system. pollutants from stormwater runoff. As with any filtration system, these pollutants must be removed to maintain the filter’s maximum...

  • Page 9: Wet Weather Inspections

    O-ring seal as well as the plastic threaded nut and connector. Required maintenance for the Jellyfish Filter is based upon results of the most recent inspection, historical maintenance records, or the site specific water quality management plan; whichever is more frequent.

  • Page 10: Sediment And Flotables Extraction

    7.3 Sediment and Flotables Extraction Remove cartridge lid from deck and carefully lower the filter Perform vacuum cleaning of the Jellyfish Filter only after cartridge into the receptacle until head plate gasket is seated filter cartridges have been removed from the system. Access squarely in receptacle.
  • Page 11 Jellyfish Filter Components & Filter Cartridge Assembly and Installation CARTRIDGE LID: ORIFICE DIAMETER PER PROJECT ITEM NO. DRAWING O-RING: INSTALLED WITH EACH MEMBRANE TABLE FILTRATION TENTACLE PART NO. 78713 40501 30600 PSLUBXL1Q NOTES: Head Pl Install H and libe TABLE 1: BOM...

  • Page 12: Jellyfish Filter Inspection And Maintenance Log

    Jellyfish Filter Inspection and Maintenance Log Owner: _______________________________________ Jellyfish Model No.:_____________________________ Location: _____________________________________ GPS Coordinates: ______________________________ Land Use: Commercial:______ Industrial: ______ Service Station:______ Road/Highway:____ Airport: ________ Residential: _________ Parking Lot:______ Date/Time: Inspector: Maintenance Contractor: Visible Oil Present: (Y/N) Oil Quantity Removed...
