Memco Panachrome Installation Manual

Memco Panachrome
2D/3D 10mm Profile
Installation Guide
Ref No. C510 850GB Version 1 (ML)

1. Detector Installation

The Panachrome 10mm 3D/2D detectors can be fitted to centre-opening or side-opening doors. For the visual indicators
to be effective, the system can be installed in dynamic mode, where at least one of the detectors is fixed to a moving
door or in static mode. TX detector must be fitted to left side of lift when viewed from landing.

Installation Notes - 2D/3D

1. Screw the earth ring tag to the lift door using a No.8
screw and a shakeproof washer. The earth must be
fitted to ensure the unit is properly grounded
2. Check also that the door itself is grounded to the lift
3. Use a P-clip either side of the pluggable connectors, to
reduce the risk of plug and socket separating
4. Do not shorten Memco cables by cutting them.
5. Position the detectors on the doors approximately 3mm
above the door sill

Installation Notes - 3D

When installing a Panachrome 3D system, the following
precautions must be observed for trouble-free operation:
1. Always mount the detectors as close to the door edge
as possible.
2. Sight-Guards cannot be used with Panachrome 3D
detectors.
3. For opening exceeding 1200mm, it is recommended
that 'As Doors Close' mode is used.
6. Mark or spot through the 3 fixing holes. See Fig 1.
7. Remove the detectors from the door before drilling
8. Drill the 3 fixing holes in the door using a 3mm drill
9. Screw the detector to the door using the No.6 self-
tapping counter sunk screws provide
Finally check that the detectors are aligned with each
other.
4. The detectors must be set no more than 10mm apart
when the doors are fully closed. The detectors must be
aligned to within ±8mm of the detector centreline.
5. 3D Switch Settings are detailed on the inside of the
Main Controller C3850 000.
