Special Jack Error Codes

To clear one of the error codes listed below:
1.
Correct or otherwise repair the issue (see the table below).
NOTE: In order to clear the special jack error code the jacks need to be "homed." In order to "home" jacks,
each jack MUST be able to retract a minimum of 6".
2.
Extend all jacks to reach the 6" of minimum retract needed.
A. Press "FRONT" (Fig. 24G) to extend the front jacks (if required).
B. Press "REAR" (Fig. 24J) to extend the rear jacks (if required).
3.
Press and hold the retract button until all of the jacks begin to retract. The jacks will retract until they
reach the hard current limit.
4. The jacks are now "homed" and the special jack error code will be cleared.
NOTE: If the jacks do not retract, an error should display on the touch pad screen. This is typically caused by
wiring interruption.
LCD Error Codes
LF Jack
RF Jack
LR Jack
RR Jack
Tongue Jack
Rev: 11.29.18
Special Leveling Jack Error Codes
What's Happening?
Error at a specific jack (left front,
right front, left rear, right rear,
tongue jack).
• Hall signal issue (open,
short, malfunction or loss of
communication)
• Open or short circuit between
controller and motor.
Page 19
What Should Be Done?
Check harness connections
at controller and at jack.
Check harness for damage.
Check fuses at controller.
Repair or replace as necessary.
CCD-0001755
