MV Sports & Leisure Mr Bounce M08514 Assembly Instructions

PLEASE READ BEFORE ASSEMBLY
Mr Bounce Trampoline
THIS PRODUCT IS WEIGHT TESTED
SAFETY NOTICE
Under no circumstances must this product be used by an
adult or anyone over 30kgs.
Caution and care must be taken in the unpacking
IMPORTANT:
and assembly of this product. Due to small parts
In the interest of your child's safety it is important that you
and packaging materials. Adult assembly is
read both the safety notice and the assembly instructions
required.
below carefully, before allowing your child to use this
Adult supervision of this product is required at all
piece of apparatus.
times. Do not leave a child unattended.
NB Before Assembly
Outdoor use - position away from water on flat
1. Check all components are present.
firm ground, ideally grass. Never position on or
2. Trampoline must be assembled on a flat surface.
near to hard surfaces such as patios or
3. It is recommended that the mat is threaded to the
driveways, or close to buildings.
Ensure area under and around trampoline is
clear of any toys/obstacles that may cause
injury.
1
Indoor use - position so that there is sufficient
ceiling height. Never position immediately below
light fittings.
Recommended age for this trampoline is 3-8
years. Maximum weight limit 30Kg.
This Trampoline is designed for one user only. Do
not let more than one child use this product at the
same time.
Users should not wear clothing that could catch
or snag on the product (eg loose clothing, cords,
shoulder bags, jewellery.)
Users should stand or bounce as near to the
centre of the mat as possible. Bouncing or
standing near the edge of the trampoline could
cause the frame to tip over.
Do not allow small children to wander into the
play area whilst the trampoline is in use.
Do not allow small children to crawl or hide under
the trampoline.
Discontinue use if any breakage is found. Failure
to do this may result in injury.
All hard-soled foot-ware must be removed before
use to avoid damaging the printed mat surface.
Not suitable for children under 3 years. This toy
contains small parts which may cause choking.
Please retain this leaflet for reference to the
manufacturer
Carefully made in China to European Safety
Standard
This mark denotes compliance
with the standards laid down by
the EC (European Community).
DISTRIBUTED BY
MV SPORTS & LEISURE LTD
35 Tameside Drive • Castle Bromwich
Birmingham • B35 7AG • UK
Email: info@mvsports.com
www.mvsports.com
Product No. M08514
frame by two adults.
Line the holes in 2 legs together so that the legs form an 'L' shape. Insert a Large Spacer making sure that the
two hexagonal recesses are facing out (as shown). Bolt together until finger tight using: Long Bolts washers and
nuts (do not add dome nuts at this stage). Bolt on the remaining two legs so that a square frame is formed.
Ensure that front pair of legs are formed using the Large Spacers and the back pair of legs using the two Small
Spacers on each leg. (as illustrated).
N.B Ensure that the four legs are level and all in contact with the ground.
FRONT LEGS
Hexagonal
recess
CUSTOMER HELPLINE
We make every effort to ensure that this
product reaches you in satisfactory condition.
However if you have any queries, need
assistance, or find this product defective,
please call our Customer Helpline:
0870 8404255
(UK ONLY)
CONTENTS:
Handle Side x2
Foam Grip
Assembly x 1
Leg Tube x 4
Printed Mat x 1
Elastic Cord x 1
REAR LEGS
Tighten all of the
nuts using the two
spanners provided
as shown, then add
and tighten 8 Dome
nuts using the
spanners provided.
Spanner x 2
Sleeve x 1
Hook x 1
Short Bolt x 4
Long Bolt x 8
Small Plastic
Washer x 20
Spacers x 4
Dome Nut x 12
Large Plastic
Spacers x 2
Nut x 12
Push Handle Side tubes firmly into
2
the Handle Top Tube as shown. We
recommend that the cover seam
and split in the foam grip are
together and twisted around to the
underside of the handle.
Split
Seam
11.03 - ISSUE 1
