Unpack Boxes
1
Component Check List
1.
MSL Jet Plus 400/500
9
2.
Autofeed (Option)
3.
Hand Feed Platform
4.
Platform Infill
8
5.
Receiving Tray
6.
Power Cable
7.
Ink Cartridge
8.
Telephone Adaptor
9.
Telephone Cable
10.
Weigh Platform (Option)
11.
Platform Support (Option)
12.
User's Guide (Not Shown)
13.
Self Adhesive Labels (30 off)
(Not Shown)
Items Sent Separately
Supervisor PIN, Credifon PIN
Attach Weight Platform &
5
Support (Options)
Pins on underside of support mate with
location points on casing.
MSL Jet Plus 400/500
10
11
7
5
1
2
6
4
3
Connect Weigh Platform
6
Scale (Options) to lower
9 pin connector
Getting Started
If you have an Autofeeder then follow Steps 2 & 3.
If not go straight to Step 4.
Detach
2
Platform Infill
3
Connect Autofeed
7
(Option)
Upper 9 pin connector is used
if MailManager II option is used
Attach Platform
3
Infill to Autofeed
(Option) or Plain
Platform supplied
with the base
Fit the slots over the tabs.
8
Attach MSL Jet
4
Plus 400/500
Fit the slots over the tabs.
Connect Telephone
Cable
Advertisement
Related Manuals for MSL Jet Plus 400
Summary of Contents for MSL Jet Plus 400
- Page 1 MSL Jet Plus 400/500 Getting Started If you have an Autofeeder then follow Steps 2 & 3. Attach MSL Jet If not go straight to Step 4. Plus 400/500 Unpack Boxes Attach Platform Detach Infill to Autofeed Platform Infill (Option) or Plain...
- Page 2 Connect Set Print Alignment Position Install the Ink Cartridge Power Cord Receiving Tray After a short delay the Switch on the power at the supply outlet. prompt to make a Test Print After a short delay, the following screen will be observed: will be observed: To make a test print, insert a blank envelope or card.
