Tube Box DS2
Tube phono-preamplifier
Suitable for MM and MC cartridges
Precise RIAA equalisation
Ultra low noise circuitry
Selection between 2 phono inputs & 2 line outputs
Dual mono circuitry for optimized channel separation
Selectable input impedance (for MC: fix or variable)
Selectable input capacitance (for MM)
Selectable subsonic filter
Gold-plated RCA in & outputs
Sandwich alu/metal casing protects from vibrations and elec-
tromagnetic interference
Finishes: silver or black, with/without wooden side panels
(rosenut, walnut, eucalyptus)
Premium phono preamplifier with tube output and highend sound!
This precision tube phono preamplifier benefits from outstanding circuit technology from Dr. Sykora and uses ultimate components.
Compatible with both MM and MC cartridges. It offers connection for two turntables plus two selectable line outputs and a continuous-
ly variable selection of input impedance for low output MC cartridges while playing a record! Other features include input capacitance
for MM cartridges and switchable subsonic, that prevents your amplifier and speakers of ultra low rumble below 20Hz. All compo-
nents including tube output and polypropylene capacitors are audiophile-grade and guarantee a breathtaking sound experience.
A perfect upgrade for ambitious vinyl lovers!
PRO-JECT AUDIO SYSTEMS
a division of AUDIO TUNING GmbH
1050 Wien, Margaretenstraße 98,

Product information

Technical data
Tube assembly 2x ECC83 (12AX7)
Input impedance variable 10-1000 Ohms, fix 47 kOhms
Capacitance 100 / 220 / 320 pF
Gain MM / MC 40 / 45 / 50 / 60 / 65 dB
Output voltage typically 500 mV/1kHz at 5mV/1kHz (at 40dB)
Signal-to-noise ratio 88dBA
THD < 0,04%
RIAA curve accuracy +/- 0,2dB/20Hz - 20kHz
Subsonic filter 20Hz @ 18dB/octave
Input / Output 2x RCA
Power supply 18V/1000mA DC
Power consumption max 490mA DC / < 0,5 watt standby
Dimensions WHD 206 x 91 x 227 mm (aluminium)
240 x 93 x 227 mm (wood)
Weight (without power supply) 1650g (aluminium)
1930g (wood)
Update: DZ / FG
09. 2016
Tube Box DS2
SRP
€ 599,00
Tube Box DS2
Wooden side panels
SRP
€ 699,00
