LG LT64 Series Installation Manual
Hide thumbs
Also See for LT64 Series:
- Owner's manual (47 pages) ,
- Manual (95 pages) ,
- Installation manual (67 pages)
Related Manuals for LG LT64 Series
Summary of Contents for LG LT64 Series
- Page 1 INSTALLATION MANUAL LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. LT64** LT65** LS64** P/NO: MFL67099961 (1204-REV00) www.lg.com Printed in Korea...
-
Page 3: Table Of Contents
LG Hotel Mode Setup . . . . . . . . . . . . . . . . . . -
Page 4: Location And Function Of Controls
locatIon anD functIon of controls y Image shown may differ from your TV . (Only 26LT64**, 26LT65**) screen buttons headphone socket usB input hDMI In remote control power Indicator (Can be adjusted using speakers the Power Indicator in the optIon -menu .) clock leD (Only LT64**) - Page 5 y Image shown may differ from your TV . (Only 32/37/42/47LT64**, 32/37/42/47LT65**) buttons screen headphone socket usB input hDMI In remote control power Indicator (Can be adjusted using the Power Indicator in the optIon -menu .) speakers clock leD (Only LT64**) OPTICAL AUDIO IN...
- Page 6 y Image shown may differ from your TV . (Only 55LS64**) screen headphone socket usB input hDMI In remote control power Indicator (Can be adjusted using touch buttons speakers the Power Indicator in the optIon -menu .) SETTINGS INPUT OPTICAL AUDIO IN DIGITAL (RGB/DVI)
-
Page 7: Introduction
ezManager Introduction This set-up menu will be invoked when it is turned on first time or user selects Factory Reset of main menu . If TV fails to set up and turn it off, TV will show failure message and run installation again on next power-cycle . -
Page 8: Pro:centric Manual
Pro:Centric Manual y Image shown may differ from your TV . Configuration Pro:Centric Mode WELCOME ◄ ► Country Please select the Mode . Data Channel Pro:Centric Auto RF Type pro:centric Manual Pro:Centric Manual Frequency (KHz) ---------- USB Clonning Symbol rate (kS/s) ------- Non Pro:Centric Modulation... -
Page 9: Usb Cloning
USB Cloning y Image shown may differ from your TV . WELCOME TV is cloning image from the USB . Please select the Mode . xx4-LOW00001 .TLL Pro:Centric Auto xx4-LOW00005 .TLL Pro:Centric Manual USB Clonning usB clonning xx4-LOW99999 .TLL Non Pro:Centric Use the button to select the USB Cloning . -
Page 10: Non Pro: Centric
Non Pro: Centric y Image shown may differ from your TV . WELCOME Please select the Mode . Pro:Centric Auto Pro:Centric Manual USB Clonning Non Pro:Centric non pro:centric Use the button to select the Non Pro:Centric . Use the oK button and then button to select Non Pro:Centric . -
Page 11: Installation Menu
The abundant functions for Hotel TV linked with software installation can be projected on OSD as ‘Installation Menu’ . The wide range of hotel features can be performed simply on additional window to enhance the LG hotel TV’s easy installation and convenient operation for Hotelier and System Integrators . -
Page 12: Lg Hotel Mode Setup
S/W V 02 . 0 5 . 0 1 . 0 1 / MCU V 02 . 0 4 / FPGA V d . 279 Use the button to select the LG Hotel Mode Setup . Use the oK button and then button to select Hotel Mode Operation . - Page 13 (3) setup Menu Display - Decide to enter 'Setup Menu Display' or not in the 'Main Menu' by setting 'Setup Menu Display' as Yes(Enter Possible) or No(Enter Impossible) on the "LG Hotel Mode Setup" OSD . (4) programme change - Decide to change channel or not by setting 'Programme Change' as Yes(Change Possible) or No(Change Impossible) when present source is TV .
- Page 14 - Decide whether work the LG remote control or not . - Set to Yes(Work) or No(Do Not Work) . - When ‘LG IR Operation’ is set to NO(Not Work), all keys don’t work . - Although set to No, it can work in Service mode .
- Page 15 LG Hotel Mode Setup (12-1) Input source - Set whether it is turned on by the set input source or by the last stored input source . - It is turned on by the Last Memory Input if the Input source is turned off .
- Page 16 De-active Initial Hotel Mode Operation Power On Status Setup Menu Programme Change Input Source Change Menu Display OSD Display LG IR Operation Local Key Operation Max Volume 0~100 DTV Channel Update Auto Manual Auto Power On Default Input Source...
-
Page 17: Tvlink-Loader
In addition to this, TVLink-Loader enables to load programme for menu installation with wireless basis . y Image shown may differ from your TV . Installation Menu (V2 . 2 3) LG Hotel Mode Setup TV Link-Loader tV link-loader Password Change... -
Page 18: Usb Cloning Procedure
USB Cloning Procedure - Introduction Disappearing OSD implies Completion of data receiving or TV turns off automatically after comple- tion of data sending . * Copy Data item : Programme Data, Installation Menu(excluding the Set ID), Picture, Sound, Option(Special) - The other data can be different depending on the chassis . - Because the Picture Mode: Expert (ISF) Data of the Picture item is charged or the image quality calibration function by set, it should not be copied . -
Page 19: Send To Usb
Send To USB y Image shown may differ from your TV . “Send To USB” must be done first before “Receive From USB” process, as it generate the file to be used in “Send To USB” . While writing is in process, the user must not turn TV off nor unplug the USB memo- ry card . -
Page 20: Password Change
Password Change y Image shown may differ from your TV . - To ensure more security, Password can be changed by installers’ own design . Installation Menu (V2 . 2 3) LG Hotel Mode Setup TV Link-Loader Password Change password change... -
Page 21: Configuration Setup
Configuration setup y Image shown may differ from your TV . Installation Menu (V2 . 2 3) Configuration Setup LG Hotel Mode Setup Select RCU TV Link-Loader Disable ◄ ► Number of RCU Password Change Set ID Setup Splash Offset Time... - Page 22 type of connector: D-sub 9-pin Male No . Signal Signal requirements RX RS232 Standard RS232 specification TX RS232 Standard RS232 specification IR from TV Power ground 6, 8 Not connected 1 .5 A +5VDC 10%, max 100mV ripple Male connector on box, 1 .5 A +12VDC 10%, max 100mV ripple viewed towards connector .
-
Page 23: External Speaker
External Speaker Installation Menu (V2 . 2 3) LG Hotel Mode Setup TV Link-Loader Password Change Set ID Setup External Speaker Configuration Setup Volume Control ◄ ► External Speaker external speaker Output 0 .01 Watt Pro:Centric Main Speaker Power Saving... -
Page 24: Speaker Output Setup
Speaker output SETUP Connect the external speaker to the speaKer output(stereo) jack on the TV . Control port for Speaker out DOWN OPTICAL AUDIO IN DIGITAL (RGB/DVI) AUDIO OUT SPEAKER A A A K RGB IN (PC) VOLUME CONTROL RS-232C IN (CONTROL &... -
Page 25: Pro:centric
Pro:Centric Installation Menu (V2 . 2 3) LG Hotel Mode Setup Pro:Centric TV Link-Loader Mode Password Change ◄ ► Receive Data Disable Set ID Setup RF Type Configuration Setup DVB-T External Speaker RF Freq . (KHz) 460000 Pro:Centric pro:centric... -
Page 26: Power Saving
Power Saving Installation Menu (V2 . 2 3) LG Hotel Mode Setup TV Link-Loader Password Change Set ID Setup Power Saving Configuration Setup Static Saving 100(OFF) ◄ ► External Speaker Keyless Off Hours Pro:Centric Standby Active power saving Power Saving... -
Page 27: Cec Setup
- Sets the custom code used for NEC Format of the remote control . The default value is 4 . The TV remote control that LG is currently using is 4 so this item is always set to 4 and disabled . -
Page 28: Clock Setup
Clock Setup Installation Menu (V2 . 2 3) LG Hotel Mode Setup Clock Setup TV Link-Loader Clock Display Password Change ◄ ► Dimming Standby Set ID Setup Configuration Setup Dimming PowerOn External Speaker Clock Source Pro:Centric Programme Power Saving Offset ATV Clock... -
Page 29: Download Extra Contents
DownloaD extra contents Download Extra Contents(flash file) toTV set The Pro:Centric application can be downloaded to your TV . FLASH ( * .SWF) / GEM supporting file An SWF file complied with Flash Lite 3 .0 or earlier (the 3 .0 version is recommended) •... - Page 30 You can see a new Application File on TV . Continue to replace ‘Extra Contents’ with one in USB memory? Select ‘Yes’ . MENU INPUT Wait till the download process is completed . After completion of download, TV set will restart automatically . TV is in updating process .
-
Page 31: Download A Splash Image
