Thank you for including the TP7 as part of the user interface
strategy for your customer. The TP7 has been designed to
provide years of trouble free operation when wired and installed
properly. The TP7 has been designed for installation in low
humidity indoor environments and should never be installed
outdoors or in high humidity areas.
Included in the box
1ea TP7 touch panel
•
1ea TP7 mounting bracket
•
4ea Mounting screws
•
1ea DC power connector
•
Introduction
To install the TP7 you will also need a standard 2 gang
US junction box or low voltage bracket.
© 2014 Core Brands, LLC. All rights reserved.
Core Brands, LLC, a Nortek company.
TP7 – 7" Touch Panel
User Interface
Quick Install Guide
Specifications
Dimensions
Overall 8"w x 5"h
Mounting Depth 1 ¾"
Microphone
Dual Digital Beam Forming
Far Field Pickup
Speaker
2w integrated
Camera
640 x 480
Display
7"
800 x 480
Network
10/100 Ethernet
802.11 B/G/N WiFi
Connections
LAN/PoE
RJ-45
Power
2 pin Phoenix
USB
USB Type A
Audio Out
1/8" stereo (Future Use)
Power Requirements
Direct – 12V
PoE – IEEE 802.3at,
13w maximum draw
(@48 V
P/N 9901341 Rev. E0 02/2015
1 A
270 mA max)
