Danfuss AB-QM DN 10-32 Operating Manual

Operating Guide
AB-QM DN 10-32
TWA-Z +
AB-QM DN 10-32
Installation / Montering / Einbau / Installation /Installatie / Installation / Asennus / Montaż / Uzstādīšana / Beépítés / MONTAJ /
Монтаж / Instalace / 安装 / Vgradnja / Instalación / Montavimas
TWA-Z
IP 41
© Danfoss | 2017.07
ABNM + AMV/AME 110 NL, 120 NL +
AB-QM DN 10-32 AB-QM DN 10-32
M *
max
DN
1) M
2) Not applicable with valves with Eurocone connection (003Z1281)
ABNM
IP 54
NovoCon™ +
AB-QM DN 10-32
L
To pipe L (mm) Code No.
10 R 3/8 26 003Z0231
15 R 1/2 27.5 003Z0232
20 R 3/4 30.5 003Z0233
25 R 1 35 003Z0234
003Z0235
32 R 1 1/4 38.5
for DN 10 is 35 Nm
max
AMV/AME 110NL, 120 NL
Weld.c. Solder.c.
Code No. Code No.
L (mm) L (mm)
17 065Z7016
37 003Z0226 22 065Z7017
42 003Z0227
42 003Z0228
003Z0229
42
IP 42
VI.A7.C4.3T | 1
