Summary of Contents for Magnaflux QB2-Plus
- Page 1 155 Harlem Avenue, Glenview, Illinois 60025 USA +1 847-657-5300 Fax: +1 847-657-5388 Rev: 1.A.110218 www.magnaflux.com support@magnaflux.com...
- Page 2 Operating Manual Quick Break Tester QB2-Plus Part Numbers: 628989...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Getting Started..........2 Precautions............2 Specifications ..........3 Operation ............3 Maintenance ............4 Troubleshooting ..........5 Warranty ............6 Support ..............6 QB2-Plus Operating Manual... -
Page 4: Getting Started
GETTING STARTED The QB2-Plus is a test meter used to verify shot time and quick-break function of magnetic particle equipment. Quick-break function applies to 3-phase FWDC equipment only. PRECAUTIONS Inspect QB2 PLUS meter and probe before each use. If damaged, it is strongly recommended to replace the unit. -
Page 5: Specifications
For a 3-turn cable wrap, set for 5,000 A Initiate mag shot and observe results on the meter SHOT TIME mode: Display will read x.xx SEC QUICK BREAK mode: Display will read VAL=x.x Press the center RESET button to clear the display for next reading. QB2-Plus Operating Manual... -
Page 6: Maintenance
MAINTENANCE • Use mild soap and a damp cloth to clean the probe as needed • Do not spray QB2-Plus or immerse any part in liquid Battery Replacement • Remove screws at the corners and lift meter out of housing •... -
Page 7: Troubleshooting
Possible Cause Possible Solution Meter does not Low Battery Replace 9V battery power up Damaged or defective meter Contact Authorized Magnaflux Service Center Erratic readings Wrong mode selected Power unit off. Follow instructions in Operation Probe not positioned Place the probe longitudinally in the... -
Page 8: Warranty
Refer to the Magnaflux Warranty Statement at www.magnaflux.com. SUPPORT If you have a question please contact Magnaflux at: 1-847-657-5300 support@magnaflux.com www.magnaflux.com You can also contact your local Distributor or Magnaflux Authorized Service Center directly; contact information is available at www.magnaflux.com. QB2-Plus Operating Manual...
