- Page 1 Â Intellislot Interface for ™ Relay Contacts Communications Card ANUAL English Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
- Page 2 Upon accepting shipment, please inspect product for any damaged or missing parts. If damaged, call Sola/Hevi-Duty at (800-377-4384) and select the Warranty Support option from the menu. If components are missing, contact your sales representative for replacement. Items included with shipment are: Œ...
- Page 3 INSTALLATION Parts required: Intellislot™ Interface for Relay Contacts card and required cable assembly. Tools required: Either #2 (medium) Phillips or small flat head screw driver. It is suggested, but not necessary, to turn the UPS off prior to installation. Locate the Intellislot™ Port on the rear panel of your UPS.
- Page 4 PIN CONFIGURATION Operation Function UPS Fault Closed if no UPS failure* Not Used Not Used UPS Fault Closed if UPS fails* Summary Alarm** Closed if SUMMARY ALARM** occurs* Summary Alarm** Closed if no alarm conditions are present* Signal Ground (for UPS Any Mode Shutdown) Not Used Common –...
- Page 5 JUMPER SET-UP Connection Description JP01 Pin 9 to Pin 17 Allows all relay COMMONS to be tied together JP02 Pin 7 to Pin 17 Allows all relay COMMONS and the ANY MODE SHUTDOWN GROUND to be tied together. NOTE: This jumper should be removed if there is any external voltage source...
- Page 6 CONTACTING TECHNICIAL SUPPORT The Sola/Hevi-Duty has a team of specially trained technicians waiting to quickly assist you with any installation or troubleshooting problems. Refer to the back of this manual for the Tech Support phone number. In order to successfully diagnose your individual problem, our technicians may require the following installation site and system information.
- Page 7 LIMITED WARRANTY Sola/Hevi-Duty extends the following LIMITED WARRANTY to the purchaser and to its customer (collectively referred to as the "Purchaser"): the enclosed Uninterruptible Power System (UPS) and components are free from defects in materials and workmanship under normal use, service, and maintenance FOR A PERIOD OF ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE from Sola /Hevi-Duty or the Sola Hevi-Duty dealer or retailer.
