LDA Audio Tech SIMAX QX-240 Handbook

Connection of pa/va system simax and lda

Handbook

Connection of PA/VA system SIMAX and

LDA

Device: SXQX240S02

Table of Contents

Need help?

Do you have a question about the SIMAX QX-240 and is the answer not in the manual?

Page 1 Handbook Connection of PA/VA system SIMAX and Device: SXQX240S02...
Page 2 SECURITY INSTRUCTIONS. 1. Please, read these safety instruction carefully. 2. Save this user manual for future use. 3. Unplug the device from the power adapter (AC) before cleaning it. 4. Don´t use liquid or spray detergent to clean the device. 5.
Page 3 DESCRIPTION OF THE SYSTEM. The system consists of three devices: 1. Mixer/amplifier model QX-240 of the SIMAX trademark (see handbook). 2. A-1 microphone station of the LDA trademark (see handbook). 3. Amplifier BA-2500 of the LDA trademark (see handbook). The input sources to the system are connected to the inputs of the QX-240, with the input 1 of said equipment reserved for the microphone A-1 to active the priority.
Page 4 The typical wiring for unbalanced stereo and mono cables at the input of balanced audio system is show below. CONNECTION WITH STEREO WIRE. CONNECTION WITH WIRE MONO. * Impedance matching with a 10 Kohm resistance bridge.
Page 5 CONNECTION DIAGRAM. As explained above, the connection will be made between the pre-amplified output of the QX-240 (connection module # 4) and the line inputs of the BA-2500 amplifier (connection terminal # 3). It will be necessary to make a short wire with a JACK stereo (balanced) connector on one end, and a three-way terminal on the other.
