- Page 1 FEQ-31 31-BAND MONO EQUALIZER N Instruction manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
-
Page 3: Exemption Of Liability
The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use. -
Page 4: Controls And Functions
CONTROLS AND FUNCTIONS FRONT PANEL 1.- Frequency controls: each one of these line potentiometers can increase or decrease the selected frequency by ±6 dB or ±12 dB. When all the potentiometers are in the middle, the equalizer output has a flat response. 2.- LEVEL: this control assigns the signal level to the equalizer. -
Page 5: Back Panel
If the fuse blows again, do not use the equipment and get in contact with the authorized FONESTAR technical service. 3.- Earth switch: switch that is used to disconnect the earth signal from the case. If there is buzzing in the system due to the earth connection or links to other pieces of equipment, move this switch to the LIFT position. -
Page 6: Specifications
SPECIFICATIONS FEQ-31 CHARACTERISTICS 31 band 1/3 octave, 20-20,000 Hz mono graphic equalizer. CONTROLS ±6 dB or ±12 dB (selectable) sliders and bypass switch FILTERS 31 1/3 octave, 1 high- pass and 1 low-pass RESPONSE 20-50 000 Hz THD DISTORTION 0.02% at 1000 Hz, centred controls INPUTS 1 balanced/unbalanced line, XLR/6.3 mm jack 20 000 Ω... -
Page 7: Declaration Of Conformity
2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
