Summary of Contents for FONESTAR FEQ-1515
- Page 1 FEQ-1515 2 X 15 BAND STEREO EQUALIZER N Instruction manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
- Page 3 The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.
-
Page 4: Controls And Functions
CONTROLS AND FUNCTIONS FRONT PANEL 1.- Filter controls: each one of these lineal potentiometers can increase or reduce the selected frequecy ±6 dB or ±12 dB. When all the potentiometers are in the centre, the equalizer output has a flat response. 2.- INPUT: this control assigns the signal level to the equalizer. - Page 5 If the fuse blows again, do not use the equipment and get in contact with authorized FONESTAR technicians. 3.- GND/LIFT: switch used for disconnecting the earth signal from the chassis. If there is buzzing in the system due to an earth connection or a link to other equipment, move this switch to the LIFT position.
-
Page 6: Specifications
SPECIFICATIONS FEQ-1515 CHARACTERISTICS 2 x 15 band 2/3 octave, 25-16,000 Hz stereo equalizer CONTROLS ±6 dB or ±12 dB (selectable) sliders and bypass switch GND lift earth disconnection FILTERS 2 x 15, 2/3 octaves, 1 high-pass and 1 low-pass per channel... - Page 7 2 months after being conscious of the problem. It is only necessary to contact FONESTAR if it is impossible or imposes an undue burden for them to solve it. To benefit from this warranty it is necessary to show the proof of purchase with the date clearly visible, with no corrections or crossing out.
