E-FLITE EFLC2002 Manual

DC Fast Charger
for Electric Gliders
Thank you for purchasing an E-flite™ charger.
This DC-powered 7.2-8.4V time charger will
allow you to fast charge Ni-Cd and Ni-MH
battery packs for your electric glider. When
used properly following these instructions,
this charger will provide many years of
trouble-free operation.
• Charges 6- or 7-cell 1200-2000mAh
Ni-Cd and Ni-MH packs
• 20- to 30-minute charger w/timer
• Heavy-gauge wire with large alligator clips
• Tamiya connector

Supplying Power to the Charger

This DC Fast Charger requires a 12V power
source, such as a 12V 7-amp Sealed Battery
(HAN102) or an automobile 12V battery.

EFL2002 Specifications

• Input Leads: 6ft w/large alligator leads
• Output Leads: 1ft w/Tamiya-style connector
• Timer: 30 minutes
• Case Size: 5
• Charge Indicator: red LED
• Trickle-Charge Rate: 30mAh
• Charge Rate: 3.6 amps
• Do not attach the charger to an auto-
mobile battery while the engine is running.
• Do not leave the charger unattended
while you are charging a battery pack.
• Continuously monitor the temperature
of the battery pack while it is being
charged. If the pack at any time becomes
very warm to the touch, disconnect the
battery immediately.
EFLC2002
Instructions

EFLC2002 Features

3 / " x 3" x 2"
4

Safety Tips
