Nav TV DIFF CAM-Switcher Install Manual page 2

Input
from car
Output to
screen
8
4
Normally connected pairs
(When no 12v is present on either
trigger)
B
PIN # Description
1 Not Used
2 Video 1 Trigger
6 Ground
:
Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
VSW Harness pin outs
Input/Output Connector
PIN #
1
2
5
3
4
5
6
7
8 Video OUT + (screen side)
1
Power/Trigger Connector
8
4
Color
White/Blue
White/Red
Black
Description
--
DIFF Video IN (-)
Video IN - (car side)
Video OUT - (screen side)
--
DIFF Video IN (+)
Video IN + (car side)
5
A
1
Label
A LED: When illuminated,
Video 1 is active
A & B LEDs: When both
illuminated (NOT USED)
BHM
11/17/16
NTV-DOC149
rB5
Color
--
White/Purple
White/Orange
Orange
--
Purple
White/Blue
Blue
Description
2 | P a g e
