ECR301 User Manual
．Package Content
Super Speed USB3.0
CFI/CFII/MD▼
MS/MS Pro/MS Duo/MS Pro Duo▼
eSATA
M2▲
MicroSD▲
SD/MMC/RS MMC▲
USB3.0
USB2.0
EN
ECR301
Screws *4
User manual
．Installation
．Connections
EN
(e) internal motherboard USB 3.0 connector
( f ) 4-Pin PSU molex connector
(g) internal motherboard USB 2.0 connector
(h) SATA 7 Pin connector
．Attention
EN
Electrostatic discharge (ESD) can damage system components. Use an ESD controlled
workstation. If such a workstation is not available, wear an antistatic wrist strap or touch
an earthed surface before handling any PC components.
