Package content

Accessories

Quantity

EMK3105PCI 1
1
SATA 7 pin data cable
1
SATA 15 pin to 4 + 4 pin Power Cable
4
Screws
1
Key
1
IInsulating pad
1
User manual

Parts

1 2 3 1 2
Unock
Lock
Front panel Back panel
1. Key lock (A:Lock B:Unock) 1. SATA power connector (15P)
2. Spring lock 2. SATA data connector (7P)
3. HDD LED indicator 3. LED access port (4P)

Installation

1.
3
2.
3.
Taking off one of sockets in the back of host case.
Putting carefully EMK3105PCI to the socket.
Confirming EMK3105PCI is flat, then screw to fix it.
