1
Step 1.
First, remove the wall plate from the
desktop by pushing inward on the metal legs.
3
Step 3.
Now you have both pieces separate.
Call Free 1.800.848.1633 or 1.888.HCL-INTL Fax Free 1.800.447.2923
Website: www.HealthCareLogistics.com • Email: hcl@HealthCareLogistics.com
ASSEMBLY INSTRUCTIONS FOR
Slim Line Wall Desk (#17684)
2
Step 2.
Pull the metal leg from the desktop.
4
Step 4.
Using a level, place the wall plate in the
desired place on the wall. (Note: Make sure the white
plastic loop is hanging downward.)
NOTE: Be sure to select
the appropriate mounting
hardware to ensure safe
and reliable use. Mount
hardware through a stud,
blocking or rigid structure
where possible during
installation.
© Health Care Logistics, Inc. 2010
Advertisement
Related Manuals for Health Care Logistics 17684
Summary of Contents for Health Care Logistics 17684
- Page 1 ASSEMBLY INSTRUCTIONS FOR Slim Line Wall Desk (#17684) NOTE: Be sure to select the appropriate mounting hardware to ensure safe and reliable use. Mount hardware through a stud, blocking or rigid structure where possible during installation. Step 1. First, remove the wall plate from the Step 2.
- Page 2 ASSEMBLY INSTRUCTIONS FOR Slim Line Wall Desk (#17684) Step 5. Place a screw in the first mounting hole. Step 6. Tighten the screw with a screwdriver and repeat with the remaining three mounting holes. Step 7. Now replace the desktop.
- Page 3 ASSEMBLY INSTRUCTIONS FOR Slim Line Wall Desk (#17684) Step 11. Close desk to keep it out of the way. Call Free 1.800.848.1633 or 1.888.HCL-INTL Fax Free 1.800.447.2923 Website: www.HealthCareLogistics.com • Email: hcl@HealthCareLogistics.com © Health Care Logistics, Inc. 2010...
