Analogue / IP electronics add-on handset
GB GB

General Information

generAl informAtion
1.
Optional installation of additional boards leads
to an increased scope of applications of your
Behnke door intercom's main board. There
needs to be enough room within the electronics
housing to hold the additional board. For door
intercom devices with built-in electronics, the
additional board may be directly connected to
the main board. In case the electronics were
installed in a separate installation, you will need
a special adapter plus cable for connection
purposes. Depending on the additional board
in use, other accessory equipment may be
necessary or useful. The electronics add-on
AIF handset can only be used with an a/b or
IP Behnke series 20 door intercom. The door
intercom must be a size 3 or bigger.

1.1. Electronics add-on AIF handset

The electronics add-on AIF handset enables
the connection of a Behnke handset module
(20-/21-1104 or 20-/21-1104-IP respectively)
to analogue or IP (SIP) Behnke series 20 door
intercom stations. The electronics add-on AIF
handset is also included with the analogue
mode handset (20-/21-1104). For the IP mode
handset (20-/21-1104-IP), the electronics
add-on AIF handset is integrated into the
correspon ding basic electronics.
Please note: Order suitable IP basic electronics.
15
Analogue electronics add-on AIF handset
(Included with the handset module 20/21-1004)
Electronics add-on AIF handset IP (included with the IP basic electronics,
order suitable basic electronics)
