Adcom GTP-870HD Quick Start Manual

GTP-870HD Quick Start Guide
1
Unpacking
What's in the box
• GTP-870HD
• Remote control
• 1.5V AAA batteries (4)
• Audio/video cable
• FM antenna
• FM antenna adapter
• AM loop antenna
• Power cord
• Warranty card & statement
• User's guide CD
3

Remote Control Overview

1
2
15
3
16
4
17
18
5
19
6
20
7
21
22
23
8
24
25
26
9
27
10
28
11
12
29
13
30
14
31
32
33
For additional information, including updates to the User's Guide,
IR codes, and RS232 codes, visit www.adcom.com
1 Main 18 Menu
2 Source Selectors Select / HD Format
19
Power Stop
3 20
4 Input Selectors Mode Select
21
5 Play 22 TH-EQ
6 Arrows 23 CH-TRIM
7 Pause 24 Tuning Up/Down
8 Direct Access Keypad 25 Test
9 FM/AM/HD 26 Stereo/Mono
10 Memory Seek
27
11 Bass/Programmable 28 Preset/Tune
12
Treble/Programmable 29 Lip Sync
13 Sleep 30 Dynamic Range
14 Backlight 31 Bypass
15 Mute 32 Dim
16 Volume Up/Down 33 Macro 1-4
17
Setup
(See Step 4 for instructions
on overriding a Setup Lock)
2

Basic Connections

Powered
Subwoofer
1 2 3 4 5 6 7
GTP-870HD
tuner inputs
in
video 4
AM Y Pb Pr
15uH
loop video 3 in
gnd
video 2 in
FM 75 ohm 7.1 preamp outputs
R L
RF RS RB
RF LF video 1 in
aux output
R L Y Pb Pr
RS LS out
zone 2 outputs
video 1 in
R L
monitor outputs
R L please visit www.adcom.com
var RB LB HD bypass
out tyranscoder out
zone 2 main
video 4
fixed C S
video out 12V DC 75 ohm
in tape output
audio
monitor output
12V DC
trigger RF LF out video 4 in in
IR input IR input IR input trigger coaxial 1 optical 1
R tape L video 3
out
RS LS in video 3 in in
RS232 control
in RB LB in video 2 in in video 2 in
Model: GFR-700
in C S in video 1 in in
audio video
cd ext 7.1 inputs R L CVBS S-video HDMI switcher
4

Setup Menus

Setup Navigation
Use the following remote control buttons to navigate
the Setup menu.
Main
• Main - Press the Main button to select the GTP-
870HD. You must first select the GTP-870HD
before you can access the Setup menu.
Arrows
• Setup - Press the Setup button to display and
exit the Setup menu.
• Arrows - Press the / buttons to move the se-
lection arrow up or down the list of menu items.
Press the / buttons to step through all avail-
able options for the selected menu item.
• Select - Press the Select button to confirm your
menu selections.
To override the Setup Lock:
Press Video 2 and Sur Mode on the front panel.
Use the switch on the back
of the unit to turn the
power on after making all
of your connections.
Amplifier
balanced audio outputs
C LB LS LF
digital audio inputs
75 ohm 75 ohm
coaxial 2 optical 2 coaxial 3 optical 3
Model GTP-870
Power Rating: 120V ~ 60Hz /
230V~ 50Hz
Power Consumption: 50W max
120 V 230 V
Power Rating: 120V ~ 60HZ
230V ~ 50Hz
please visit www.adcom.com
Power consumption: 780W max
DVD Player
Setup
Select /
HD Format
on off
HDTV
TV
