ELECTRICAL SYSTEM
ELECTRICAL APPLIANCES
Clothes iron
Toaster (2 slice)
Coffee maker
(1) The carbon monoxide/propane sensor drains the batteryin two weeks
if the trailer is not connected to a 120-volt feed. You therefore should
disconnect the F6 fuse for the batteryin the converter (green fuse) to
avoid triggering the alarm signal.

The trailer's 120-volt AC system and converter/charger

The 120-volt AC system in a trailer is similar to that in your home and can recharge the
batteries through a converter/charger.
This current comes from an electrical outlet in a campground (15 or 30 amps) or directly
from your home.
Your trailer has circuit (breakers) for the 120-volt system, located in
converter/charger panel.
CONSUMPTION(AMPERES)
AC (120 V)
4
10
7
Battery fuse
DC (12 V)
N/A
N/A
N/A
81
081
