- Page 1 1019-E ALARMS MANAGEMENT MULTIFUNCTIONAL CONTROL PANEL OPERATOR MANUAL MANUAL NO.TM0009-A Revisione 2 Pagina 1 di 46 TM0009-A...
- Page 2 PROPRIETARY RIGHTS NOTICE This document and the informations that it contains are the propety of FENWAL ITALIA S.p.A.. Rights to duplicate or otherwise copy this document, the rights to disclose the document and the informations that it contains to others and the right to use the information contained therein may be acquired only by written permission signed by a duly authorised officer of FENWAL ITALIA S.p.A..
- Page 3 Preliminary Pages AMENDMENT INCORPORATION RECORD Amendment No. Brief Description of Content Author Production configuration. Level 2 fire Password = 144567 Level 3 fire Password = 198767 Production Configuration. Servicing Password = 3***** INDEX Page 3 of 46...
-
Page 4: Table Of Contents
____ SAFETY SECTION (FIRE) ........................... 5 INTRODUCTION ..........................6 ACCESS TO THE PANEL FUNCTIONS..................11 1.2.1 Silence Buzzer ..........................13 1.2.2 Scroll ............................13 1.2.3 Silence Sounders ......................... 13 1.2.4 Reset ............................. 14 1.2.5 Delay Override ..........................14 1.2.6 Evacuate ............................14 ↵... -
Page 5: Safety Section (Fire)
1 SAFETY SECTION (FIRE) Page 5 of 46... -
Page 6: Introduction
INTRODUCTION The operator interface of the new 1019-E panel is a 256x64 Dots graphic LCD, with 14 signals leds and 22 functions buttons as shown in figure A. The 1019-E is built in accordance to the EN-54-2 std.with the following functions: Function EN54-2 Ref. - Page 7 Led Test (Fire) It is illuminates constantly when the panel is in test mode. It switches of automatically at the test mode exit. In case of a zone test mode, the alarm signal from devices/inputs must not start the actuation, but only the signals.
- Page 8 The led is extinguished automatically at the end of the count down or when the delay override button is pressed Led System Fault (fire/intrusion) The led is illuminated constantly when a microprocessor fault (watch-dog) or a memory fault is detected. The led is extinguished automatically only when power supply is turned off The led is installed on the card in a visible location.
- Page 9 A message must be visualized on display, memorized in the event log and sended to the pheripherical (if any – host/printer i.e.). Numerical button 1 (Fire/intrusion) It is utilized to select the password numerals and to introduce datas in the various operator menu .
- Page 10 CR button (Fire/intrusion) It affects in the various operator menu to confirm the pressed buttons or to confirmthe selected menu on display. Arrow up button (Fire/intrusion) It is utilized to select the menu various options in vertical way.. Arrow down button (Fire/intrusion) It is utilized to select the menu various options in vertical way..
-
Page 11: Access To The Panel Functions
ACCESS TO THE PANEL FUNCTIONS The access to the panel fire fighting functions is organized on 3 different levels. The access to the first level does not require any password. Each access level has a proper operative system, as shown in the following table, that define the operator use of the panel. It is possible reach the 2 and 3 levels only digitinga password on the front keyboard of the panel. - Page 12 STATUS Tue 03 Apr 01 10:33 N O RM AL FENWAL figure 1 To reach the required level (level 2 or 3), press button 1, the request “Select password” will be shown on display (see figure 2). At this time digit the four numbers of the password code and press confirmation button.
-
Page 13: Silence Buzzer
Saf et y ( Ar ea- 1) Access Level 3 1: I sol at e/Dei sol at e 2: Li st 3: M anagem ent 4: Test Sel ect opt i on usi ng L M and ↵ figure 3 1.2.1 Silence Buzzer When the panel inside buzzer is operating, pressing the keyboard Silence Buzzer button, the buzzer will acknowledge. -
Page 14: Reset
Access Level EVACUATE Tue 03 Apr 01 10:33 FENWAL figure 5 The evacuate function will be active till the silence sounders button will be pressed. Pressing Evacuate button when an alarm is active, the display will show the confirmation, as per figure 6, up to the deactivation. -
Page 15: Confirmation Button ( )
↵ ↵ ↵ ↵ 1.2.6 Confirmation button ( With the Control Panel in “Normal Status”, the Confirmation button is used to accept numerical codes,. to reach the menu options and to confirm system datas insertion. During an alarm activation, Confirmation button will be used to show datas of each devices as per figure ALARM Tot al Fi r st Zone 1... -
Page 16: Isolate/Deisolate
ISOLATE/DEISOLATE Selecting Isolate/Deisolate it is possible to reach the isolate/deisolate menu as shown in figure 8. The menu option can be selected using the directional buttons and the confirmation button to confirm the option choise. I sol at e/Dei sol at e Access Level 3 1: Zone I nput s 2: Zone O ut put s... -
Page 17: Output Zone
Sensors/I nput s Zone Access Level 3 1: Zone 001 N orm 2: Zone 002 N orm 3: Zone 003 I sol 4: Zone 004 I sol L M and ↵ or ESC t o qui t figure 10 1.3.2 Output zone Selecting this option with a single operation, it is possible to isolate all the outpots of a zone. -
Page 18: Devices
1.3.3 Devices Selecting this option is possible to isolate a single device either an imput, a detector, or an output. It is required the zone number as shown in figure 11. After selecting the zone number the display will show three available options as per figure 13. Select the needed option by means of the directional buttons and press confirmation button for the required option. -
Page 19: Panel Sounders
Access Level DEVI CES Tue 03 Apr 01 10:33 I SO LATED FENWAL figure 16 1.3.4 Panel Sounders Selecting this option is possible to isolate the two local sounders output of the panel as shown in figure 17. In this phase acting on directional buttons is possible to select the needed output, than press confirmation button to isolate or deisolate the selected output sounder. -
Page 20: Local Buzzer
I sol at e Panel Sounders Access Level 3 1: Sounders O ut put 1: N orm al 2: Sounders O ut put 2: I sol at ed L M and ↵ or ESC t o qui t figure 17 After the isolate control the COMMON ISOLATE led will illuminate constantly and OUTPUT ISOLATE led will flash. -
Page 21: List
Access Level BUZZER Tue 03 Apr 01 10:33 I SO LATED FENWAL figure 19 LIST Selecting this option the operators function list is reached, as shown in figure 20. The list items can be selected acting on directionals and confirmation buttons or pressing the correspondent numerical button of the required option. -
Page 22: Isolations
Using directional button is possible to run throught the zone list. Press ESC button to return at the previous menu. Pressing confirmation button a complete zone listwill be printed, if the control panel configuration provides printer option rated. 1.4.2 Isolations Selecting this option the display shows the fire section active isolation menu, as reported in figure 21. -
Page 23: Panel Function (System Isolation List)
Li st I sol at i ons Devi ces Access Level 3 Zone 001 N orm al Sensor 001 O per at Sensor 002 N orm al L M t o scrol l ESC t o qui t figure 24 1.4.2.2 Panel Function (system isolation list) Selecting panel function option a system isolation list will be shown on display as per figure Li st I sol at i ons Syst em... -
Page 24: Alarm Log
Li st Event Log Access Level 3 Event 001 Tue 03 Apr 2001 14: 01: 05 Zone O ut put 1 O UT1 Event I SO LATE L M t o scrol l ESC t o qui t figure 26 Using directional buttons is possible to scroll the next event. -
Page 25: Extinction Enable
M anagem ent Access Level 3 1: Ext i nct i on Enabl e 2: Ti m e and Dat e updat e 3: Panel Conf i gur ati on 4: User Passw ord Sel ect opt i on usi ng L M and ↵ figure 28 1.5.1 Extinction Enable This option is used to enable the discharge control from the extinction cards. -
Page 26: Panel Configuration
Set Ti m e and Dat e Access Level 3 Tue 03 Apr 01 14: 10 Set Ti m e 14: 10 ( hh: m m ) Set Dat e 03/04/2001 ( dd/m m /yyyy) Sel ect opt i on usi ng L M and ↵ figure 29 If time and date are inserted with two numbers figure, using numerical buttons, the next line will be automatically enable. -
Page 27: Communications
It is not possible to manually modify it. Company Name: The two rows are standard programmed with FENWAL ITALIA S.P.A. text. It is possible to change it during panel software configuration ONLY and not in this menu. - Page 28 figure 30C. Pr i nt er Set up Access Level 3 Pr i nt er Di sabl e Baud Rat e 9600 M ode Com pl et e Dat a Bi t s St op Bi t s Par i t y H andshake Xon/Xof f Sel ect opt i on usi ng L M and ↵...
- Page 29 H ost Com put er Access Level 3 H ost Di sabl e Baud Rat e 9600 Dat a Bi t s St op Bi t s Par i t y H andshake Xon/Xof f Sel ect opt i on usi ng L M and ↵ Figure 30D The reported are default values.
- Page 30 TCP/I P Access Level 3 H ost Di sabl e I P Panel 000. 000. 000. 000 I P M ast er 1 000. 000. 000. 000 I P M ast er 2 000. 000. 000. 000 I P Gat ew ay 000.
-
Page 31: Various Parameters
The reported are default values. To modify the printer configuration set use arrow keys and enter key. Press ESC to exit and return to the previous menu. For new configuration the admitted values for each field are the following: • Network Disable: disables the communication on remote keyboards bus. - Page 32 U ser Passw ord Access Level 3 1: Change Level 2 Passw ord 2: Change Level 3 Passw ord Sel ect opt i on usi ng L M and ↵ figure 31 To select the wanted level is required to insert a code of 4 numbers. For security reasons the display shows # symbols.
-
Page 33: Test
TEST This option is used to perform controlpanel tests. Selecting test option, the display will show the information per figure 33. The option can be selected using the directional buttons, then press confirmation button. Test Access Level 3 1: Panel Test 2: Zone Test Sel ect opt i on usi ng L M and ↵... - Page 34 Zone 1 i n Test M ode Access Level 3 Test M ode Di sabl e Test Ti m e O FF Sel ect opt i on usi ng L M and ↵ Figure 34A Then press confirmation button to put the zone in test mode. Pressing repeatedly the confirmation button is possible enable or de-enable the test function for the selected zone.
-
Page 35: Events Visualization
STATUS Tue 03 Apr 01 10:33 N O RM AL FENWAL Figure 35A If during the initialising phase a system failure is detected, the local sounder, the system fault led and the system output fault are activated. The example shows a failure on card 44 (figure 36). - Page 36 At the end of the initialisation phase the display will be as indicated in Figure 36A. Access Level PAN EL Tue 03 Apr 01 10:33 FAULT FENWAL Figure 36A Pressing ESC button the panel the Fault situation will be visualised as indicated in figure 36B. PAN EL FAULT...
-
Page 37: Isolate
1019- E PAN EL I ni zi al i zat i on f ai l ed: panel hal t ed Figure 37 If the faults are detected after the initialising phase, the panel continues its work with exception for two cases: Memory Error and Cpu Failure, in these cases the program is stopped. -
Page 38: Fault
Access Level DEVI CES Tue 03 Apr 01 10:33 I SO LATED FENWAL figure 38 1.7.3 Fault Following a Fault conditionthe panel performs the following actions: • Common fault led on frontal panel will flash • Buzzer output will activate intermittently •... - Page 39 FAULT Tot al Fi r st Zone 1 Sensor 02: SEN S02 01/02 Li ne O pen Pr ess Scrol l or ESC t o qui t Figure 40 If more events of the same style are present at the same time the display will show the following messages: •...
- Page 40 Access Level SYSTEM Tue 03 Apr 01 10:33 RESET FENWAL figure 43 If during the fault events visualization an event with higher priority occurs, this will be immediatly shown on display. The presence of lower importance events will be reported on display as per figure 44.
-
Page 41: Prealarm
1.7.4 Prealarm Following a prealarm condition, the panel performs the following actions: • Prealarm led on frontal panel will flash • Buzzer outputwill activate intermittently • Fire prealarm output will activate constantly • Eventual activation of outputs in concurrence with the event The display will show the figure 45 message. - Page 42 49 message. Access Level SYSTEM Tue 03 Apr 01 10:33 RESET FENWAL figure 49 If during the prealarm events, an event with higher priority occurs, this will be immediately shown on display as per figure 50. Page 42 of 46...
-
Page 43: Alarm
ALARM Low pri ori t y event s pendi ng Tot al Fi r st Zone 1 Press ↵ or ESC t o qui t Figure 50 The presence of lower important events will be reported on display as per figure 50A. PREALARM Low pr i or i ty event s pendi ng Tot al... - Page 44 Pressing the confirmation button the zone device in alarm list is shown as per figure 52. ALARM Tot al Fi r st Zone 1 Sensor 02: SEN S02 01/02 Pr ess Scrol l or ESC t o qui t Figure 52 If more events of the same style are present at the same time, the display will show the following messages: •...
- Page 45 SYSTEM Tue 03 Apr 01 10:33 RESET FENWAL figure 56 In case of alarm it is not possible to perform the reset if buzzer and sounders have not been silenced. In case system reset is tried without the correct procedure a message will be visualized on the lower line of the display for three seconds (see figure 57).
- Page 46 ALARM Tot al Fi r st Zone 1 Buzzer and sounder s m ust be si l ence bef or e Figure 57 The presence of lower priority events will be reported on display as per figure 58. ALARM Low pr i ori ty event s pendi ng Tot al Fi r st Zone 1 Pr ess ↵...
