B E F O R E F L I G H T
DOWNLOAD FREEFLIGHT PRO AND PIX4DCAPTURE (Available on the App Store only)
1. Sign in to the App Store®.
2. Download the free apps FreeFlight Pro and Pix4Dcapture on your smartphone or tablet.
• It is recommended to use Pix4Dcapture the free application allowing to generate a flight plan to capture
photos above a specific area and to make your drone fly autonomously.
• FreeFlight Pro is the official free application of Parrot allowing to freely pilot the drone.
CHARGE THE BATTERY OF PARROT DISCO-PRO AG
1. The battery must be unplugged from Parrot Disco-Pro AG.
2. Select the supplied adapter depending on your country and insert it into the charger.
3. Connect the cable to the charger.
4. Connect the battery to the charger cable and then plug the charger into the AC outlet.
The charge time is approximately 55 minutes for an approximate flight time of 25 minutes.
The light indicator is red during charge and turns green when the battery is charged.
CHARGE THE BATTERY OF PARROT SKYCONTROLLER 2
1. Select the supplied adapter depending on your country and insert it into the charger.
2. Connect the cable to the charger.
3. Connect Parrot Skycontroller 2 to the charger cable and plug the charger into the AC outlet.
The charge time is approximately 1 hour and 40 minutes for 4 hours of use.
The light indicator is red during charge and turns green when the battery is charged.
C H E C K L I S T

Advertisement

loading
Need help?

Need help?

Do you have a question about the DISCO-PRO AG and is the answer not in the manual?

Questions and answers

Related Manuals for Parrot DISCO-PRO AG

Summary of Contents for Parrot DISCO-PRO AG

  • Page 1 1. Select the supplied adapter depending on your country and insert it into the charger. 2. Connect the cable to the charger. 3. Connect Parrot Skycontroller 2 to the charger cable and plug the charger into the AC outlet. The charge time is approximately 1 hour and 40 minutes for 4 hours of use.
  • Page 2 M A K E S U R E Y O U . . . Take off the drone’s cover. Insert the Parrot Disco-Pro AG battery into the dedicated slot in Parrot C.H.U.C.K. Take off the protective lens and the protective Insert the SD card in Parrot Sequoia.
  • Page 3 Skycontroller 2 and install the smart device in it. already paired with Parrot Disco-Pro AG. Connect the USB cable of your smart device from Parrot Skycontroller 2 to your smart device. Turn on Parrot Disco-Pro AG. The button must The Parrot Skycontroller button is green when it be green.
  • Page 4 This step will allow you to simply configure the drone flight above your plot as well as the automatic photo capture done with Parrot Sequoia. 1. Open the application Pix4Dcapture and create an account. 2. Select Parrot Disco-Pro AG. 3. Select the mission: • GRID 4.
  • Page 5 14. The photos are stored on the SD card. Remove the SD card from the drone to put it on your computer. 15. Go to parrot.airinov.com or cloud.pix4D.com and enter your email adress to create an account. 16. Select the photos from your SD card. In case you have performed the radiometric calibration of your Sequoia, add the images coming from the calibration to the selected photos.
  • Page 6 R A D I O M E T R I C C A L I B R A T I O N O F PA R R OT S E Q U O I A It is not mandatory to perform a radiometric calibration if you want to create an NDVI map.
  • Page 7 PIX4DCAPTURE– MISSION RESUME AND MULTI-BATTERY FLIGHTS Mission resume allows to continue a mission that has been aborted or interrupted by taking over manual control. The incomplete portion is saved in the same project as a new mission, so that it can be executed later. The procedure to create the remaining mission of an interrupted one is described here: 1.
  • Page 8 • Any Parrot Skycontroller button. • The ABORT button. After that, Parrot Disco-Pro AG will turn on the standby mode and wait for your commands. Several options are available: • Flight with manual control using Parrot Skycontroller 2. • RESTART the Flight Plan, so the mission will start again.

  • Page 9: Update Available

    Launch the process as follow: • Select: • The drone calibration menu will appear. • Follow instructions to calibrate the Parrot Disco-Pro AG. Note: Drone calibration can also be done with FreeFlight Pro app. BATTERY NOT CHARGED ENOUGH • Charge the battery.
